By increasing the Q to 10.000, the center frequency remains the same. The markers show
the bandwidth of the filter narrowed to between 900 Hz and 1200 Hz, or about 300 Hz
(see figure 29). Using the Q value, parametric filters can be used to notch out a very
narrow, or very wide range of frequencies.
Figure 29. Parametric Filter at 1000 Hz, Q: 10.000
The dialog box above shows the frequency curve for a single active filter. To add its effect
to the overall frequency response, remove the bypass on the other filters by clicking
Bypass.
