Page 1 User Guide Audio Products Mixers and Processors DMP 128 Digital Matrix Processor 68-2036-01 Rev. C 08 13...
Page 2: Safety Instructions
safety instructions chinese simplified Safety Instructions • English （简体中文）警告：产品上的这个标志意在警告用户该产品机壳内有暴露的危险 WARNING: This symbol, , when used on the product, is intended to 电压，有触电危险。 alert the user of the presence of uninsulated dangerous voltage within the product’s enclosure that may present a risk of electric shock. 注...
Page 3 Extron Safety and Regulatory Compliance accessibility, and related topics, see the “ Guide” on the Extron website. Copyright © 2013 Extron Electronics. All rights reserved. Trademarks All trademarks mentioned in this guide are the properties of their respective owners. The following registered trademarks ®...
Page 4: Conventions Used In This Guide
conventions used in this guide Notifications The following notifications are used in this guide: DANGER: A danger indicates a situation that will result in death or severe injury. A warning indicates a situation that has the potential to result in death or warning: severe injury.
Page 5: Table Of Contents
contents Introduction Line Output Channels ........58 ............1 Post-mixer Trim Control (TRIM) ....58 About This Guide ..........1 Loudness (LOUD) ......... 58 About the DMP 128 Digital Matrix Processor ..1 Delay Block (DLY) ........61 Features ............. 1 Filter Block (FILT) ..........
Page 6 DSP Configurator Windows Menus ....97 SIS Programming and Control ...... 129 Keyboard Navigation ........97 Connection Options ........129 Optimizing Audio Levels ......... 100 RS-232 Port ..........130 About Setting Gain Structure ...... 101 USB Port (Front Panel) ........ 130 Setting Input Gain ........
Page 7: Introduction
DMP 128 C AT — 12x8 ProDSP processor with AEC and Dante • DMP 128 C P — 12x8 ProDSP processor with AEC and Phone (POTS) interface • DMP 128 C P AT — 12x8 ProDSP processor with AEC, Phone (POTS) interface, •...
Page 8 Inputs — Twelve balanced or unbalanced mic/line level on 3.5 mm, 3-pole and • 6-pole captive screw connectors, eight with phantom power. Outputs — Eight balanced or unbalanced line level on 3.5 mm, 6-pole captive screw • connectors. • Eight channels of acoustic echo cancellation (AEC) — The DMP 128 C models include eight independent channels of high performance AEC, as well as selectable noise cancellation.
Page 9 Device manager — Device Manager in the DSP Configurator Software enables • easy configuration of multiple Extron DSP products, including two linked DMP 128 processors, by toggling between graphical user environments for each unit. Processors can be grouped into folders for organizing as separate rooms or buildings. Settings for multiple Extron DSP products in the Device Manager can be saved to a single file.
Page 10: Dmp 128 Application Diagram
-2 32 Stereo E IN /L IN M IC 0. 6A M IC 0- 24 /6 0 Extron Recording Device DmP 128 -7 0 W IR Digital Matrix 4/ 8 Processor O FF IT E LI m O TE S IG...
Page 11: Installation
installation This section describes the installation of the DMP 128, including: mounting the DmP 128 • • DmP 128 models • Hardware Configuration • Rear Panel Features and Cabling • USB Configuration Port (Front Panel) Front Panel Indicators • • Reset Actuator and LED Mounting the DMP 128 The 1U high, full rack width, 8.5-inch deep DMP 128 Digital Matrix Processor can be: •...
Page 12: Rear Panel Features And Cabling
Panel Features and cabling DMP 128 C AT DMP 128 C AT 100-240V ~ 0.6A MAX 1 2 3 4 5 G 7 8 9 10 G MIC +48V LINE PHONE RS-232 RESET 50/60 Hz 11 12 13 14 15 G...
Page 13 Do not tin the wires! mono output connectors — Four 6-pole 3.5 mm captive screw connectors provide up to eight balanced or unbalanced connections for mono line level output signals. Audio Output Wiring Ring NO Ground Here Sleeve Sleeve Balanced Output Unbalanced Output Do not tin the wires! attEntion:...
Page 14 EXP port connector — One RJ-45 jack for one additional DMP 128 connection. The EXP connector has a green LED to indicate proper connection to an active expansion network and a yellow LED that blinks to indicate data activity. notE: A one foot shielded CAT 6 cable is provided for the EXP connection.
Page 15: Usb Configuration Port (Front Panel)
OUTPUTS ACTIVITY CLIP CLIP SIGNAL SIGNAL CONFIG DMP 128 DIGITAL MATRIX PROCESSOR Figure 7. DmP 128 Front Panel Power LED — The power indicator blinks during power-up and firmware uploads, and lights solid when the DMP 128 is operational. Ç Activity Indicators — Two green LEDs labeled EXP ( ) for the expansion audio port É...
Page 16: Reset Actuator And Led
reset actuator and LED A recessed button on the rear panel initiates several reset modes. The rear panel LED blinks to indicate the reset mode. Rear Panel 1 2 3 4 5 G 7 8 9 10 G PHONE RS-232 RESET 11 12 13 14 15 G 16 17 18 19 20 G...
Page 17: Digital I/O Ports
mode 5 — Factory default reset: With power on, press and hold the reset button until the reset LED blinks 3 times (~9 seconds). Release then momentarily (<1 second) press the reset button to return the DMP 128 to factory default conditions. If the second momentary press does not occur within one (1) second, the reset is exited.
Page 18: Dmp Software
DMP software This section describes the control software for the DMP 128, including: • Software Control Windows-based Program Control • • DSP Configurator Program Basics • Audio level, mix-point, Processing Blocks, and Signal Chains • mic/Line Input Signal Chain Controls • Telephone Rx (DmP 128 C P and DmP 128 C P AT only) •...
Page 19: Windows-Based Program Control
windows-based Program control The DSP Configurator Control Program is compatible with Windows XP, Windows Vista, and Windows 7, and provides remote control of the input gain/attenuation, output volume output adjustment, and other features. DSP Configurator can control the DMP 128 by any of the three control ports, RS-232, USB, or LAN.
Page 20 Scroll to the DSP Configurator program and click Install to its right. Figure 10. DvD Control Software menu Follow the on-screen instructions. By default, the installation creates a folder for the DSP Configurator C:\Program Files\Extron\DSP_Configurator program. When the DSP Configurator installation is complete, the USB Installer starts automatically (see figure 11, next page).
Page 21: Installing The Usb Driver
installing the usB Driver When the USB installer begins: When the driver installation dialog opens, click Next to proceed (a status window tracks the installation). Figure 11. USB Installer Splash Screen The USB driver installer launches. When the installer completes the installation of the USB drivers, the following dialog opens: Figure 12.
Page 22: Dsp Configurator Program Basics
Extron recommends connection via the Ethernet LAN port for running the DSP Configurator program. To run the DSP Configurator Program, click Start > Programs > Extron Electronics > DSP Configurator > DSP Configurator. DSP Configurator starts in Emulate mode (see figure 13, next page). Also see...
Page 23 Figure 13. DmP 128 Navigation Aids minimize buttons — Click to toggle the view of a selected section from minimum to maximum. For example, the Inputs section is maximized with all processor blocks and the mix-points shown. Clicking the button in this example shrinks the view to its minimum screen area allowing items below to fill the screen.
Page 24 Figure 14. DmP 128 DSP Configurator main Screen The DSP Configurator program screen consists of an input and virtual return signal processor chain, the mix-points, and an output signal processing chain. The main mixer is separated into segments as shown in figure 14. notE: The expansion bus input mix-points are not shown in this view.
Page 25 Cut, Copy, or Paste Functions The user can cut, copy, or paste a processor. These actions can be performed from a context menu accessed by a right-click on the processor block, using the Edit menu, or using the standard Windows keystrokes: <Ctrl+X> = cut; <Ctrl+C> = copy; <Ctrl+V> = paste.
Page 26: Navigation
Click Yes. The entire Mic #4 input path is now identical to the Mic #1 input path including signal levels, parameters settings, and mute/bypass selections. Any single processor block is copied, then pasted to a similar processor block in the same or different input, virtual or output signal path.
Page 27: Dsp Configurator Toolbar Menus
DsP configurator toolbar Menus The DSP Configurator contains the following menu bar, arranged horizontally below the title bar: • File • Edit • View • Tools • Window • Help File notE: New, Open, and Recent Files are unavailable in Live mode.
Page 28 View • Meter Bridge — Opens a Meters dialog box with real-time meters that monitor signal levels at each input and output. Figure 15. meter Bridge notE: Meter Bridge is available in Live mode only while connected using the LAN port. •...
Page 29 tools The Tools menu contains the following items and sub-menu: • Presets — Provides three options: Mark All Items — Mark (select) all parts of the • current configuration (excluding presets), including processors and mix-points to save as a partial preset. Save Preset —...
Page 30 • Configure Groups — Opens the configure groups dialog box (see Group masters on page 82). • Device Settings (live mode only) — Opens a dialog box to change the IP address, set administrator and user passwords, change the device name, change the date and time, and to select the serial port baud rate.
Page 31: Window Menu
Processor Defaults, Reset All Defaults — • Returns the DMP 128 processor and level control blocks to factory default settings. Each processor, and gain/volume/ trim block also has an individual default reset. Processor Defaults, Defaults — Individually selects • the default parameters for the various processor, trim, and gain blocks.
Page 32: Presets Drop-Down
Presets Drop-down This drop-down list displays up to 32 presets. Select a preset to display and either activate (Recall), abort the selection without either recalling or deleting (Cancel), or delete it (Delete). notE: An asterisk in the drop-down list indicates a preset exists only in the DMP 128 and has not been downloaded to DSP Configurator.
Page 33: Audio Level, Mix-Point, Processing Blocks, And Signal Chains
Figure 16. Control Blocks and Processor Chains audio Level, Mix-point, Processing Blocks, and signal chains As outlined in red above (see figure 16), all control blocks on the main DSP control screen have one of three main functions in the overall signal chain: •...
Page 34: Level Control Blocks
Level control Blocks To access a gain, trim or volume control to view a setting, make a change, or observe a live audio meter (input gain and output volume blocks only), double-click the gain block icon (see figure 18). This action opens a dialog box that contains the fader for that control. Double-click a gain, trim, or volume control.
Page 35 Once a processor is inserted, to view associated parameters that define the selected processor (such as a frequency curve) or to remove the bypass, double-click the processor block. This action opens a new dialog box with parameters for the process (see figure 20).
Page 36: Mic/Line Input Signal Chain Controls
Mic/Line input signal chain controls The input signal processor chain allows adjustments to program or microphone audio material before input to the main mixer. gain control (gain) The gain control provides a single long-throw fader with a range of – 18 dB to +80 dB, adjustable in 1 dB increments with the fader or in 0.1 dB increments using direct entry in the level setting readout below the fader.
Page 37 • Low pass filter — A low pass filter passes a band of frequencies extending from a specified cutoff frequency (less than infinite) towards the lower end of the frequency spectrum. All frequencies below the specified frequency are allowed to pass, while all frequencies above are attenuated.
Page 38 Figure 23. Filter Dialog Box, Filters Added Within the dialog box, a filter is focused when a filter type is inserted, or is focused by clicking the filter number to the left of the filter selection drop-down list. Note the box number in row 3 in figure 23 is highlighted in yellow, indicating it is the filter in focus.
Page 39 Figure 24. Filter Dialog Box, Filter Not Bypassed Above the graph, each filter has a "handle" (circled in red above) placed directly above the cutoff or center frequency whose number corresponds to the filter number (outlined in red). Click a handle or click the table row to bring focus to that filter. Click+hold+drag the handle horizontally to change the cutoff or center frequency.
Page 40 high Pass The high pass filter allows all frequencies above the specified cutoff frequency to pass unattenuated. All frequencies below the cutoff are attenuated. The default cutoff is 100 Hz. Figure 25. High Pass Filter Response Curve In figure 25, all frequencies lower than the specified frequency, 100 Hz, are attenuated leaving the upper frequency response flat.
Page 41 Low Pass The low pass filter is the opposite of the high pass filter. All frequencies above the specified frequency are attenuated allowing lower frequencies to pass. The default cutoff is 10 kHz. Figure 26. Low Pass Filter Response Curve Here, the frequencies higher than the specified frequency, 10 kHz, are attenuated leaving the lower frequency response flat.
Page 42 Bass and treble shelving Bass and treble shelving can be added to the filter. Known as shelving or tone controls, the separate bass and treble filters provide the ability to cut or boost gain linearly above or below a selected frequency, with the end-band shape giving the visual appearance of a shelf.
Page 43 Parametric (Equalizer) The parametric filter is a frequency equalizer that offers control of all parameters, including amplitude (the amount of gain [boost], or gain reduction [cut] applied), center frequency (frequency), and range of affected frequencies (Q) around the center frequency. Q is the center frequency divided by the bandwidth.
Page 44 By increasing the Q to 10.000, the center frequency remains the same. The markers show the bandwidth of the filter narrowed to between 900 Hz and 1200 Hz, or about 300 Hz (see figure 29). Using the Q value, parametric filters can be used to notch out a very narrow, or very wide range of frequencies.
Page 45 The overall frequency response is now shown as a solid red line with the filter in focus located in row 3 (see figure 30 below) shown in the color of its table row. Figure 30. All Parametric Filters Active The parametric filter allows frequency selection accurate to 0.1 Hz and either 6 or 12 dB of slope.
Page 46: Acoustic Echo Cancellation (Aec)
acoustic Echo cancellation (aEc) The DMP 128 C models provide one acoustic echo canceller processor for each of the first eight mic/line inputs. A single reference can be selected for each AEC from a list of the twelve line inputs. about aEc Echo occurs when audio from a talker in the far end is received and amplified into the near end listener’s room, with that sound then being picked up by microphones in the near end acoustic space and sent back to the far end.
Page 47: Activity Leds
When using an output channel as a reference, the reference point is post volume control; therefore, changes to the listening volume in the room affects the AEC gain structure (see Dialog, below). If you have an output channel on the DMP 128 that is not being used, you can isolate the reference channel from the channel being used for volume control by routing reference signals to the unused output channel.
Page 48 Meters • ERL – the ratio in dB between the signal at the reference and the signal at the AEC channel input. When ERL is a positive number, the signal level at the AEC channel input is lower than the signal at the selected reference (0 to +15 dB is desirable). •...
Page 49: Advanced Aec Controls
advanced aEc controls Click on the open/collapse icon at the bottom of the AEC dialog to reveal the advanced AEC controls. Advanced control functionality is as follows: non-linear Processing (nLP) controls • Enable NLP — this box is selected by default. NLP is necessary for the removal of echo.
Page 50: Dynamics (Dyn)
Dynamics (DYn) A dynamics processor alters the dynamic range, the difference between the loudest to the quietest portions, of an audio signal. Each input channel provides two dynamics processor blocks that, when inserted, provide one of four types; AGC, Compressor, Limiter, or a Noise Gate processor.
Page 51 agc (automatic gain control) AGC adjusts the gain level of a signal based on the input strength to achieve a more consistent volume. Below the set threshold, the signal is not affected. Above the threshold, weaker signals are boosted up to the maximum gain setting to reach a user-defined target level.
Page 52 compressor The compressor regulates signal level by reducing, or compressing, the dynamic range of the input signal above a specified threshold. The input level to output level ratio determines the reduction in the dynamic range beyond the threshold setting. For example, with a ratio setting of 2:1, for every 2 dB of input above the threshold, the compressor outputs 1 dB.
Page 53 Limiter The limiter restricts the input signal level by compressing its dynamic range above a specified threshold. The limiter is most commonly used to prevent clipping, protecting a system against component or speaker damage. While the limiter is closely related to the compressor, it applies a much higher compression ratio of ∞:1 above the threshold.
Page 54 noise gate The noise gate allows an input signal to pass only when it exceeds a specified threshold level. Above the threshold level, the signal passes unprocessed; below the threshold the signal is attenuated at the rate set by the ratio adjustment. The typical setting of the noise gate threshold is just above the noise level of the environment or source equipment.
Page 55: Delay (Dly)
Delay (DLY) The delay processor block, when inserted, provides a means to delay the audio signal. Audio delay syncs audio to video or can time-align speakers that are placed at different distances from the listener. The DMP 128 can set delay by either of two criteria: time or distance (feet or meters).
Page 56: Ducking
Ducking Ducking provides a means to duck, or lower, the level of one or more input signals when a specified source must take precedence. The ducking processor block, when inserted, provides a means to duck one or more mics and program material (ducking targets) when the processor detects a signal from the ducking source.
Page 57 Ducking configuration Ducking is configured in a dialog box that opens when an active ducking processor block is double-clicked. Current Source Shows the input selected as the ducking source. Ducker settings affect the input channel shown here. When a ducker dialog is opened, the current source defaults to that channel.
Page 58 Priority In some cases, multiple levels of ducking can be required to enable an input source to take precedence over all but one other input. In this example, Inputs 2 through 6 are set to duck when Input #1 has a signal above the ducking threshold.
Page 59: Ducker Tutorials
Ducker tutorials The examples below are based on different input configurations. Insert a ducker from a ducker processor block using one of the following methods: Double-click the block, Right-click the box to open context -or- then click Ducker menu, then click Insert Ducker Once inserted, double-click on the ducker block to open the ducker configuration dialog box.
Page 60: Automix (Am)
automix (aM) An automixer manages multiple microphone sources, gating or varying input gain automatically. When properly set, the automixer system will improve use and performance when multiple mics are in use. The two basic types of automixer include gated and gain-sharing.
Page 61 • Off Reduction — The channel attenuation when a mic channel gates off. Range is 0.0 dB to 100.0 dB attenuation (0 to – 100 dB). Default: 60.0 dB. • Attack Time — Sets the time at which gain is applied after a channel gates on. Range is 0.0 msec to 3000.0 msec in 0.1 msec increments.
Page 62 automix groups Assigning individual automix channels to groups allows you to see and adjust all channels assigned to the group on one page. The automix group dialog provides details of all grouped and ungrouped inputs including the automix settings of each channel or mic. This provides an overview of all channels in the selected group at a glance.
Page 63: Pre-Mixer Gain (Gain)
configuring an automix channel Before configuring automix, Extron recommends that you set proper gain staging for the input mics. This ensures that adequate signal is provided for automix to work properly. An automix block is inserted for each microphone, and the mic assigned to a group (see figure 33, Automix Groups Dialog on the previous page).
Page 64: Telephone Rx (Dmp 128 C P And Dmp 128 C P At Only)
telephone rx (DMP 128 c P and DMP 128 c P at only) Figure 36. Telephone Rx Signal Path The DMP 128 provides a telephone interface with separate input and output signal processing paths. The telephone input (Rx) is identical to the other input processing paths except the AEC block is not used. See Telephone Interface on page 126 for additional information.
Page 65 When bypassed, the graph displays the current filter curve as a dotted line. When bypass is disengaged, the current filter curve is displayed as a solid line. Figure 34. Loudness Dialog Dialog box The Loudness dialog box contains the following elements: Graph —...
Page 66 Unmute the mix-point from the pink noise source to the output connected to the room amplifier being calibrated. With the basic gain structure previously set up, loudness can be calibrated using an SPL meter or by ear. (Loudness can also be set using an SPL meter, then fine-tuned by ear.) To calibrate loudness, use a sound pressure level meter set to “C”...
Page 67: Delay Block (Dly)
Delay Block (DLY) The delay processor block, when inserted, provides a means to delay the audio signal to compensate for loudspeaker placement in situations where speakers delivering the same signal are much farther away than others. The delay processor block is identical to the delay processor available on the input (see Delay (DLY) on page 49).
Page 68: Volume Control (Vol)
Volume control (VoL) Each output channel volume block provides a mono long-throw fader and a volume setting readout (in dB) below the fader. Volume level is adjustable with the slider or by entering the desired level directly into the volume setting readout in 0.1 dB increments. Clicking the fader handle or clicking within the fader area brings focus to the fader.
Page 69: Virtual Bus Returns
Virtual Bus returns There are eight mono virtual bus return inputs, fed by the virtual sends. Channel controls and processing blocks described in the sub-sections that follow are identical for each virtual bus return channel. The eight returns are divided into two similar paths. Channels A through D contain a feedback suppression processing block in each channel.
Page 70 the FBs dialog box provides the following global buttons: • Clear All — Clears all dynamic filter settings. • Lock — Locks the dynamic filters to current settings, preventing automatic updates. This temporary mode is useful while testing the system, or during the time when dynamic filters are being converted to fixed filters.
Page 71 FBs settings tab The Settings tab enables selection of the feedback suppressor parameters. • For Composite view show: — The graph view is set by one of three radio buttons: Only Dynamic FBS Filters • Only Fixed FBS Filters • Dynamic &...
Page 72 FBs Dynamic Filters tab This dialog contains the fifteen dynamic filters, with a scroll bar to display filters hidden due to the dialog box size. Dynamic filters are cut only notch filters, providing attenuation up to 30 dB at the specified Q.
Page 73 FBs Fixed Filters tab Fixed filters are notch filters with an adjustable center frequency and Q, and up to 30 dB of cut. The fixed filters are typically set by converting dynamic filters to fixed, however adjustments to filter parameters can be manually made from the Fixed Filters tab. Fixed Filters are inactive and the filter type is set to Unused by default (see rows 4 and 5 in figure 40).
Page 74: Virtual Bus Returns, E-H
Filter (FiLt) Filter function and interface is identical to the mic/line input channel Filter block except that only three filters are provided (see Filter (FILT) on page 30). Dynamics (DYn) There is one dynamics processor block available on each virtual path. Dynamics function and interface is identical to the mic/line input channel Dynamics block, (see Dynamics (DYN)
Page 75: Output Mix Matrix
output Mix Matrix The DSP architecture contains an output mix matrix that connects all inputs to the line outputs, a virtual send mix matrix that connects all inputs to the virtual outputs, and an expansion (EXP) output mix matrix that connects the mic/line inputs and virtual bus returns to the expansion outputs (see figure 41 on the next page).
Page 76 Output Virtual Send Expansion Output Mix Matrix Mix Matrix Mix Matrix Outputs Inputs Virtual Send Bus Expansion Outputs Virtual Returns Expansion Outputs Expansion Inputs 1 - 8 9 - 16 Figure 41. Overview of DSP 128 mix-matrix DMP 128 • Software Control...
Page 77: Mix-Point Behavior
Mix-point Behavior: mix-point color — There are three colors of mix-points: Teal indicates standard processing (default). Orange indicates that the signal chain includes an auto-mix processor. Green indicates that all signal processing has been bypassed, post input gain control. No mix information — A faint transparent circle (teal, green, or orange) on the mix-point indicates that it is muted (contains no mix information).
Page 78 Click a mix-point to bring focus to that mix-point. A circle appears around the teal mix-point, which remains transparent. Double-click a mix-point to open a configuration dialog box with the following components: • mono Fader — Sets the signal level from the Mix-point selected input to the output bus.
Page 79: Mix-Point Examples
Mix-point Examples In order to better understand how mix-points work, the following diagrams provide examples of mixes. notE: To simplify the diagrams not all input and output lines are shown. Figure 42. Input 1 to Output 1 In the first example (see figure 42) input audio from Input 1 is processed and arrives at the output 1 matrix mix-point.
Page 80 Figure 43. All Inputs to Output 1 In the next example (see figure 43), input audio from all twelve mic/line inputs are processed individually and arrive at their output 1 mix-points. As each mix-point mute button is released, its output 1 mix-point junction turns teal, and the signals are all routed to Output 1.
Page 81 Figure 44. Input 1 to All Outputs In the example in figure 44, input 1 has been routed to all eight outputs by unmuting the mix-point for Input 1 for each output (1 through 8) bus. The example also shows the mix-point for output four with input processing bypassed (green) and the mix-point for output eight with active automix.
Page 82: Virtual Send Bus Mix Matrix
Virtual send Bus Mix Matrix The DSP architecture contains a Virtual Send Bus mix matrix that connects the inputs and virtual bus return signals to the virtual sends. There is an additional mix matrix to route EXP input signals to the virtual sends. The DSP Configurator main screen provides control of the virtual bus mix matrix, used to set levels from input signals to the virtual sends.
Page 83 In the example in figure 46 below, input 1 is sent to the virtual send bus by muting all eight signals on the Input 1 output mix-points and unmuting virtual send bus output 1. The virtual bus now serves as additional signal processing for the input. The signal routes from virtual send A through the virtual bus A signal chain before it is sent to the virtual bus return mix-point and finally to output 1.
Page 84: Expansion Outputs Mix Matrix
Expansion outputs Mix Matrix The DSP architecture contains a third mix matrix that supports connection and control of a second DMP 128 using the included shielded CAT 6 cable. The output connects the mic/line inputs and virtual returns to the Expansion Outputs. The DSP Configurator main screen provides all necessary control of the mix matrix.
Page 85: Extron Exp Bus
This has no bearing on how audio is transported from unit to unit, making it unimportant which unit is set to primary. notE: You can connect a DMP 128 AT to a non-AT unit by the EXP ports, however be aware that the AT unit defaults to the primary unit and cannot be changed.
Page 86: Using The Expansion Bus
Connect the EXP port of one unit to the EXP port of a second unit MIC/LINE INPUTS DIGITAL I/O DMP 128 C AT 100-240 ~ 0.6A using the included shielded (or similar) CAT 6 cable. 1 2 3 4 6 7 8 9 10...
Page 87: Device Manager
The mic/line inputs and the virtual bus returns make up the expansion bus mix matrix that feed EXP outputs 1 through 8 (see figure 49, Ä ) of the primary unit. They are connected to EXP inputs 1 through 8 of the secondary unit (see figure 49, Å...
Page 88: Group Masters
group Masters There are 32 Group Masters that can each be configured to simultaneously control up to 16 group members. Group masters are configured in DSP Configurator and saved in the device. Working in emulate mode, group masters are saved in a configuration file and pushed to the device upon connection.
Page 89 Figure 51. Sample Gain Group master and Associated Gain Controls Mute controls within the blocks can also be grouped (see figure 52). Figure 52. Sample mute Group master and muted Outputs DMP 128 • Software Control...
Page 90: Configuring A Group Master
configuring a group Master To configure a group: Click Tools > Configure Groups (see figure 52 on the previous page) to open the Configure Groups dialog. or click View > Group Controls > Add a Group. Click the Select Group drop-down list (see figure 53). The list defaults to the first empty group.
Page 91: Deleting A Group Master
Deleting a group Master To delete a group: Click Tools > Configure Groups (see figure 54) to open the configure groups dialog box or click View > Group Controls and then click Add a Group. In the Select Group drop-down list, click a numbered group (such as Group #1) to select it.
Page 92: Tools
tools The Tools menu (see right) contains these selections: • Clear All Groups — clears all group members and group master parameters. Soft limits are also cleared. • Increment/Decrement Simulator — allows the user to test increment/decrement values (see below for more information) •...
Page 93: Soft Limits
group Details report Select Tools > Group Details Report to create a text file that details all created groups (see figure 56). GROUP DETAILS REPORT Group #1 Processor Type: Output Volume Current Mute status: Unmuted Current Group Members: Main Amp (Output#1) Left Channel Stage Mixer (Output#2) Right Channel House Video (Output#3) Left Channel Prgm Record (Output#4) Right Channel...
Page 94: Digital I/O Ports
When selected, the script is compiled and placed onto the File Management system of the device. For more advanced or custom scripts, contact an Extron Electronics Applications Engineer.
Page 95: Reinitialize Digital I/O
reinitialize Digital i/o Should the script stop running for any reason, select Tools > Configure DigitalI/O > Reinitialize Digital I/O. This option is only available in live mode. To remove a digital I/O script from the DmP 128: Only one digital I/O configuration can be active at a time. If the I/O activity requires modification, remove the current configuration by: From the main menu, select Tools>Configure Digital I/O >...
Page 96: Selecting Live Mode And Pushing Or Pulling Data
selecting Live Mode and Pushing or Pulling Data To switch from Emulate to Live mode: Select the desired connection to the DMP 128 and make the proper connections. notE: Extron recommends connection via the Ethernet LAN port when using DSP Configurator. Click Live (see figure 57, b ). The communication type selection dialog opens. Extron USB device Figure 57.
Page 97 If RS-232 is selected in step 3: Click the Com Port drop-down list and select the port connected to the rear panel RS-232 port. Check the baud rate displayed in the port selection dialog box. If the baud rate does not match the device rate, click the Baud Rate drop-down list and select the desired baud rate.
Page 98 Click either: Pull to configure DSP Configurator to match the device — proceed to step 9 -or- -or- Push to configure the device to match DSP Configurator — proceed to step 8 To push all of the gain and processor block adjustments (configuration), and all presets to the DMP 128, proceed to step 9.
Page 99: Presets
Presets Presets recall a group of frequently used settings. Presets created by DSP Configurator can contain all elements (gain blocks, processor blocks, and mix-points) or a portion of the elements available within the program. In Emulate mode, up to 32 partial presets can be created, then uploaded as a set and stored to the device or stored to disk as a configuration file.
Page 100: Building A Preset
Building a Preset Only elements of the preset highlighted (given focus) are saved as a preset. <Ctrl + A> highlights all elements within DSP Configurator. To build a preset, highlight the desired DSP Configurator elements (gain/processor blocks, mix-points) using standard Windows keyboard and mouse actions as follows: Click on the desired block to select a single block, <Ctrl + click>...
Page 101: Managing Presets
Select a preset number. In the dialog box, unused presets are named Preset Name unassigned. To create a new preset, select an unused preset number and type a preset name. If no name is entered, a default name is assigned. To overwrite an existing preset, select a preset with a name other than unassigned.
Page 102: Presets: Pull, Push, Or Create Live
Presets: Pull, Push, or create Live When a preset is pulled from the device, the preset data remains in the device until the preset is recalled. DSP Configurator pulls the names of the presets only. These presets cannot be saved to disk until recalled. An asterisk next to the preset name indicates that only the preset name has been pulled from the device, and the preset data exists only in the device (it has not been recalled).
Page 103: Dsp Configurator Windows Menus
DsP configurator windows Menus Keyboard navigation DSP Configurator is fully navigable using the computer keyboard. Some keyboard navigation behavior matches Windows standards, while other behaviors are specific to DSP Configurator. <Tab> jumps to the various sections outlined in red in figure 61, below. When the program starts, the cursor defaults to the Emulate button ( a ).
Page 104 notE: The first selection in any area is always the minimize/maximize button. If the area is hidden, the next <Tab> moves the highlight to the minimize/maximize button of the next section. If the area is maximized, the next <Tab> moves to the signal processing chain or mix-points (depending on the section) before leaving the area for the next section in order.
Page 105 To move away from the highlighted block or set of sequential blocks, or to highlight non-sequential blocks: After highlighting blocks in step 2, press and hold <Ctrl>, then use the navigation , and ) keys to move to the next desired element. As long as <Ctrl> is held down, the block moved away from is not highlighted.
Page 106: Optimizing Audio Levels
optimizing audio Levels The DMP 128 uses floating point DSP technology, processing data using a combination of 32- and 128-bit algorithms. The analog to digital converters (ADC) and digital to analog converters (DAC) sample at 48kHz, with 24-bit resolution. With floating point DSP it is extremely difficult to clip the audio signal within the DSP audio signal chain, after the ADC input and before the DAC output.
Page 107: About Setting Gain Structure
The remainder of this section references the gain, trim and volume controls outlined in figure 63. Figure 63. Gain, Trim and volume Controls Mic/Line input gain Mix-point gain Output volume Pre-mixer gain Post-mixer trim about setting gain structure There are two approaches the system designer can take in setting up gain structure depending upon where output volume is controlled.
Page 108: Setting Input Gain
setting input gain Floating point DSP technology is internally more flexible than fixed point. However, the input ADCs and output DACs always run as fixed point, so it is important to optimize the audio by setting the input level as close to 0 dBFS as possible. This maintains the resolution at 24-bit.
Page 109: Adjusting Trim
adjusting Pre-mixer gain After setting input gain, add desired processors into the input signal chain. The pre-mixer gain control (see figure 63, b on page 101) is used to compensate for level changes due to processing. Adding a compressor generally reduces the signal level, while a filter can boost or cut the overall signal level.
Page 110: Setting Mic/Line Input And Mix Levels
setting Mic/Line input and Mix Levels In this example, the mic/line input 1 signal is sent to output 1. To set the mic/line input and mix levels: Connect a microphone to Input #1. Double-click the mix-point (see figure 63, c on page 101) for mic/line input 1 to output 1 to open the dialog box for that mix-point, and unmute the mix-point to place that signal into the mix.
Page 111: Signal Path Building Blocks
signal Path Building Blocks The discrete signal paths (mic/line input, virtual return input, and line output) can be individually loaded with pre-configured, modular templates called building blocks. These blocks are designed for specific microphones, source devices or speaker destinations and can greatly streamline initial configuration. The blocks are configurable and are more versatile than a global template.
Page 112 Figure 65. Building Blocks Dialog Box The following steps select a lavalier microphone configuration for input #1. Click the Input 1 box. dialog box (see figure 65) opens. Building Blocks Select Lavalier by placing the mouse over the text Lavalier. The selected text changes color and is underlined.
Page 113: Adding A Building Block
adding a Building Block Custom building blocks are created using a signal path configured for a specific device. For example, when a new mic is connected to Input #3, the signal path might be tailored specifically for that mic. In this example a gain setting is applied and a noise gate inserted. They are then stored as a custom building block.
Page 114 The new mic configuration is now a building block used to quickly configure new devices. A new configuration can also overwrite existing templates. to overwrite an Existing configuration: Click in the input number box. In the dialog box that opens, select the Add Block icon in the upper left. In the dialog box, type an existing name for the new device.
Page 115: Organize Building Blocks
A dialog box prompts to warn an existing configuration will be overwritten. Click Yes. The new mic configuration overwrites the existing template and is ready to use. organize Building Blocks The Tools menu contains a utility that allow building blocks organization and rearrangment to suit an application.
Page 116: Building Blocks
Delete a Building Block Delete a building block to remove it from the list. If you delete a default building block, you can restore it if needed (see Restore Default Building Blocks below). To delete a building block: From the main menu, select Tools>Organize Building Blocks.
Page 117 To import a building blocks file: From the menu, select Tools>Organize Building Blocks. The Organize Building dialog box opens. Blocks Click the Import Building Blocks File icon. The “Import from...” dialog box opens. Browse to and select the desired building blocks file.
Page 118: Dante Installation And Operation (At Models Only)
Dante installation and operation (at Models only) This section describes the DMP 128 AT network installation, configuration, and control using Dante Controller for Windows and includes: • DmP 128 AT Bus • Dante Controller Software Installation • Creating a Physical Dante Network • Dante Controller Configuration Selecting Inputs and Outputs for Dante •...
Page 119: Dante Controller Software Installation
Dante controller software installation The DMP 128P AT uses Dante Controller for Windows from Audinate to select and route inputs and outputs for all connected DMP 128 ATs and other Dante-compatible audio devices. Download and install the latest version of Dante Controller for Windows from the included software DVD or from the Dante Controller product page at www.extron.com Dante network audio setup...
Page 120 In the Unit Name: field, enter a descriptive name for the DMP 128 (typically the device name and location) to enable easy identification on the network (see figure 68). DMP128-ConfRoom1 Unit name can be up to 24 characters drawn from the alphabet (A-Z), digits (0-9), and minus sign/hyphen (-).
Page 121: Dante Device Discovery
Dante Device Discovery The Tools menu also provides a way to locate other Dante devices on your network. Once the device is named (see Dante Network Audio Setup on page 113), it can easily be identified as a Dante host from any other Dante device. To locate Dante devices on an audio network: Select Tools>Device Settings.
Page 122: Creating A Physical Dante Network
Alternatively, a larger network switch can be used in place of the central DMP 128 AT, allowing more than three units to be connected in the star configuration (see figure 69). DMP 128 AT #2 RS-232 RESET...
Page 123: Redundant Configuration
redundant configuration Redundant network configurations can be employed, however, you must observe the proper order of rear panel AT port connections. In redundant mode the 4-port switch acts as two separate 2-port switches that duplicate audio traffic (see figure 71). The two sets of switches (primary and secondary) cannot be connected together anywhere in the system.
Page 124: Dante Controller Configuration
Dante controller configuration Now that the DMP 128 ATs are configured for network operation and the Dante software is installed, Dante Controller must be configured. start Dante controller To launch Dante Controller. From the DSP Configurator menu bar, select Tools>Network Audio Control. Figure 72.
Page 125 When the network scan is compete, Dante Controller opens in Network View. Dante Transmitters Dante Receivers Connection Points Figure 73. Dante Network view Receivers, representing Dante device inputs, are on the left side running vertically. Transmitters, representing Dante device outputs, are along the top running horizontally. The connection points form a large matrix in the center of the screen.
Page 126: Rename A Dante Device
rename a Dante Device Figure 74. Dante Controller - Rename Device To rename a connected device: From the toolbar, select Device > Device View or use <Ctrl+D>. From the dialog box, select Device Config. Device View From the pulldown list, select the device to rename. In the Rename Device field, type the new name for the device following the naming conventions note on the previous page.
Page 127: Rename An Input Or Output
rename an input or output To simplify setup and operation of large matrix systems, rename the input (receiver) and output (transmitter) lines to a label indicating the input a source device is connected to or the output a receiver is connected to. Figure 75.
Page 128: Selecting Inputs And Outputs For Dante
selecting inputs and outputs for Dante Dante Controller is used for all network level signal routing, however DSP Configurator assigns the input and output channels to the AT bus. The line outputs, expansion outputs, and virtual returns are available on the AT bus outputs. DMP 128P at Bus outputs Outputs DMP Outputs 1-8...
Page 129: Dmp 128P At Expansion Bus (At Inputs)
The DMP 128 output lines are always the first eight transmitter lines (Outputs 01 through 08 in figure 77, d ). The eight expansion outputs (see figure 76, b on the previous page) appear in the Dante transmitter list (item d , below), as EXP_Out-01 to EXP_Out-08).
Page 130: Signal Routing With Dante
signal routing with Dante Channels either transmitted to the network, or received from the network are routed using the main Dante network view (see figure 79). Figure 79. Dante Routing view There are several icons used to communicate the status of both the transmitter and receiver channels and the connections made.
Page 131: Using The Extron Expansion Bus With Dmp 128 At Devices
Expansion port connectivity using a DMP 128 at: Power on both units. Open DSP Configurator and connect Live to the non-AT model DMP 128. From the menu, select Tools > Expansion Bus > Secondary MIC/LINE INPUTS DMP 128 C AT DIGITAL I/O 100-240 ~ 0.6A Unit. 1 2 3 4 6 7 8 9 10 Connect the DMP 128P AT EXP port to the non-AT model DMP 128...
Page 132: Telephone Interface
telephone interface This section describes the telephone interface and control, including: • Telephone Configuration Telephone Dialer • • Third Party Control of the Phone Dialer The DMP 128 provides a telephone interface with separate input and output signal processing paths. The telephone input (Rx) is identical to the other input processing paths except the AEC block is not available (see Telephone Rx (DmP 128 C P and DmP 128 C P AT only)
Page 133: Telephone Dialer
telephone Dialer A telephone dialer is provided to aid setup and troubleshooting. to use the telephone dialer: From the main DSP Configurator screen toolbar, select Tools>Phone Dialer (see figure 80). The phone dialer dialog box opens (see figure 81, below). The phone dialer uses the connected telephone lines and provides the same features as a normal dialing interface to assist the installer with setup and...
Page 134: Third Party Control Of The Phone Dialer
third Party control of the Phone Dialer See the SIS section for commands to control and query the phone dialer (see Telephone commands on page 146). When sending a dial command or off hook command using SIS commands, you must first initialize the phone. To prevent excessive levels from the dial tone, or on hook and off hook sounds, fine control of the phone receive audio is recommended during dialing.
Page 135: Sis Programming And Control
DmP Software on page 12 and for the embedded Web pages, HTmL Operation on page 155. SIS commands can be executed using the Extron Electronics DataViewer program, found on the Software Products DVD included with the product. DmP 128 RS-232 protocol: • 38400 baud •...
Page 136: Port
rs-232 Port The DMP 128 has a serial port that can be connected to a host device such as a computer running the HyperTerminal utility, or the DataViewer utility. The port makes serial control of the switcher possible. Use the protocol information listed above to make the connection (see Host-to-device Communications on page 132).
Page 137: Verbose Mode
to Establish a network connection to the DMP 128: Open a TCP socket to port 23 using the mixer IP address. notE: If the local system administrators have not changed the value, the factory-specified default, 192.168.254.254, is the correct value for this field. The DMP 128 responds with a copyright message including the date, the name of the product, firmware version, part number, and the current date/time.
Page 138: Host-To-Device Communications
Copyright connection via Internet protocol (IP) is established. © Copyright 2013, Extron Electronics, DMP 128 {string}, Vn.nn, 60-nnnn-nn Day, DD MMM YYYY HH:MM:SS • is the firmware version number.
Page 139: Symbol Definitions
When programming, certain characters are more conveniently represented by their hexadecimal rather than ASCII values. The table below shows the hexadecimal equivalent of each ASCII character: ASCII to HEX Conversion Table Space • Figure 83. ASCII to Hex Conversion Table The Command and Response tables list valid ASCII (for Telnet or RS-232) command codes, the corresponding URL (uniform resource locator) encoded (for Web browsers) command codes, the DMP 128 responses to the host, and a description of the command...
Page 140: Simple Control Port Commands - Telnet And Web-Browser Accessible
simple control Port commands - telnet and web-browser accessible Upper and lower case text can be used interchangeably except where noted. Port 23 is default for Telnet. Port 80 is default for web browsers. They both can be mapped to different ports.
Page 141: Command And Response Tables
Query part number DMP 128: 60-1211-01 DMP 128 AT: 60-1211-10 DMP 128 C: 60-1178-01 DMP 128 C AT: 60-1178-10 DMP 128 C P: 60-1179-01 DMP 128 C P AT: 60-1179- Query model name V00x00•A12x08 ] Query model name DMP •128• DMP •128•AT DMP •128•C...
Page 142 command and response table for Basic sis commands (continued) command ascii command response additional description (host to device) (device to host) iP setup commands Set unit name EX1@ X1@] • X1@] View unit name Set name to factory default X4(] •...
Page 143 command and response table for Basic sis commands (continued) command ascii command response additional description (host to device) (device to host) Password and security settings E X3# X4!] Set administrator password • View administrator X4!] password Reset (clear) administrator • •...
Page 144 command and response table for Basic sis commands (continued) command ascii command response additional description (host to device) (device to host) serial Port X1& } X@ Send Data String response Configure parameters X2& X2& X2*] Cpn1 • X2& X2* ] View serial port parameters Configure rcv timeout X1&...
Page 145 command ascii command response additional description (host to device) (device to host) Event control EX3% X3& X5$] Read event buffer memory EX3% X3& X3( ] Write event buffer memory X3& notE: Response to Write Event is padded with leading zeros for EX3% X3&...
Page 146 command and response table for Basic sis commands (continued) command ascii command response additional description (host to device) (device to host) Presets, i/o names Write preset name EX1) X1!] Name preset 1 “Security 1”. Example: 1,Security 1NG Nmg01,Security 1 EX1) X1!] Read preset name Example:...
Page 147: Dsp Sis Commands
DsP sis commands Many digital signal processor (DSP) functions; gain, mute, group masters, and a protected configuration can be controlled using SIS commands. These commands follow the same general rules as basic SIS commands, but the variables ( X/ ) tend to be more complex. Also, an understanding of the audio signal flow is helpful to understanding the commands.
Page 148: Symbol Definitions
symbol Definitions Carriage return/line feed Carriage return (no line feed) • Space character Pipe (can be used interchangeably with the character) Asterisk character (which is a command character, not a variable) Escape key can be used interchangeably with the character Gain and trim control See table 1 on page 147.
Page 149 command and response table for DsP sis commands command ascii command response additional description (host to device) (device to host) audio level control, and mix-point selection notEs: The command format is the same, regardless of the control to be set; the acceptable adjustment range varies depending on the control or mix-point: •...
Page 150 command and response table for DsP sis commands (continued) command ascii command response additional description (host to device) (device to host) audio group master commands notEs: • See Group masters for more information about audio group masters. • A group must have assigned members for these commands to have an effect. •...
Page 151 command and response table for DsP sis commands (continued) command ascii command response additional description (host to device) (device to host) Protected configuration notE: The DMP 128 can save and recall a Personal Identification Number (PIN)-protected configuration, which includes all processing and levels in the current coinfiguration, with the exception of the IP address). The protected configuration is useful to establish the DMP 128 in a known state, either as a troubleshooting tool or as a baseline configuration.
Page 152 command ascii command response additional description (host to device) (device to host) Telephone commands notE: Prior to using the the modem, ensure the country code is set using DSP Configurator (see Telephone Configuration page 126). To receive proper responses, place the DMP 128 in verbose mode 3. Initialize phone Must be sent prior to dialing or AT+FCLASS=8,PHON...
Page 153 table 1: Level control Level Level input gain control Pre-mixer gain Mic/Line Input 1 40000 Mic/Line Input 1 40100 Mic/Line Input 2 40001 Mic/Line Input 2 40101 Mic/Line Input 3 Mic/Line Input 3 40002 40102 Mic/Line Input 4 40003 Mic/Line Input 4 40103 Mic/Line Input 5 40004...
Page 154: Setting Audio Levels
setting audio Levels The audio dB to SIS command conversion values in table 2 beginning on the next page, are the same for all signal level blocks. However, the minimum and maximum levels differ depending upon the individual level control. The following table can determine those minimum and maximum levels for the individual controls.
Page 155 DMP 128 • SIS Programming and Control...
Page 156 DMP 128 • SIS Programming and Control...
Page 157 DMP 128 • SIS Programming and Control...
Page 158 DMP 128 • SIS Programming and Control...
Page 159 DMP 128 • SIS Programming and Control...
Page 160 DMP 128 • SIS Programming and Control...
Page 161: Html Operation
htML operation This section describes HTML operation and control of the DMP 128, including: Download the Startup Page • • Status Tab • Configuration Tab • File management Tab • Special Characters The DMP 128 can be accessed by a PC or controller from a LAN or WAN using the Ethernet port and a web browser such as the Microsoft Internet Explorer.
Page 162 Press <Enter>. The device checks to see if it is password protected. If the device is not password protected, it checks and downloads the HTML pages (proceed to step 7). If the device is password protected, the device opens the dialog box Connect To (see figure 85).
Page 163: Status Tab
status tab system status Page page (see figure 86) provides an overall view of the status of the System Status device, including system information, power supply status, and serial port settings. The page is the default page when a connection to the device is established. System Status Access the page from other pages by clicking the Status tab.
Page 164: Unit Name Field
On password-protected connections, there are two levels of protection: administrator and user. Administrators have full access to the passwords and firmware upgrade pages. Users have view only access. • Ethernet connection to the device, either entering SIS commands (see SIS Programming and Control on page 129) or using the Extron DSP Configurator Program, (see DSP Configurator Program Basics...
Page 165: Mac Address Field
The Model field displays the Extron model number of the device. Part number Field The Part Number field displays the Extron Electronics part number of the device. Date/time settings Panel The Date/Time Settings fields (see figure 88) provide a location for viewing and setting the time functions.
Page 166: Passwords Page
Passwords Page Click the Passwords link to access the passwords page (see figure 89). Figure 89. Passwords Page The fields on the passwords page enter and verify administrator and user passwords. Passwords are case sensitive and limited to 12 upper case and lower case alphanumeric characters.
Page 167: Firmware Upgrade Page
Click Download to copy the firmware to your computer. Download NOTE: The version, release date, and size shown are example values only. Firmware DMP 128 Digital Matrix Processor 19-2247-50 V1.02 August 10, 2012 2.4 MB Firmware for DMP 128 DMP 128 FW1x02.exe Download DMP128_FW1x02.exe...
Page 168 To continue, click Next. Folder where firmware is The InstallShield Wizard has successfully installed the installed Firmware Update. The release notes can be found at C:\Program Files\Extron\Firmware\DMP 128\v1.01 Figure 91. Downloading Firmware Upgrade Files DMP 128 • HTML Operation...
Page 169 Click Next (see figure 91, g on the previous page). The program extracts and places the firmware files in a folder identified in the InstallShield Wizard dialog box. notE: The download folder can change depending on the operating system. Note the folder where the firmware file is saved. Click Finish (figure 91, ) to exit the program.
Page 170: File Management Tab
File Management tab File Management Page To delete files such as HTML pages from the connected device or to upload custom files to the device, click the File Management tab. The device downloads the file management HTML page (see figure 93). Figure 93.
Page 171: Reference Information
reference information This section contains reference information for the DMP 128, including: • mounting the DmP 128 Firmware Loader • • DmP 128 Hardware Reset modes • DSP SIS Commands for mix-point Level and mute Control • SIS Command mix-points Mounting the DMP 128 The 1U high, full rack width, 8.5 inch deep DMP 128 Digital Matrix Processor can be: •...
Page 172: Rack Mounting
rack Mounting The DMP 128 is delivered with rack mounting brackets attached. For rack mounting, do not install the rubber feet. Use the rack ears to mount the DMP 128 in a standard equipment rack. The DMP 128 can be mounted on a 19 inch Universal 1U or Basic rack shelf.
Page 173: Table Or Wall Mounting
table or wall Mounting The table or wall mounting brackets extend approximately 1/4 inch (6.4 mm) above the top surface of the enclosure. This design allows for an air space between the enclosure and the surface to which it is mounted. Table or wall mount the DmP 128 as follows: Remove the rack mounting brackets and attach the MBU 149 brackets in their place.
Page 174: Firmware Loader
Firmware Loader Extron provides a firmware loader utility that, when installed, allows the firmware of the DSP Configurator program to be updated or replaced. To install upgrade the DMP 128 firmware: • Download, then install the Firmware Loader utility from www.extron.com. • Download the desired firmware file from the Extron website, (see Firmware Upgrade Page...
Page 175: Dmp 128 Hardware Reset Modes
DMP 128 hardware reset Modes DmP 128 Reset mode Summary mode mode Activation Result Purpose/Notes Hold the reset button while applying The DMP 128 reverts to the factory This mode reverts to the power. default firmware. factory default firmware version if incompatibility Event scripting does not start if notE: After a mode 1 reset, update the issues arise with user- the DMP 128 is powered on in this...
Page 176: Dsp Sis Commands For Mix-Point Level And Mute Control
DsP sis commands for Mix-point Level and Mute control Many functions; gain, mute, group masters, mix-points, and a protected configuration can be controlled using SIS commands. These commands follow the same general rules as basic SIS commands, but the variables ( X/ ) tend to be more complex. Before attempting SIS control of the DSP, a comprehensive understanding of the audio signal flow is helpful to understanding the commands.
Page 177: Selecting Mix-Points
selecting Mix-points Mix-points are controlled by their address. Each mix-point in figure 94 has an individual address selected and controlled using SIS commands. (A mix-point contains a level control and a routing control that mutes or unmutes the signal path from the input mix-point to the output.) For example, to view the current status of the input 1 to output 1 mix-point (SIS address: ...
Page 178: Setting Audio Levels
setting audio Levels The mix-point level is controlled using SIS commands. The commands template follows a similar structure as mute and unmute commands. The audio conversion tables are the same for all mix-points (see table 2 beginning on page 149). Although a greater range is shown in the table, the minimum and maximum levels are the same for all mix-points (–35.0 to +25.0 dB).
Page 179: Sis Command And Response Table For Dsp Mix-Point And Level Control
sis command and response table for DsP Mix-point and Level control Setting the level of a mix-point requires the mix-point address and level value. Making a connection between a mix-point input and output requires the mix-point be unmuted. command ascii command response additional description...
Page 180: Sis Command Mix-Points
sis command Mix-points The mix-points are divided into three main matrix mixers: the Main or Output mix matrix ( a ), the virtual send bus mix matrix ( b ), and the expansion (EXP) outputs mix matrix ( c ). Output Virtual Send Expansion Output...
Page 181: Output Mixer
output Mixer The output mixer routes the mic/line inputs ( ), virtual returns ( ), and expansion bus inputs ( ), to the outputs. Outputs Output Mixer Inputs Virtual Send Bus Expansion Outputs Mic/Line Inputs to Output Mix-points Virtual Returns Expansion Outputs Virtual Returns to Output Mix-points...
Page 182 table 3: Mic/Line inputs to output Mix-points ( Mic/Line inputs to outputs Mic/Line inputs to outputs Mic/Line Input 1 to Output 1 20000 Mic/Line Input 2 to Output 1 20100 Mic/Line Input 1 to Output 2 20001 Mic/Line Input 2 to Output 2 20101 Mic/Line Input 1 to Output 3 20002...
Page 183 Mic/Line inputs to outputs Mic/Line inputs to outputs Mic/Line Input 11 to Output 1 21000 Mic/Line Input 12 to Output 1 21100 Mic/Line Input 11 to Output 2 21001 Mic/Line Input 12 to Output 2 21101 Mic/Line Input 11 to Output 3 21002 Mic/Line Input 12 to Output 3 21102...
Page 184 table 4: Virtual returns to output Mix-points ( Virtual returns to outputs Virtual returns to outputs Virtual Return A to Output 1 Virtual Return B to Output 1 21300 21400 Virtual Return A to Output 2 Virtual Return B to Output 2 21301 21401 Virtual Return A to Output 3...
Page 185 table 5: ExP inputs to output Mix-points ( ExP returns to outputs ExP returns to outputs EXP Input 1 to Output 1 EXP Input 2 to Output 1 22100 22200 EXP Input 1 to Output 2 EXP Input 2 to Output 2 22101 22201 EXP Input 1 to Output 3...
Page 186 ExP returns to outputs ExP returns to outputs EXP Input 11 to Output 1 23100 EXP Input 12 to Output 1 23200 EXP Input 11 to Output 2 EXP Input 12 to Output 2 23101 23201 EXP Input 11 to Output 3 EXP Input 12 to Output 3 23102 23202...
Page 187 ExP returns to outputs ExP returns to outputs EXP Input 21 to Output 1 24100 EXP Input 22 to Output 1 24200 EXP Input 21 to Output 2 24101 EXP Input 22 to Output 2 24201 EXP Input 21 to Output 3 24102 EXP Input 22 to Output 3 24202...
Page 188 ExP returns to outputs ExP returns to outputs EXP Input 31 to Output 1 25100 EXP Input 32 to Output 1 25200 EXP Input 31 to Output 2 25101 EXP Input 32 to Output 2 25201 EXP Input 31 to Output 3 25102 EXP Input 32 to Output 3 25202...
Page 189 ExP returns to outputs ExP returns to outputs EXP Input 41 to Output 1 26100 EXP Input 42 to Output 1 26200 EXP Input 41 to Output 2 26101 EXP Input 42 to Output 2 26201 EXP Input 41 to Output 3 26102 EXP Input 42 to Output 3 26202...
Page 190 ExP returns to outputs ExP returns to outputs EXP Input 51 to Output 1 27100 EXP Input 52 to Output 1 27200 EXP Input 51 to Output 2 27101 EXP Input 52 to Output 2 27201 EXP Input 51 to Output 3 27102 EXP Input 52 to Output 3 27202...
Page 191: Virtual Sends Bus Mix Matrix
Virtual sends Bus Mix Matrix The Virtual Sends bus mixer can be further broken down into the mic/line inputs ( virtual bus returns ( ), and EXP input mix-points ( Virtual Send Bus Mix Matrix Virtual Send Bus Mix-points (from Mic/Line Inputs) Virtual Send Bus Mix-points (from Virtual Bus Returns) EXP Inputs to Virtual Bus...
Page 192 table 6: Mic/Line inputs to Virtual sends Mix-points inputs to Virtual inputs to Virtual sends sends Input 1 to Virtual Send A 20009 Input 2 to Virtual Send A 20109 Input 1 to Virtual Send B Input 2 to Virtual Send B 20010 20110 Input 1 to Virtual Send C...
Page 193 inputs to Virtual inputs to Virtual sends sends Input 11 to Virtual Send A 21009 Input 12 to Virtual Send A 21109 Input 11 to Virtual Send B Input 12 to Virtual Send B 21010 21110 Input 11 to Virtual Send C Input 12 to Virtual Send C 21011 21111...
Page 194 table 7: Virtual returns to Virtual sends Virtual returns to Virtual returns to Virtual sends Virtual sends Virtual Return B to Virtual Send A 21409 Virtual Return A to Virtual Send B 21310 Virtual Return A to Virtual Send C 21311 Virtual Return B to Virtual Send C 21411...
Page 195 table 8: ExP Bus inputs to Virtual sends ExP inputs to Virtual sends ExP inputs to Virtual sends EXP Input 1 to Virtual Sends A 22109 EXP Input 2 to Virtual Sends A 22209 EXP Input 1 to Virtual Sends B 22110 EXP Input 2 to Virtual Sends B 22210...
Page 196 ExP inputs to Virtual sends ExP inputs to Virtual sends EXP Input 11 to Virtual Sends A 23109 EXP Input 12 to Virtual Sends A 23209 EXP Input 11 to Virtual Sends B 23110 EXP Input 12 to Virtual Sends B 23210 EXP Input 11 to Virtual Sends C 23111...
Page 197 ExP inputs to Virtual sends ExP inputs to Virtual sends EXP Input 21 to Virtual Sends A 23109 EXP Input 22 to Virtual Sends A 23209 EXP Input 21 to Virtual Sends B 23110 EXP Input 22 to Virtual Sends B 23210 EXP Input 21 to Virtual Sends C 23111...
Page 198 ExP inputs to Virtual sends ExP inputs to Virtual sends EXP Input 31 to Virtual Sends A 24109 EXP Input 32 to Virtual Sends A 24209 EXP Input 31 to Virtual Sends B 24110 EXP Input 32 to Virtual Sends B 24210 EXP Input 31 to Virtual Sends C 24111...
Page 199 ExP inputs to Virtual sends ExP inputs to Virtual sends EXP Input 41 to Virtual Sends A 25109 EXP Input 42 to Virtual Sends A 25209 EXP Input 41 to Virtual Sends B 25110 EXP Input 42 to Virtual Sends B 25210 EXP Input 41 to Virtual Sends C 25111...
Page 200 ExP inputs to Virtual sends ExP inputs to Virtual sends EXP Input 51 to Virtual Sends A 26109 EXP Input 52 to Virtual Sends A 26209 EXP Input 51 to Virtual Sends B 26110 EXP Input 52 to Virtual Sends B 26210 EXP Input 51 to Virtual Sends C 26111...
Page 201: Exp Outputs
ExP outputs The EXP output bus routes the inputs ( ), and virtual returns ( ), to the Extron EXP outputs. Outputs EXP Output Mix-points Inputs Expansion Outputs (1-8) Virtual Send Bus Mic/Line Inputs to EXP Output Mix-points Virtual Returns Virtual Returns to EXP Output Mix-points Expansion Outputs...
Page 202 table 9: Mic/Line inputs to ExP outputs inputs to ExP outputs inputs to ExP outputs Input 1 to EXP Output 1 20018 Input 2 to EXP Output 1 20117 Input 1 to EXP Output 2 20018 Input 2 to EXP Output 2 20118 Input 1 to EXP Output 3 20019...
Page 203 inputs to ExP outputs inputs to ExP outputs Input 11 to EXP Output 1 21017 Input 12 to EXP Output 1 21117 Input 11 to EXP Output 2 21018 Input 12 to EXP Output 2 21118 Input 11 to EXP Output 3 21019 Input 12 to EXP Output 3 21119...
Page 204 table 10: Virtual returns to ExP outputs Virtual returns to ExP Virtual returns to ExP outputs outputs Virtual Return A to EXP Output 1 21317 Virtual Return B to EXP Output 1 21417 Virtual Return A to EXP Output 2 Virtual Return B to EXP Output 2 21318 21418...
Page 205: Extron Warranty
Extron Electronics makes no further warranties either expressed or implied with respect to the product and its quality, performance, merchantability, or fitness for any particular use. In no event will Extron Electronics be liable for direct, indirect, or consequential damages resulting from any defect in this product even if Extron Electronics has been advised of such damage.
