Configuration Manual
Ascom i62 VoWiFi Handset
5

Maintenance

5.1

Handset

In an existing VoWiFi system it is important to be able to replace VoWiFi Handsets, install
new VoWiFi Handsets and exchange faulty VoWiFi Handsets. The recommended procedure
is to use a template with basic network settings for log in, created in the PDM, and then get
the rest of the settings that were created by the templates in Device Manager in IMS3.
Another important matter is to be able to upgrade system parameters and security settings
in the VoWiFi Handsets. These upgrades are preferably done in the IMS3 if available.
If PDM and IMS3 are used, do one of the following:
• If you want to install new VoWiFi Handset, see
Management (IMS3)
• If you want to create spare VoWiFi Handsets to be used when broken VoWiFi Handsets
need to be replaced later on, see
Number in Large
If only PDM is used, do one of the following:
• If you want to install new VoWiFi Handset, see
Management (IMS3)
• If you want to replace a broken VoWiFi Handset, see
PDM Only
5.1.1

Configure Spare VoWiFi Handsets without a Number in Large Systems

In large systems where IMS3 is used, it is recommended to configure a couple of spare
VoWiFi Handsets without a number in order to quickly replace an broken VoWiFi Handset
later on.
Create a Template
1 Open PDM.
2 Select the Templates tab and click "New". The New template window is opened.
3 In the Device type and Parameter version drop-down lists, select the matching device
type and parameter version for the spare VoWiFi Handset to use, respectively.
4 In the Name field, enter a descriptive name of the template.
5 Click "OK".
6 Set the following network parameters:
• Network settings
• VoIP settings
• Syslog settings
• Unite settings
7 Click "OK" to save the template.
1. All required system settings for the WLAN. For example SSID and Security mode.
2. For example VoIP protocol, Gatekeeper IP address or SIP proxy IP address used to access the PBX.
3. The parameter "Syslog" must be enabled in order to set the "Syslog IP address".
4. IIP address and password (if any) to the IMS3.
9 December 2011/ Ver. D
on page 8.
5.1.1 Configure Spare VoWiFi Handsets without a
Systems.
on page 11.
on page 24.
1
(located under Network > Network A, B, C, or D)
2
(located under VoIP)
3
(if any) (located under Device > General)
4
(if any) (located under Device > Unite)
4.1 Installation with Central Device
4.2 Installation without Central Device
5.2.4 Replacement of Handset with
TD 92675EN
15
