Dialling Tone Pattern; Display; User Display Text; Font Style - ASCOM i62 Configuration Manual

Configuration Manual
Ascom i62 VoWiFi Handset
3 If the downloaded language is selected, it might be needed to select matching
characters as text input language, and the sort order in the phonebook
In the Input Language drop-down list, select the text input language to be used.
Note: This parameter is only applicable for the downloaded language and cannot be
changed by the user. See
information.

6.10.3 Dialling Tone Pattern

Defines which tone pattern to use when dialling.
1 Select Audio > General.
2 In the Dialling tone pattern drop-down list, select the applicable region.

6.11 Display

6.11.1 User Display Text

Defines a text to be shown in the display in idle mode instead of the endpoint ID. If nothing
is entered in this text field, the endpoint ID will be shown.
1 Select Device > Settings.
2 In the User display text field, enter the text to be displayed.

6.11.2 Font style

The display font style can be changed to bold for increased readability.
1 Select Device > Settings.
2 In the Font style list, choose Normal or Bold.

6.11.3 Backlight Timeout

Numbers of seconds before the backlight is turned off.
1 Select Device > General.
2 In the Backlight timeout field, enter number of seconds before the backlight is turned
of when VoWiFi Handset is idle.

6.11.4 Brightness

1 Select Device > Settings.
2 In the Brightness drop-down list, select one of the following:
• Normal - maximum backlight will be used.
• Power save - reduced backlight will be used.

6.11.5 Screen Saver

1 Select Device > Settings.
2 In the Screen saver drop-down list, select one of the following:
• Information - time and status (for example message indication) will be displayed
when the screen saver is activated.
• Black - no information will be displayed when the screen saver is activated.
9 December 2011/ Ver. D
6.5.11 Uploadable Language
TD 92675EN
on page 39 for more
52
