Installation without Central Device Management (IMS3)

In a small VoWiFi system, the administration can be handled using only the PDM.
The synchronization is in this case not handled automatically by the system when a VoWiFi
Handset's parameters are changed in the PDM. When the parameters have been changed in
PDM, each VoWiFi Handset must be placed in the DP1 cradle connected to the
administrator's computer in order to synchronize the parameters with the VoWiFi Handset.
1 Open the PDM.
2 In the Numbers tab, click "New". The New numbers window is opened.
3 In the Device Type and Parameter version drop-down lists, select the matching
device type and the parameter version for the VoWiFi Handset to be use, respectively.
4 In the Prefix field, enter the numbers' prefix (if needed).
5 Create a range of numbers by selecting the "Range" option. Enter the start call
number and the end call number in the fields, respectively.
6 Click "OK".
7 Create a network settings template (see
the following network parameters:
• Network settings
8 Create another template (see
VoWiFi Handset settings applicable to all VoWiFi Handsets (exclude the network
parameters and used security settings). Example of parameters settings:
• VoIP settings
• Software TFTP IP address (if any) (located under Device > General)
• Syslog settings
In addition, settings for hiding menu items in the display, certain level of ring signal
and vibrators etc can also be configured.
9 Apply the network settings template to the VoWiFi Handset, see
Template to a Handset with a Number
10 Apply the common settings template to the VoWiFi Handset, see
Template to a Handset with a Number
11 Put the VoWiFi Handset in the DP1 cradle.
12 In the Device Wizard window, select "Associate with number" and press "OK".
13 Select the VoWiFi Handset to associate with. Press "OK".
The number and parameter settings saved in the PDM will now be synchronized with the
VoWiFi Handset. In addition, the VoWiFi Handset's Device ID will also be synchronized with
the number in the PDM.
If certificates must be used to access a VoWiFi system, also perform the steps 14 - 19.
14 In the Numbers tab, right-click the VoWiFi Handset's number and select "Edit
certificates". An Edit certificate window opens.
15 In the Root tab and Client tab, click "Edit" and select the certificates to import. Click
"Close".
16 In the Numbers tab, right-click the VoWiFi Handset's number and select "Edit
parameters".
1. All required system settings for the WLAN. For example SSID and Security mode.
2. VoIP protocol, Gatekeeper IP address or SIP proxy IP address used to access the PBX.
3. The parameter "Syslog" must be enabled in order to set the "Syslog IP address".
9 December 2011/ Ver. D
1
(located under Network > Network A, B, C, or D)
4.4.1 Create a template
2
(located under VoIP)
3
(if any) (located under Device > General)
on page 13.
on page 13.
4.4.1 Create a template on page 12) with
on page 12) with the common
4.4.2 Apply a
TD 92675EN
4.4.2 Apply a
