Configuration Manual
Ascom i62 VoWiFi Handset
The spare VoWiFi Handset is automatically updated from the IMS3 and restarted. The last
stored settings and licenses for the broken VoWiFi Handset in the IMS3 has been transfered
to the spare VoWiFi Handset.
5.2.3

Replacement of the Handset with PDM and IMS3

If the spare VoWiFi Handset to be used must be factory reset or no network template has
been applied, a PDM is needed to apply the network template to the spare VoWiFi Handset.
When the network template is added, the VoWiFi Handset can log on to the Device Manager.
There are two different replacement procedures as follows:
• If the broken VoWiFi Handset and the spare VoWiFi Handset have the same device type
and functionality license, see
• If the broken VoWiFi Handset and the spare VoWiFi Handset have not the same device
type and/or functionality license. The license must be moved to the spare VoWiFi
Handset, see
Replace without Move Licenses using PDM and IMS3
Both the broken VoWiFi Handset and the spare VoWiFi Handset must be of the same device
type and have same functionality license.
1 In the VoWiFi Handset, press *#34# in idle mode and select "License" to check that
both VoWiFi Handsets have same device type and licenses.
2 Make sure that the broken VoWiFi Handset is saved in the Device Manager (indicated
by a
Handset and select "Save".
3 Switch off the broken VoWiFi Handset to make it offline.
If the spare VoWiFi Handset is not prepared with the basic network settings, also perform
the steps 4 - 7.
4 Open the PDM.
5 Put the spare VoWiFi Handset in the DP1 cradle.
6 Run the template with the basic network settings containing (see
Handset with a Template
• Network settings
• VoIP settings
• Unite settings
7 Remove the VoWiFi Handset from the DP1 cradle. The VoWiFi Handset might be
restarted depending on parameter changes.
8 Enter the number and the password
The spare VoWiFi Handset is automatically updated from the IMS3 and might be restarted
depending on the parameter changes. The last stored settings for the broken VoWiFi
Handset in the IMS3 has been transfered to the new VoWiFi Handset.
Replace and Move License using PDM and IMS3
The broken VoWiFi Handset and the spare VoWiFi Handset do not have the same device
type and/or have the same functionality license.
1. All required system settings for the WLAN. For example SSID and Security mode.
2. VoIP protocol, Gatekeeper IP address or SIP Proxy IP address used to access the PBX.
3. IP address and password (if any) to the IMS3.
4. The password is only required if the "Password" parameter is set.
9 December 2011/ Ver. D
Replace without Move Licenses using PDM and
Replace and Move License using PDM and IMS3
in the Saved column. If not, in the Numbers tab, right-click the broken VoWiFi
on page 12):
1
(located under Network > Network A, B, C, or D)
2
(located under VoIP)
3
(located under Device > Unite)
on page 23.
4
(if any). Press "Login".
TD 92675EN
IMS3.
4.4 Configure a
23
