Configuration Manual
Ascom i62 VoWiFi Handset
Parameter name
Mode for automatic call after
alarm
Turn off NM-MD during call
6.9

Telephony

The following parameters are required for the basic telephony settings.
6.9.1

Endpoint ID and Endpoint number

The Endpoint ID and Endpoint number will automatically be received when registering the
VoWiFi Handset in the VoWiFi system. The Endpoint ID is normally the user's name
registered in the PBX and is displayed in the VoWiFi Handset in idle mode. To change the
name displayed in the VoWiFi Handset, see
Note: If the Endpoint ID needs to be changed, this must be also done in the PBX.
6.9.2

VoIP Protocol

A protocol is a set of standard rules for data traffic required to send information over a
communication channel. Communication protocol is basically following certain rules so that
the system works properly. The following VoIP protocols are supported: H.323 and SIP.
1 Select VOIP > General.
2 In the VoIP protocol drop-down list, select "H.323" or "SIP".
3 Continue with chapter
selected protocol.
H.323 Protocol
If the H.323 protocol is used the Gatekeeper IP Address is usually automatically distributed.
No configuration necessary.
1 Select VoIP > H.323.
2 The following settings are applicable for the H.323 protocol.
• Gatekeeper IP address
• Secondary Gatekeeper address
• Gatekeeper listening port
• Gatekeeper ID (name)
• Gatekeeper password
SIP Protocol
If the SIP protocol is used the SIP Proxy IP Address must be manually entered.
1 Select VoIP > SIP.
9 December 2011/ Ver. D
Description
Off: no automatic call after alarm.
Normal: the call is established as an
ordinary call.
Loudspeaker: the loudspeaker on the
backside of the VoWiFi Handset is
turned on.
Monitoring: a one-way speech channel
is established, that is, the called part
can only listen to an conversation.
Enable or disable alarms during a call.
6.11.1 User Display Text
H.323 Protocol or chapter
TD 92675EN
Value {default}
Off, Normal,
Loudspeaker,
Monitoring {Off}
Yes/No {No}
on page 52.
SIP Protocol depending on the
48
