Configuration Manual
Ascom i62 VoWiFi Handset
4 In the Device Type and Parameter version drop-down lists, select the device type and
the parameter version to use, respectively. Note: The device type and parameter
version must match the VoWiFi Handsets to be used to apply the template.
5 In the Prefix field, enter the numbers' prefix (if needed).
6 Create a range of numbers by selecting the "Range" option. Enter the start call
number and the end call number in the fields, respectively. Click "OK".
Note: The maximum range that can be added at a time are 100 numbers.
7 Apply the network settings template to the selected VoWiFi Handsets. See
Apply a Template to a Handset with a Number
8 Apply the common settings template to the selected VoWiFi Handsets. See
Apply a Template to a Handset with a Number
9 Close the IMS3.
4.1.4

Create a Network Template with Initial Configuration in the PDM

In a factory delivered VoWiFi Handset, the WLAN settings are not configured that is required
to access the IMS3. Using the PDM allows the VoWiFi Handset to be primed with the WLAN
parameters and allows it to log in to the Device Manager in IMS3 for future management
over the air.
Create a template with the basic network settings and IP adress to IMS3. This template is
only used once for each VoWiFi Handset since it must access the WLAN and then log on the
Device Manager. After log in, the settings in the VoWiFi Handset are changed according to
the templates in the Device Manager in IMS3.
1 Open the PDM.
2 Do one of the following:
• If a network template was created in the Device Manager in IMS3, export this
template and import it to PDM. See
(Recommended)
• Create a template (see
network parameters:
a. All required system settings for the WLAN. For example SSID and Security mode.
b. IP adddress and password (if any) to IMS3.
3 Put the VoWiFi Handset in the DP1 cradle.
4 Run the template. See
13.
5 Remove the VoWiFi Handset when synchronisation is finished.
6 Enter the Number and the password
Settings that were stored for the VoWiFi Handset in the Device Manager in IMS3 will now be
downloaded to the VoWiFi Handset. This can, for example, be unique soft- or hotkeys that
have been prepared earlier. When the settings have been downloaded to the VoWiFi
Handset, it might be restarted depending on the parameter changes.
7 Repeat step 3 – 6 for all VoWiFi Handsets.
1. The password is only required if the "Password" parameter is set.
9 December 2011/ Ver. D
4.4.1 Create a template
a
- Network settings (located under Network > Network A (B, C, or D)
b
- Unite settings (located under Device > Unite)
Note: The parameters in this template should be identical to the parameters
in the network template created in the IMS3.
4.4.3 Apply a Template to Handset without a Number
on page 13.
on page 13.
Appendix A for more information.
on page 12) with the following
1
(if any) . Press "Login".
TD 92675EN
4.4.2
4.4.2
on page
10
