Connecting the Cables

I/O ports are on the back panel of the server, and arranged as shown in
USB
10101
(serial data)
Parallel
Ethernet
SCSI
NET MGT
SER MGT
PCI slots
FIGURE 2-1
12 Sun Fire V250 Server Installation Guide • September 2003
5
4
3
2
1
0
Sun Fire V250 I/O Ports
.
FIGURE 2-1
