Summary of Contents for Sun Microsystems Fire V250
- Page 1 Sun Fire V250 Server Parts Replacement Manual Sun Microsystems, Inc. 4150 Network Circle Santa Clara, CA 95054 U.S.A. 650-960-1300 Part No. 817-0901-10 September 2003, Revision A Send comments about this document to: docfeedback@sun.com...
- Page 2 Sun détient une license non exclusive de Xerox sur l’interface d’utilisation graphique Xerox, cette licence couvrant également les licenciées de Sun qui mettent en place l’interface d ’utilisation graphique OPEN LOOK et qui en outre se conforment aux licences écrites de Sun.
-
Page 3: Table Of Contents
Contents Contents iii Figures vii Preface ix Parts Installation and Removal 1 Lifting the Server 2 Replaceable Components 2 Controlling Server Power 3 To Turn Server Power On 4 To Turn Server Power Off 4 Avoiding Electrostatic Discharge 5 To Avoid Electrostatic Discharge While Working on the Front of the Server 5 To Avoid Electrostatic Discharge While Working On Internal Components 6... - Page 4 To Remove a Hard Disk Drive 11 To Insert a Hard Disk Drive 12 Power Supply Unit 13 To Replace a PSU 14 Service Provider Replaceable Components 15 System Configuration Card Reader Module 16 To Remove the System Configuration Card Reader Module 16 To Replace the System Configuration Card Reader Module 17 Power Distribution Board 18 To Remove the Power Distribution Board 19...
- Page 5 To Replace the SCSI Backplane 38 Tape Drive (Optional) 38 To Install a Tape Drive 38 To Remove the Tape Drive 40 DVD-ROM Drive 42 To Remove the DVD-ROM Drive 42 To Replace the DVD-ROM Drive 43 Front Fan Modules 44 To Remove a Front Fan Module 45 To Replace a Front Fan Module 46 Battery 46...
- Page 6 Sun Fire V250 Server Parts Replacement Manual • September 2003...
-
Page 7: Figures
Figures Front Panel Electrostatic Grounding Point 6 FIGURE 1-1 Back Panel Electrostatic Grounding Point 7 FIGURE 1-2 Location of the Service Panel Retaining Screws 8 FIGURE 1-3 Removing the Service Panel 9 FIGURE 1-4 Removing a Hard Disk Drive 12 FIGURE 1-6 Inserting a Hard Disk Drive 13 FIGURE 1-7... - Page 8 FIGURE 1-30 Replacing a DVD-ROM Drive 44 FIGURE 1-31 Front Fan Module Removal 45 FIGURE 1-32 Replacing a Front Fan Module 46 FIGURE 1-33 Removing the Battery 47 FIGURE 1-34 viii Sun Fire V250 Server Parts Replacement Manual • September 2003...
-
Page 9: Preface
Some of the procedures can be carried out by the user, others by the service provider only. Before You Read This Book Read the Sun Fire V250 Server Compliance and Safety Manual before following any of the procedures described in this book. Using UNIX Commands ®... -
Page 10: Typographic Conventions
To delete a file, type rm filename. Shell Prompts Shell Prompt C shell machine-name% C shell superuser machine-name# Bourne shell and Korn shell Bourne shell and Korn shell superuser ALOM shell sc> OpenBoot PROM shell x Sun Fire V250 Server Parts Replacement Manual • September 2003... -
Page 11: Related Documentation
Advanced Lights-Out Manager Online 817-3175-xx Help Read the Sun Fire V250 Server Compliance and Safety Guide before performing any of the procedures documented in this manual. Accessing Sun Documentation Online You can view, print, or purchase a broad selection of Sun documentation, including localized versions, at: http://www.sun.com/documentation/... - Page 12 Sun Fire V250 Server Parts Replacement Manual • September 2003...
-
Page 13: Parts Installation And Removal
C H A P T E R Parts Installation and Removal This chapter contains procedures for replacing the server’s internal hardware components. Caution – The procedures in this section are for the attention of service providers only. Caution – Read “Avoiding Electrostatic Discharge” on page 5, and wear a properly grounded antistatic strap, before you carry out any of the procedures in this book. -
Page 14: Lifting The Server
Motherboard, 0 MB, single 1.28GHz CPU F375-3176 Motherboard, 0 MB, dual 1.28GHz CPU F375-3130 SCC reader module F370-5646 Front fan F370-5962 Cable kit F370-6114 SCSI backplane F370-5959 Power distribution board F370-5961 Sun Fire V250 Server Parts Replacement Manual • September 2003... -
Page 15: Controlling Server Power
Service Provider Replaceable Components TABLE 1-2 Component Part Number Rear fan module F370-6084 ALOM card F501-6346 CPU heatsink with fan F370-5686 256MB DDR1 DIMM (pair) F370-5565 512MB DDR1 DIMM (pair) F370-4939 1GB DDR1 DIMM (pair) F370-4940 DVD Drive F370-5690 DAT Drive F390-0028 Caution –... -
Page 16: To Turn Server Power On
Whenever possible, initiate an orderly shutdown. Forcing an immediate hardware shutdown can corrupt the disk drive and cause loss of data. 5. Wait for the front panel green LED to go out. Sun Fire V250 Server Parts Replacement Manual • September 2003... -
Page 17: Avoiding Electrostatic Discharge
6. Disconnect the power cable. This is the only way to remove power from the server. Electrical power is present when the server is in Standby mode. Caution – As long as the power cord is connected, electrical energy is present inside the server. -
Page 18: To Avoid Electrostatic Discharge While Working On Internal Components
FIGURE 1-1 Front Panel Electrostatic Grounding Point FIGURE 1-1 To Avoid Electrostatic Discharge While Working On Internal Components 1. Turn server power off. See “Controlling Server Power” on page 3. Sun Fire V250 Server Parts Replacement Manual • September 2003... -
Page 19: Service Panel
2. Attach one end of the antistatic strap to the grounding stud located on the server’s back panel, and the other end to your wrist. Back Panel Electrostatic Grounding Point FIGURE 1-2 Service Panel Remove the service panel, which is located on one side of the server, to gain access to the internal components. -
Page 20: To Remove The Service Panel
Location of the Service Panel Retaining Screws FIGURE 1-3 4. Place the server on its side. Take care not to damage the feet. 5. Remove the service panel from the body of the server. FIGURE 1-4 Sun Fire V250 Server Parts Replacement Manual • September 2003... -
Page 21: Location Of Components
Slide service panel away from front of server, then lift up Removing the Service Panel FIGURE 1-4 Location of Components The position of each of the server’s major components is shown in FIGURE 1-5 Chapter 1 Parts Installation and Removal... - Page 22 System configuration card reader module Front fan Back fans ALOM card CPU/CPU cards Retaining arm for long PCI card SCSI backplane Hard disk drive Location of Internal Components FIGURE 1-5 Sun Fire V250 Server Parts Replacement Manual • September 2003...
-
Page 23: User Replaceable Components
User Replaceable Components Hard Disk Drives For information on removing a hard disk drive while the operating system is running, see the Sun Fire V250 Server Administration Guide. To Remove a Hard Disk Drive 1. Ensure you are properly grounded. -
Page 24: To Insert A Hard Disk Drive
This releases the handle on the front of the hard disk drive. The lever must be open before you insert the hard disk drive into the server. If it is not, the hard disk drive will not engage with the server correctly. Sun Fire V250 Server Parts Replacement Manual • September 2003... -
Page 25: Power Supply Unit
Inserting a Hard Disk Drive FIGURE 1-7 8. Close the door and lock it. Power Supply Unit Note – For information on replacing a redundant power supply unit, see the Sun Fire V250 Server Administration Guide. Chapter 1 Parts Installation and Removal... -
Page 26: To Replace A Psu
4. Slide the PSU out of the server body by pulling on the green PSU handle. FIGURE 1-8 5. Place the module on an antistatic bag or mat. 6. Locate the replacement PSU in the correct bay. Sun Fire V250 Server Parts Replacement Manual • September 2003... -
Page 27: Service Provider Replaceable Components
7. With the handle in its down position, slide the PSU into the server’s chassis as far as it will go. Ensure that the handle does not return to a vertical position until the PSU is as far into the chassis as it will go, otherwise the PSU will not engage with the power distribution board inside the server. -
Page 28: System Configuration Card Reader Module
On/Standby button operation mode switch For information on the function of the system configuration card, see the Sun Fire V250 Server Administration Guide. To Remove the System Configuration Card Reader Module 1. Turn server power off. -
Page 29: To Replace The System Configuration Card Reader Module
6. Unclip and slide out the system configuration card reader module. Squeeze the two green release catches at both sides to release it. See FIGURE 1-10 Removing the System Configuration Card Reader Module FIGURE 1-10 7. Place the module on an antistatic bag or mat. To Replace the System Configuration Card Reader Module 1. -
Page 30: Power Distribution Board
Power Distribution Board The power distribution board (PDB) takes power to the server’s internal components. Caution – The procedures in this section are for the attention of service providers only. Sun Fire V250 Server Parts Replacement Manual • September 2003... -
Page 31: To Remove The Power Distribution Board
To Remove the Power Distribution Board 1. Turn server power off. See “Controlling Server Power” on page 3. 2. Open the door. 3. Ensure you are properly grounded. See “Avoiding Electrostatic Discharge” on page 5. 4. Disconnect the power and data cables from the DVD-ROM drive and tape drive (if fitted). -
Page 32: Figure 1-12 Power Distribution Board Retaining Screws
FIGURE 1-12 8. Disconnect the power and data cables: 2x power from the system board 1x data from the SCSI backplane 9. Disconnect the wiring from the cable management bracket. Sun Fire V250 Server Parts Replacement Manual • September 2003... -
Page 33: Figure 1-13 Power Distribution Board Removal
10. Remove the power distribution board and wiring harness. See FIGURE 1-13 Power Distribution Board Removal FIGURE 1-13 Chapter 1 Parts Installation and Removal... -
Page 34: To Replace The Power Distribution Board
Memory There are four memory module sockets per processor on the server’s system board. Memory is supplied by Sun in paired DIMMS. Ensure that you use the DIMM pairs as supplied and do not mix them. Caution – The procedures in this section are for the attention of service providers only. -
Page 35: Memory Configuration Rules
Memory Configuration Rules Memory is shipped in matched pairs for use on the Sun Fire V250 server. Use memory only in these matched pairs - do not mix memory modules. When you install memory, follow the configuration rules below. DIMMs must be identical. -
Page 36: To Remove Memory
7. Replace the service panel. To Remove Memory 1. Press down on the retention latches at the sides of the memory module. This frees the module from its socket. See FIGURE 1-16 Sun Fire V250 Server Parts Replacement Manual • September 2003... -
Page 37: Rear Cooling Fans
3. Replace the service panel. Rear Cooling Fans The Sun Fire V250 server has one cooling fan module in the back, which contains two fans. Remove and replace the module as a single unit. Caution – The procedures in this section are for the attention of service providers only. -
Page 38: To Remove The Fan Module
3. Disconnect the fan module power cables from the system board. FIGURE 1-17 Fan module power cables Disconnecting the Fan Module Power Cables FIGURE 1-17 4. Unclip the fan retaining tab. FIGURE 1-18 Sun Fire V250 Server Parts Replacement Manual • September 2003... -
Page 39: To Replace The Fan Module
Fan module retaining tab Removing the Fan Module FIGURE 1-18 5. Rotate the fan module out and remove it from the chassis. To Replace the Fan Module 1. Insert the replacement fan module. 2. Connect the fan power cables to the system board. 3. -
Page 40: To Remove A Cpu Fan And Heatsink Assembly
2. Ensure the server is properly grounded. See the instructions in “Avoiding Electrostatic Discharge” on page 5. 3. Remove the service panel. See “To Remove the Service Panel” on page 8. Sun Fire V250 Server Parts Replacement Manual • September 2003... -
Page 41: To Replace A Cpu Fan And Heatsink Assembly
4. Disconnect the power cable for the CPU fan from the system board. CPU Fan Removal FIGURE 1-19 5. Press down on the tabs to release the rear clips. 6. Remove the clips from the side of the assembly. 7. Slide the heatsink assembly to release the front clips. FIGURE 1-19 8. -
Page 42: System Board Assembly
3. Connect the CPU fan and heatsink assembly power cable. System Board Assembly The CPU and system board is replaced as a single assembly. Caution – The procedures in this section are for the attention of service providers only. Sun Fire V250 Server Parts Replacement Manual • September 2003... -
Page 43: To Remove The System Board
To Remove The System Board 1. Power off the server. See “Controlling Server Power” on page 3. 2. Place the system on its side. 3. Ensure the server is properly grounded. See “Avoiding Electrostatic Discharge” on page 5. 4. Remove the service panel. See “To Remove the Service Panel”... -
Page 44: Figure 1-22 Location Of System Board Retaining Screw
Location of System Board Retaining Screw FIGURE 1-22 12. Slide the system board release lever towards the front of the server to release the system board. Sun Fire V250 Server Parts Replacement Manual • September 2003... -
Page 45: Pci Cards
Removing the System Board from the Chassis FIGURE 1-23 PCI Cards For information on the PCI cards that are available for the server, see the Sun Fire V250 Server System Administration Guide. Caution – The procedures in this section are for the attention of service providers only. -
Page 46: Figure 1-24 Pci Card Retaining Mechanism
6. Place the PCI card into its slot and press it home. 7. Replace the support for long PCI cards, if necessary, and screw into place. 8. Return the PCI card retaining mechanism to its closed position. Sun Fire V250 Server Parts Replacement Manual • September 2003... -
Page 47: To Remove A Pci Card
To Remove a PCI Card 1. If removing a long PCI card, loosen the screws which secure the support for long PCI cards. These are located on the base of the server. See FIGURE 1-25 2. Slide the support towards the back of the PCI card. Moving the Support for Long PCI Cards FIGURE 1-25 3. -
Page 48: Scsi Backplane
Caution – The procedures in this section are for the attention of the service provider only. To Remove the SCSI Backplane 1. Power off the server. See “Controlling Server Power” on page 3. Sun Fire V250 Server Parts Replacement Manual • September 2003... -
Page 49: Figure 1-26 Location Of Scsi Backplane And Fixing Screws
2. Ensure the server is properly grounded. See “Avoiding Electrostatic Discharge” on page 5. 3. Remove all hard disk drives. See “To Remove a Hard Disk Drive” on page 11. Make a note of which slot you remove each hard disk drive from. 4. -
Page 50: To Replace The Scsi Backplane
1. Turn server power off. See “Controlling Server Power” on page 3. 2. Open the door. 3. Ensure the server is properly grounded. See “Avoiding Electrostatic Discharge” on page 5. Sun Fire V250 Server Parts Replacement Manual • September 2003... -
Page 51: Figure 1-27 Tape Drive Blanking Plate Removal
4. Remove the blanking plate. See FIGURE 1-27 Blanking plate Tape Drive Blanking Plate Removal FIGURE 1-27 5. Attach the power and data cables to the tape drive module. Chapter 1 Parts Installation and Removal... -
Page 52: To Remove The Tape Drive
2. Turn server power off. See “Controlling Server Power” on page 3. 3. Open the door. 4. Ensure the server is properly grounded. See “Avoiding Electrostatic Discharge” on page 5. Sun Fire V250 Server Parts Replacement Manual • September 2003... -
Page 53: Figure 1-29 Removing The Optional Tape Drive
5. Release the tape drive module from the server. See FIGURE 1-29 Squeeze the two green release catches at both sides to release it. Tape drive release catch Removing the Optional Tape Drive FIGURE 1-29 6. Slide the tape drive out of the server’s chassis. 7. -
Page 54: Dvd-Rom Drive
2. Turn server power off. See “Controlling Server Power” on page 3. 3. Open the door. 4. Ensure the server is properly grounded. See “Avoiding Electrostatic Discharge” on page 5. Sun Fire V250 Server Parts Replacement Manual • September 2003... -
Page 55: To Replace The Dvd-Rom Drive
5. Unclip the DVD-ROM drive module. See FIGURE 1-30 Squeeze the two green release catches at both sides to release it. Removing the DVD-ROM Drive FIGURE 1-30 6. Slide the DVD-ROM drive out of the slot. 7. Disconnect the power and data cables. To Replace the DVD-ROM Drive 1. -
Page 56: Front Fan Modules
Front Fan Modules There are two cooling fan modules on the front of the server, next to the hard disk drive bays. Open the door to access the fan modules. Sun Fire V250 Server Parts Replacement Manual • September 2003... -
Page 57: To Remove A Front Fan Module
To Remove a Front Fan Module 1. Turn server power off. See “Controlling Server Power” on page 3. 2. Open the door. 3. Ensure the server is properly grounded. See “Avoiding Electrostatic Discharge” on page 5. 4. Loosen the retaining screw. Loosen retaining screw Front Fan Module Removal... -
Page 58: To Replace A Front Fan Module
5. Slide the fan module all the way in to its bay. 6. Tighten the retaining screw. Replacing a Front Fan Module FIGURE 1-33 Battery The battery powers the server’s clock. Sun Fire V250 Server Parts Replacement Manual • September 2003... -
Page 59: To Replace The Battery
Caution – There is a risk of explosion if the battery is replaced with the wrong type. Dispose of used batteries according to the instructions. To Replace the Battery 1. Turn server power off. See “Controlling Server Power” on page 3. 2. - Page 60 5. Locate the new battery in the housing and press down on it to secure it in place. Sun Fire V250 Server Parts Replacement Manual • September 2003...
-
Page 61: Index
hard disk drive 11 installation memory card reader 16, 17 Index lid 7 memory 22 battery 46 moving the system, precautions 4 cooling fans 25 PCI cards 33 CPU and system board assembly 30 power CPU heatsink 27 controlling server power 3 the on/standby switch 3 power distribution board 18 disk drive... - Page 62 Sun Fire V250 Server Parts Replacement Manual • September 2003...
