- Page 1 Sun Fire™ V210 and V240 Servers Product Notes Sun Microsystems, Inc. 4150 Network Circle Santa Clara, CA 95054 U.S.A. 650-960-1300 Part No. 816-4828-13 February 2004, Revision A Send comments about this document to: docfeedback@sun.com...
- Page 2 LOOK GUIs and otherwise comply with Sun’s written license agreements. Use, duplication, or disclosure by the U.S. Government is subject to restrictions set forth in the Sun Microsystems, Inc. license agreements and as provided in DFARS 227.7202-1(a) and 227.7202-3(a) (1995), DFARS 252.227-7013(c)(1)(ii) (Oct. 1998), FAR 12.212(a) (1995), FAR 52.227-19, or FAR 52.227-14 (ALT III), as applicable.
-
Page 3: Table Of Contents
Introduction This document contains information that became available after the platform documentation was printed. It contains the following sections: “Contents of the Ship Kit” on page 2 “Preinstalled Software” on page 2 “Sun ONE Software” on page 3 “Unpacking the Server” on page 3 “Opening the Bezel”... -
Page 4: Contents Of The Ship Kit
Contents of the Ship Kit The table below replaces that given in Chapter 1 of the Sun Fire V210 and V240 Servers Installation Guide. Contents of the Sun Fire V210 and V240 Servers Ship Kit TABLE 1 Description Quantity Part Number... -
Page 5: Sun One Software
Sun ONE Software The Sun Fire V210 and V240 servers ship with Sun ONE software preinstalled. The packages are: Sun ONE Web Server 6.0 (60 days try and buy) http://docs.sun.com/source/816-5683-10/index.html Sun ONE Application Server 7, Platform Edition (free) http://docs.sun.com/db/prod/ Sun ONE Application Server 7, Standard Edition (60 days try and by) http://docs.sun.com/db/prod/... -
Page 6: Opening The Bezel
Status Indicators: Hard Disk Drive This section corrects page 9 of the Sun Fire V210 and V240 Servers Administration Guide. The hard disk drive indicators are arranged as shown in... -
Page 7: Powering On The Server From The Keyboard
Powering On the Server From the Keyboard There is an error in Chapter 4 of the Sun Fire V210 and V240 Servers Installation Guide. In the subsection called “To Power On From the Keyboard” (pages 42-45), there is another step that you need to perform after typing the poweron command in step 5. -
Page 8: Motherboard Jumper Information
Fit jumper to 2-3 to clear CMOS. JP10 1-2: Not Fitted Override PSON#. Only service personnel should modify this setting. JP11 1-2: Not Fitted ROM write-protect. Only service personnel should modify this setting. Sun Fire V210 and V240 Servers Product Notes • February 2004... - Page 9 Default Jumper settings TABLE 2 Jumper ID Default setting Additional information JP12 1-2: Not Fitted ALOM console bypass. Only service personnel should modify this setting. JP13 1-2: Fitted (this is non- OBP Flash ROM swap halves. Only service functional setting) personnel should modify this setting.
- Page 10 JP12 JP14 JP11 JP10 JP13 Jumper Locations FIGURE 2 Sun Fire V210 and V240 Servers Product Notes • February 2004...
-
Page 11: Sun Fire V240 Server: Power Supply Unit Removal
The design of the air duct inside the server has changed since the platform documentation went to print. The air duct no longer screws into place, as described in the Sun Fire V210 and V240 Servers Parts Replacement Manual, but clips into the chassis instead. Use the handle on top of the duct to position it correctly and clip it into the chassis. -
Page 12: Replacing The Battery
Serial Interface Adapter (X-option number X1155A), this adapter will not fit into slot 0 of the Sun Fire V240 Server or the PCI slot of the Sun Fire V210 Server. It will fit into slots 1 and 2 of the Sun Fire V240 Server but you cannot use it in a Sun Fire V210 Server. -
Page 13: Installing A Hard Disk Drive
PCI Cards The following note refers to page 36 of the Sun Fire V210 and V240 Server Parts Replacement Manual (817-0743-10). Note – A 66 MHz PCI card can only perform at 33 MHz when it is attached to... -
Page 14: Usb Circuit Breakers
Rackmounting the Server This section gives some additional information about rackmounting the server. It supports the rackmounting section of the Sun Fire V210 and V240 Servers Installation Guide (816-4825-xx). The design of the slide assemblies has changed slightly since the platform documentation was written. - Page 15 See the steps in to attach the cable management arm to the slide rail FIGURE 4 assemblies. Installing the cable management arm FIGURE 4 When you attach cabling to the cable management arm, ensure you leave enough slack for the cable management arm to extend when the slide rail assemblies are extended.
- Page 16 Attach cable to both parts of arm Leave enough slack cable to allow for extension Attaching cables to the cable management arm FIGURE 5 Sun Fire V210 and V240 Servers Product Notes • February 2004...
-
Page 17: Sunvts Tests
# cd /cdrom/cdrom0/XML_Libraries_2.4.12/Product # pkgadd -d . SUNWlxml SUNWlxmlx SUNWlxmlS Additional Tests Not Included In the Manual There are three additional tests to add to Table 5-1 in the Sun Fire V210 and V240 Servers Administration Guide: Additional SunVTS Tests... -
Page 18: Additional Alom Information
Do not issue the scadm resetrsc command until after the firmware update is complete. Do not issue the scadm resetrsc command immediately after the firmware update has taken place. Sun Fire V210 and V240 Servers Product Notes • February 2004... - Page 19 Not all console output sent to ttyb on initial redirect or ALOM server reset If you have your console set to ttyb (10101) rather than to ttya (the ALOM serial port, labeled SER MGT), you may not see all the output from the console. This is because both OBP and POST send diagnostic output to ttya by default.
-
Page 20: To Set The Serial Port Speed Back To The Default
POST failure is received When OpenBoot PROM (OBP) reports memory DIMM errors to ALOM, it sends SC alert messages with the incorrect memory slot position for the Sun Fire V210 and V240 servers. However, the memory errors are still valid.
