Four DDR DIMM slots per processor
One 10/100/1000 BASE-T autonegotiating Ethernet port
One Ultra160 SCSI multimode port
One RJ-45 serial port for server management
One 10BASE-T Ethernet port for server management
One DB-9 general purpose serial port
Four USB ports
Six PCI expansion ports
DVD-ROM drive
Up to eight SCSI hard disk drives
System configuration card
Capacity for dual redundant power supplies

Front Panel Overview

You access the front panel features by unlocking and opening the door of the server.
The door key supplied in the shipkit.
See
FIGURE 1-2
4 Sun Fire V250 Server Installation Guide • September 2003
for the location of each front panel component.
