Final Set Up

Step 16 - Setting of Courtesy Light Time
The courtesy light time can only be adjusted with the
Universal Programmer (PG-3).
Step 17 - Setting the Pet Mode position
The default Pet Mode height can be changed as follows:
a. Make sure the door is closed, then press and
hold the OPEN button for six (6) seconds (Fig.
29), until you hear three beeps and the OPEN
and CLOSE LEDs fl ash rapidly.
b. Press the OPEN or CLOSE button to move the
door to the desired pet mode open position.
c. Press the SET button to record the new position.
When activated, Pet Mode drives the door to the preset
position from either above or below. Pet Mode's active
status is indicated by both the OPEN and CLOSE LIMIT
LEDs being illuminated. If a Pet Mode button is pressed
while the door is moving the door will stop. If a Pet
Mode button is pressed when the door is in the Pet
position, then the door will close.
Step 18 - Installing the Wall Mounted
Transmitter (Optional)
a. Remove the faceplate from the transmitter.
b. Affi x the baseplate in a convenient wall location
that is out of reach of children and convenient
to the customer (Fig 30). Make sure the door is
visible from this location.
c. Replace the faceplate.
d. To code the transmitter, see Steps 10.1 through
10.4 on page 19.
Step 19 - Reset all Factory Defaults
a. Turn power to opener off.
b. Press and hold the SET Button (Fig 31).
c. Turn power on while holding the SET button.
Continue to hold until all LEDs are off.
» This will not erase transmitter codes
stored in memory.
Owner Installation Instructions GDO-6v3 EasyRoller
fi g 29
fi g 30
fi g
31
