Draytek Vigor2110 Series User Manual page 92

Enable Access Control
Policy
MAC Address Filter
Client's MAC Address
Attribute
Add
Delete
Edit
Cancel
OK
Clear All
Select to enable the MAC Address access control feature.
Select to enable any one of the following policy. Choose
Activate MAC address filter to type in the MAC
addresses for other clients in the network manually.
Choose Isolate WLAN from LAN will separate all the
WLAN stations from LAN based on the MAC Address list.
Display all MAC addresses that are edited before.
Manually enter the MAC address of wireless client.
s: Isolate the station from LAN - select to isolate the
wireless connection of the wireless client of the MAC
address from LAN.
Add a new MAC address into the list.
Delete the selected MAC address in the list.
Edit the selected MAC address in the list.
Give up the access control set up.
Click it to save the access control list.
Clean all entries in the MAC address list.
82
Vigor2110 Series User's Guide
