Page 2 Vigor2110 Series Broadband Firewall Router User’s Guide Version: 3.0 Firmware Version: V3.3.6 Date: 27/07/2011 Vigor2110 Series User’s Guide...
Page 3: Copyright Information
Web registration is preferred. You can register your Vigor router via Be a Registered http://www.draytek.com. Owner Due to the continuous evolution of DrayTek technology, all routers will be regularly Firmware & Tools upgraded. Please consult the DrayTek web site for more information on newest Updates firmware, tools and documents.
Page 4: European Community Declarations
Product: Vigor2110 Series Router DrayTek Corp. declares that Vigor2110 Series of routers are in compliance with the following essential requirements and other relevant provisions of R&TTE Directive 1999/5/EEC. The product conforms to the requirements of Electro-Magnetic Compatibility (EMC) Directive 2004/108/EC by complying with the requirements set forth in EN55022/Class B and EN55024/Class B.
Page 5: Table Of Contents
3.1.4 PPTP/L2TP........................38 3.2 LAN ............................41 3.2.1 Basics of LAN ......................... 41 3.2.2 General Setup......................... 42 3.3 NAT ............................45 3.3.1 Port Redirection ......................46 3.3.2 DMZ Host........................48 3.3.3 Open Ports........................50 3.4 Applications ........................... 52 Vigor2110 Series User’s Guide...
Page 6 4.2.5 Bind IP to MAC ......................118 4.3 NAT ............................119 4.3.1 Port Redirection ......................119 4.3.2 DMZ Host........................122 4.3.3 Open Ports........................124 4.4 Firewall ..........................125 4.4.1 Basics for Firewall......................125 4.4.2 General Setup....................... 128 Vigor2110 Series User’s Guide...
Page 7 4.12 Wireless LAN ........................224 4.12.1 Basic Concepts......................224 4.12.2 General Setup......................227 4.12.3 Security ........................230 4.12.4 Access Control......................232 4.12.5 WPS..........................233 4.12.6 WDS..........................235 4.12.7 Advanced Setting......................238 4.12.8 WMM Configuration ....................239 Vigor2110 Series User’s Guide...
Page 8 5.9.1 Creating an Account via Vigor Router ................299 5.9.2 Creating an Account via MyVigor Web Site..............302 5.10 How can I get the files from USB storage device connecting to Vigor router? ....306 viii Vigor2110 Series User’s Guide...
Page 9 6.4 Checking If the ISP Settings are OK or Not ................ 313 6.5 Problems for 3G Network Connection ................315 6.6 Backing to Factory Default Setting If Necessary ..............316 6.7 Contacting Your Dealer ....................... 317 Vigor2110 Series User’s Guide...
Page 11: Preface
Vigor2110 series is a broadband router. It integrates IP layer QoS, NAT session/bandwidth management to help users control works well with large bandwidth. By adopting hardware-based VPN platform and hardware encryption of AES/DES/3DS, the router increases the performance of VPN greatly, and offers several protocols (such as IPSec/PPTP/L2TP) with up to 2 VPN tunnels.
Page 12: Led Indicators And Connectors
Firewall >>General Setup. (Such profile must be established under CSM menu) Interface Description Connector for accessing the Internet. LAN (1-4) Connecters for local networked devices. Connecter for USB storage device (Pen Driver/Mobile HD) or printer. Vigor2110 Series User’s Guide...
Page 13 5 seconds. When you see the ACT LED begins to blink rapidly than usual, release the button. Then the router will restart with the factory default configuration. Connector for a power adapter. Power Switch. ON/OFF Vigor2110 Series User’s Guide...
Page 14: For Vigor2110N
Press the button once to enable (WLAN LED on) or WLAN disable (WLAN LED off) wireless connection. Connector for accessing the Internet. LAN (1-4) Connecters for local networked devices. Connecter for USB storage (Pen Driver Mobile/HD) or printer. Vigor2110 Series User’s Guide...
Page 15 5 seconds. When you see the ACT LED begins to blink rapidly than usual, release the button. Then the router will restart with the factory default configuration. Connecter for a power adapter. Power Switch. ON/OFF Vigor2110 Series User’s Guide...
Page 16: For Vigor2110Vn
Press the button once to enable (WLAN LED on) or WLAN disable (WLAN LED off) wireless connection. Connector for accessing the Internet. LAN (1-4) Connecters for local networked devices. Connecter for USB storage (Pen Driver Mobile/HD) or printer. Vigor2110 Series User’s Guide...
Page 17 5 seconds. When you see the ACT LED begins to blink rapidly than usual, release the button. Then the router will restart with the factory default configuration. Connecter for a power adapter. Power Switch. ON/OFF Vigor2110 Series User’s Guide...
Page 18: Hardware Installation
4 PCs directly. Connect Phone port to a conventional analog telephone. Connect detachable antennas to the router for Vigor2110 series (n model). Connect one end of the power cord to the power port of this device. Connect the other end to the wall outlet of electricity.
Page 19: Stand Installation
The Vigor2110 must be placed erectly. Therefore you have to install a stand onto the router to make it standing firmly. Please follow the figures listed below to finish the installation. Vigor2110 Series User’s Guide...
Page 20: Printer Installation
You can install a printer onto the router for sharing printing. All the PCs connected this router can print documents via the router. The example provided here is made based on Windows XP/2000. For Windows 98/SE/Vista, please visit www.draytek.com. Before using it, please follow the steps below to configure settings for connected computers (or wireless clients).
Page 21 Open File->Add Printer. A welcome dialog will appear. Please click Next. Click Local printer attached to this computer and click Next. In this dialog, choose Create a new port Type of port and use the drop down list to select Standard TCP/IP Port. Click Next. Vigor2110 Series User’s Guide...
Page 22 In the following dialog, type 192.168.1.1 (router’s LAN IP) in the field of Printer Name or IP Address and type IP_192.168.1.1 as the port name. Then, click Next. Click Standard and choose Generic Network Card. Then, in the following dialog, click Finish. Vigor2110 Series User’s Guide...
Page 23 10. Select "LPR" on Protocol, type p1 (number 1) as Queue Name. Then click OK. Next please refer to the red rectangle for choosing the correct protocol and LPR name. Vigor2110 Series User’s Guide...
Page 24 If you do not know whether your printer is supported or not, please visit www.draytek.com to find out the printer list. Open Support >FAQ; find out the link of Printer Server and click it; then click the What types of printers are compatible with Vigor router? link.
Page 25: Configuring Basic Settings
Yet, for admin mode operation, please type “admin/admin” on Username/Password and click Login for full configuration. Notice: If you fail to access to the web configuration, please go to “Trouble Shooting” for detecting and solving your problem. Vigor2110 Series User’s Guide...
Page 26: Changing Password
Please type “admin/admin” on Username/Password for admin mode. Otherwise, do not type any word (both username and password are Null for user mode) on the window and click Login on the window. Now, the Main Screen will appear. Main screen for admin mode operation (full configuration) Vigor2110 Series User’s Guide...
Page 27 Note: The home page will change slightly in accordance with the type of the router you have. Go to System Maintenance page and choose Administrator Password/User Password. Enter the login password (the default is blank) on the field of Old Password. Type New Password. Then click OK to continue. Vigor2110 Series User’s Guide...
Page 28: Quick Start Wizard
On the next page as shown below, please select the appropriate Internet access type according to the information from your ISP. For example, you should select PPPoE mode if the ISP provides you PPPoE interface. Then click Next for next step. Vigor2110 Series User’s Guide...
Page 29: Pppoe
If your ISP provides you the PPPoE connection, please select PPPoE for this router. The following page will be shown: Assign a specific valid user name (maximum 63 characters) provided User Name by the ISP. Assign a valid password provided by the ISP. Password Vigor2110 Series User’s Guide...
Page 30: Pptp/L2Tp
Click Finish. Then, the system status of this protocol will be shown. Click PPTP/L2TP as the protocol. Type in all the information that your ISP provides for this protocol. Click Next for viewing summary of such connection. Vigor2110 Series User’s Guide...
Page 31: Static Ip
Click Finish. Then, the system status of this protocol will be shown. Click Static IP as the protocol. Type in all the information that your ISP provides for this protocol. After finishing the settings in this page, click Next to see the following page. Vigor2110 Series User’s Guide...
Page 32: Dhcp
Click Finish. Then, the system status of this protocol will be shown. Click DHCP as the protocol. Type in all the information that your ISP provides for this protocol. After finishing the settings in this page, click Next to see the following page. Vigor2110 Series User’s Guide...
Page 33: Service Activation Wizard
Service Activation Wizard is a tool which allows you to use trial version or update the license of WCF directly without accessing into the server (MyVigor) located on http://myvigor.draytek.com. For using Web Content Filter Profile, please refer to section 5.6.3 Web Content Filter Profile for detailed information.
Page 34 Note: If you activate Formal edition with license key first, the free trial edition will be invalid. In the following page, you can activate the Web content filter service at the same time or individually. When you finish the selection, please click Next. Vigor2110 Series User’s Guide...
Page 35 Note: The service will be activated and applied as the default rule configured in Firewall>>General Setup. Now, the web page will display the service that you have activated according to your selection(s). The valid time for the free trial of these services is one month. Vigor2110 Series User’s Guide...
Page 36 Activation Wizard again to reach your goal by clicking the radio button of Formal edition with license key and clicking Next. Check the box of “I have read and accept the above..” and click Next. Follow the on-screen instruction to install the formal edition of WCF license. Vigor2110 Series User’s Guide...
Page 37: Online Status
Note: The words in green mean that the WAN connection of that interface is ready for accessing Internet; the words in red mean that the WAN connection of that interface is not ready for accessing Internet. Vigor2110 Series User’s Guide...
Page 38: Saving Configuration
Each time you click OK on the web page for saving the configuration, you can find messages showing the system interaction with you. Ready indicates the system is ready for you to input settings. Settings Saved means your settings are saved once you click Finish or OK button. Vigor2110 Series User’s Guide...
Page 39: User Mode Operation
Hence, the NIC has reserved certain addresses that will never be registered publicly. These are known as private IP addresses, and are listed in the following ranges: Vigor2110 Series User’s Guide...
Page 40 However, the original Ethernet WAN1 still can be used and Load-Balance can be done in the router. Besides, 3G USB Modem also can be used as backup device. Therefore, when WAN1 is not available, the router will use 3.5G for supporting automatically. The supported 3G USB Vigor2110 Series User’s Guide...
Page 41: Pppoe
Modem will be listed on DrayTek web site. Please visit www.draytek.com for more detailed information. Below shows the menu items for Internet Access. To choose PPPoE as the accessing protocol of the internet, please select PPPoE from the Internet Access menu. The following web page will be shown.
Page 42 Modem Dial String2 - Such value is used to dial through USB mode. Please use the default value. If you have any question, please contact to your ISP. PPP Username - Type the PPP username (optional). PPP Password - Type the PPP password (optional). Vigor2110 Series User’s Guide...
Page 43 Notice that this setting is available for WAN1 only. Fixed IP – Click Yes to use this function and type in a fixed IP address in the box of Fixed IP Address. Default MAC Address – You can use Default MAC Address or Vigor2110 Series User’s Guide...
Page 44: Static Or Dynamic Ip
If you have a public subnet, you could assign an IP address or many IP address to the WAN interface. To use Static or Dynamic IP as the accessing protocol of the internet, please choose Static or Dynamic IP mode from Internet Access menu. The following web page will be shown. Vigor2110 Series User’s Guide...
Page 45 Ping IP – If you choose Ping Detect as detection mode, you have to type IP address in this field for pinging. TTL (Time to Live) – Displays value for your reference. TTL value is set by telnet command. Vigor2110 Series User’s Guide...
Page 46 Please use the default value. If you have any question, please contact to your ISP. PPP Username - Type the PPP username (optional). PPP Password - Type the PPP password (optional). PPP Authentication – Select PAP only or PAP or CHAP for PPP. Vigor2110 Series User’s Guide...
Page 47 Default MAC Address : Click this radio button to use default MAC address for the router. Specify a MAC Address: Some Cable service providers specify a specific MAC address for access authentication. In such cases you Vigor2110 Series User’s Guide...
Page 48: Pptp/L2Tp
WAN Backup Setup please Enable the Dial Backup Mode to perform file backup via USB device. After choosing Enable, please click the 3G USB Modem Backup link to access into the following page for configuring detailed settings. Vigor2110 Series User’s Guide...
Page 49 Ping IP – If you choose Ping Detect as detection mode, you have to type IP address in this field for pinging. TTL (Time to Live) – Displays value for your reference. TTL value is set by telnet command. Vigor2110 Series User’s Guide...
Page 50 Obtain an IP address automatically – Click this button to obtain WAN IP Network the IP address automatically. Settings Specify an IP address – Click this radio button to specify some data. IP Address – Type the IP address. Subnet Mask – Type the subnet mask. Vigor2110 Series User’s Guide...
Page 51: Lan
IP address. As a part of the public subnet, the Vigor router will serve for IP routing to help hosts in the public subnet to communicate with other public hosts or servers outside. Therefore, the router should be set as the gateway for public hosts. Vigor2110 Series User’s Guide...
Page 52: General Setup
1st IP Address (Default: 192.168.1.1). Type in an address code that determines the size of the network. 1st Subnet Mask (Default: 255.255.255.0/ 24) For IP Routing Usage Click Enable to invoke this function. The default setting is Disable. Vigor2110 Series User’s Guide...
Page 53 1st Subnet - Select the router to change the RIP information of the 1st subnet with neighboring routers. 2nd Subnet - Select the router to change the RIP information of the 2nd subnet with neighboring routers. Vigor2110 Series User’s Guide...
Page 54 DNS Server. If your ISP does not provide it, the router will automatically apply default secondary DNS Server IP address: 194.98.0.1 to this field. The default DNS Server IP address can be found via Online Status: Vigor2110 Series User’s Guide...
Page 55: Nat
192.168.1.0/24 subnet for the router. As stated before, the NAT facility can map one or more IP addresses and/or service ports into different specified services. In other words, the NAT function can be achieved by using port mapping methods. Below shows the menu items for NAT. Vigor2110 Series User’s Guide...
Page 56: Port Redirection
The port redirection can only apply to incoming traffic. To use this function, please go to NAT page and choose Port Redirection web page. The Port Redirection Table provides 20 port-mapping entries for the internal hosts. Vigor2110 Series User’s Guide...
Page 57 Note that the router has its own built-in services (servers) such as Telnet, HTTP and FTP etc. Since the common port numbers of these services (servers) are all the same, you may need to reset the router in order to avoid confliction. Vigor2110 Series User’s Guide...
Page 58: Dmz Host
Netmeeting or Internet Games etc. The security properties of NAT are somewhat bypassed if you set up DMZ host. We suggest you to add additional filter rules or a secondary firewall. Click DMZ Host to open the following page: Vigor2110 Series User’s Guide...
Page 59 LAN network. Select one private IP address in the list to be the DMZ host. When you have selected one private IP from the above dialog, the IP address will be shown on the following screen. Click OK to save the setting. Vigor2110 Series User’s Guide...
Page 60: Open Ports
Inactive or Active state. To add or edit port settings, click one index number on the page. The index entry setup page will pop up. In each index entry, you can specify 10 port ranges for diverse services. Vigor2110 Series User’s Guide...
Page 61 Specify the transport layer protocol. It could be TCP, UDP, or ----- Protocol (none) for selection. Specify the starting port number of the service offered by the local Start Port host. Specify the ending port number of the service offered by the local End Port host. Vigor2110 Series User’s Guide...
Page 62: Applications
Click the number below Index to access into the setting Index page of DDNS setup to set account(s). Display the domain name that you set on the setting page Domain Name of DDNS setup. Display if this account is active or inactive. Active Vigor2110 Series User’s Guide...
Page 63 Delete a Dynamic DNS Account In the DDNS setup menu, click the Index number you want to delete and then push Clear All button to delete the account. Vigor2110 Series User’s Guide...
Page 64: Upnp
NAT router. The application will also learn the external IP address and configure port mappings on the router. Subsequently, such a facility forwards packets from the external ports of the router to the internal ports used by the application. Vigor2110 Series User’s Guide...
Page 65: Voip
“userinfo” includes the user field, the password field and the @ sign following them. This is very similar to a URL so some may call it “SIP URL”. SIP supports peer-to-peer direct calling and also calling via a SIP proxy server (a role similar to the gatekeeper in H.323 networks), Vigor2110 Series User’s Guide...
Page 66 SIP Registrar. Peer-to-Peer Before calling, you have to know your friend’s IP Address. The Vigor VoIP Routers will build connection between each other. Vigor2110 Series User’s Guide...
Page 67: Dialplan
“speed-dial” Phone Number. There are total 60 index entries in the phonebook for you to store all your friends and family members’ SIP addresses. Loop through and Backup Phone Number will be displayed if you are using Vigor2110Vn for setting the phone book. Vigor2110 Series User’s Guide...
Page 68 Choose one of the SIP accounts for this profile to dial out. It is Dial Out Account useful for both sides (caller and callee) that registered to different SIP Registrar servers. If caller and callee do not use Vigor2110 Series User’s Guide...
Page 69 And when the VoIP phone is switched into the PSTN phone, the telecom co. might charge you for the connection fee. Please type in backup phone number (PSTN) for this VoIP phone setting. Vigor2110 Series User’s Guide...
Page 70 VoIP interface. Take the above picture (Prefix Table Setup web page) as an example, the prefix number of 03 will be replaced by 8863. For example: dial number of “031111111” Vigor2110 Series User’s Guide...
Page 71 Choose the one that you want to enable the prefix number Route settings from the saved SIP accounts. Please set up one SIP account first to make this interface available. Call barring is used to block phone calls coming from the one that is not welcomed. Vigor2110 Series User’s Guide...
Page 72 Unknown Domain or Block IP Address. Simply click the relational links to open the web page. For Block Anonymous – this function can block the incoming calls without caller ID on the interface (Phone port) specified in the following window. Vigor2110 Series User’s Guide...
Page 73 This page allows you to process incoming or outgoing phone calls by regional. Default values (common used in most areas) will be shown on this web page. You can change the number based on the region that the router is placed. Vigor2110 Series User’s Guide...
Page 74 [Deact] Dial the number typed in this field to block all the incoming Block IP Calls [Act] calls from IP address. Dial the number typed in this field to release this function. Block IP Calls [Deact] Vigor2110 Series User’s Guide...
Page 75 PSTN number for dialing without passing through Internet. Please type the number in the field of phone number for PSTN relay. Then, check the Enable box to make the PSTN number available for dial whenever you need. Vigor2110 Series User’s Guide...
Page 76: Sip Accounts
Type in the IP address or domain of the STUN server. STUN Server Type in the gateway IP address. External IP The default value is 150 (sec). It is useful for a Nortel server SIP PING interval NAT Traversal Support. Vigor2110 Series User’s Guide...
Page 77 (e.g., nat.draytel.org:5065) Check this box to make the proxy acting as outbound proxy. Act as Outbound Proxy The caller-ID that you want to be displayed on your friend’s Display Name screen. Vigor2110 Series User’s Guide...
Page 78 G.729A/B; it occupies little bandwidth while maintaining good voice quality. If your upstream speed is only 64Kbps, do not use G.711 codec. It is better for you to have at least 256Kbps upstream if you would like to use G.711. Vigor2110 Series User’s Guide...
Page 79 This function can detect if the voice on both sides is active or Voice Active Detector not. If not, the router will do something to save the bandwidth for other using. Click On to invoke this function; click off to close the function. Vigor2110 Series User’s Guide...
Page 80: Phone Settings
IP of local router), you can check this box to solve this problem. Dynamic RTP Port Start - Specifies the start port for RTP stream. The default value is 10050. Dynamic RTP Port End - Specifies the end port for RTP stream. The default value is 15000. Vigor2110 Series User’s Guide...
Page 81 Check the box to enable T.38 FAX Relay function. T.38 Fax Function Error Correction Mode – Choose the mode for error correction. Vigor2110 Series User’s Guide...
Page 82 ID type automatically. Or you can adjust tone settings manually if you choose User Defined. TOn1, TOff1, TOn2 and TOff2 mean the cadence of the tone pattern. TOn1 and TOn2 represent sound-on; TOff1 and TOff2 represent the sound-off. Vigor2110 Series User’s Guide...
Page 83 If you cannot find out a suitable one, please choose User Defined and fill out the corresponding values for dial tone, ringing tone, busy tone, congestion tone by yourself for VoIP phone. Also, you can specify each field for your necessity. It is Vigor2110 Series User’s Guide...
Page 84 DTMF tone and transfer it into SIP form. Then it will be sent to the remote end with SIP message. Payload Type (rfc2833) - Choose a number from 96 to 127, the default value was 101. This setting is available for the OutBand (RFC2833) mode. Vigor2110 Series User’s Guide...
Page 85: Status
The present in-call or out-call peer ID (the format may be IP or PeerID Domain). The format is represented as hours:minutes:seconds. Elapse Total number of transmitted voice packets during this Tx Pkts connection session. Total number of received voice packets during this connection Rx Pkts session. Vigor2110 Series User’s Guide...
Page 86: Wireless Lan
Point (AP) connecting to lots of wireless clients or Stations (STA). All the STAs will share the same Internet connection via Vigor wireless router. The General Settings will set up the information of this wireless network, including its SSID as identification, located channel etc. Vigor2110 Series User’s Guide...
Page 87 MAC addresses to isolate users’ access from wired LAN. Manage Wireless Stations - Station List will display all the station in your wireless network and the status of their connection. Below shows the menu items for Wireless LAN. Vigor2110 Series User’s Guide...
Page 88: General Setup
Means the identification of the wireless LAN. SSID can be SSID any text numbers or various special characters. The default SSID is "DrayTek". We suggest you to change it. Means the channel of frequency of the wireless LAN. The Channel default channel is 6.
Page 89 Vigor wireless router while site surveying. The system allows you to set four sets of SSID for different usage. In default, the first set of SSID will be enabled. You can hide it for your necessity. Vigor2110 Series User’s Guide...
Page 90: Security
PSK. WPA2/PSK-Accepts only WPA2 clients and the encryption key should be entered in PSK. Mixed (WPA+ WPA2)/PSK - Accepts WPA and WPA2 clients simultaneously and the encryption key should be entered in PSK. Vigor2110 Series User’s Guide...
Page 91: Access Control
MAC address that has been configured can access the wireless LAN interface. By clicking the Access Control, a new web page will appear, as depicted below, so that you could edit the clients' MAC addresses to control their access rights. Vigor2110 Series User’s Guide...
Page 92 Delete Edit the selected MAC address in the list. Edit Give up the access control set up. Cancel Click it to save the access control list. Clean all entries in the MAC address list. Clear All Vigor2110 Series User’s Guide...
Page 93: Station List
There is a code summary below for explanation. For convenient Access Control, you can select a WLAN station and click Add to Access Control below. Click this button to refresh the status of station list. Refresh Click this button to add current typed MAC address into Access Control. Vigor2110 Series User’s Guide...
Page 94: Usb Application
FTP sessions. The router allows up to 6 FTP sessions connecting to USB storage disk at one time. Default Charset - At present, Vigor router supports three types of character sets: default, GB2312 and BIG5. Vigor2110 Series User’s Guide...
Page 95: Usb User Management
USB diskette must type the same username and password configured in this page. Before adding or modifying settings in this page, please insert a USB diskette first. Otherwise, an error message will appear to warn you. Click index number to access into configuration page. Vigor2110 Series User’s Guide...
Page 96 Only “/” can be used in such case. You can click to open the following dialog to add any new folder which can be specified as the Home Folder. Vigor2110 Series User’s Guide...
Page 97 Directory –Check the items (List, Create and Remove) for such profile. Before you click OK, you have to insert a USB diskette into the USB interface of the Vigor router. Otherwise, you cannot save the configuration. Vigor2110 Series User’s Guide...
Page 98: File Explorer
Click this icon to add a new folder. Create Display current folder. Current Path Click this button to upload the selected file to the USB diskette. Upload The uploaded file in the USB diskette can be shared for other user through FTP. Vigor2110 Series User’s Guide...
Page 99: Usb Disk Status
It displays the IP address of the user’s host which connecting to IP Address the FTP server. When you insert USB diskette into the Vigor router, the system will start to find out such device within several seconds. Vigor2110 Series User’s Guide...
Page 100: System Maintenance
Display the current status of DHCP server of the LAN DHCP Server interface. Display the assigned IP address of the primary DNS. WAN------- Display current connection status. Link Status Display the MAC address of the WAN Interface. MAC Address Vigor2110 Series User’s Guide...
Page 101: User Password
Type in new password in this field. New Password Type in the new password again. Confirm Password When you click OK, the login window will appear. Please use the new password to access into the web configurator again. Vigor2110 Series User’s Guide...
Page 102: Time And Date
The Web Configurator may be used to restart your router for using current configuration. Click Reboot System from System Maintenance to open the following page. Click Reboot Now. The router will take 5 seconds to reboot the system. Vigor2110 Series User’s Guide...
Page 103: Diagnostics
DHCP assigned IP address for it. It displays the leased time of the specified PC. Leased Time It displays the host ID name of the specified PC. HOST ID Click it to reload the page. Refresh Vigor2110 Series User’s Guide...
Page 104: Traffic Graph
Type in the IP address of the Host/IP that you want to ping. IP Address Click this button to start the ping work. The result will be displayed on the screen. Click this link to remove the result on the window. Clear Vigor2110 Series User’s Guide...
Page 105: Trace Route
Use the drop down list to choose the interface that you want to ping Protocol through. It indicates the IP address of the host. Host/IP Address Click this button to start route tracing work. Click this link to remove the result on the window. Clear Vigor2110 Series User’s Guide...
Page 106 This page is left blank. Vigor2110 Series User’s Guide...
Page 107: Admin Mode Operation
Hence, the NIC has reserved certain addresses that will never be registered publicly. These are known as private IP addresses, and are listed in the following ranges: Vigor2110 Series User’s Guide...
Page 108 Then a session will be created. Your user ID and password is authenticated via PAP or CHAP with RADIUS authentication system. And your IP address, DNS server, and other related information will usually be assigned by your ISP. Below shows the menu items for Internet Access. Vigor2110 Series User’s Guide...
Page 109: Pppoe
TTL (Time to Live) – Displays value for your reference. TTL value is set by telnet command. Check this box to invoke the Bridge function for WAN connection. Enable Bridge Mode The router will work as a bridge modem. Vigor2110 Series User’s Guide...
Page 110 PPP Authentication – Select PAP only or PAP or CHAP for PPP. Index (1-15) in Schedule Setup - You can type in four sets of time schedule for your request. All the schedules can be set previously in Vigor2110 Series User’s Guide...
Page 111 You can set up to 8 public IP addresses other than the current one you are using. Notice that this setting is available for WAN1 only. Fixed IP – Click Yes to use this function and type in a fixed IP address in the box of Fixed IP Address. Vigor2110 Series User’s Guide...
Page 112: Static Or Dynamic Ip
If you have a public subnet, you could assign an IP address or many IP address to the WAN interface. To use Static or Dynamic IP as the accessing protocol of the internet, please choose Static or Dynamic IP mode from Internet Access menu. The following web page will be shown. Vigor2110 Series User’s Guide...
Page 113 IP address in this field for pinging. TTL (Time to Live) – Displays value for your reference. TTL value is set by telnet command. Routing Information Protocol is abbreviated as RIP（RFC1058） RIP Protocol specifying how routers exchange routing tables information. Click Vigor2110 Series User’s Guide...
Page 114 PPP Authentication – Select PAP only or PAP or CHAP for PPP. Index (1-15) in Schedule Setup - You can type in four sets of time schedule for your request. All the schedules can be set previously in Vigor2110 Series User’s Guide...
Page 115 IP Address: Type the IP address. Subnet Mask: Type the subnet mask. Gateway IP Address: Type the gateway IP address. Default MAC Address : Click this radio button to use default MAC address for the router. Vigor2110 Series User’s Guide...
Page 116 MAC Address field. Type in the primary IP address for the router if you want to use DNS Server IP Static IP mode. If necessary, type in secondary IP address for Address necessity in the future. Vigor2110 Series User’s Guide...
Page 117: Pptp/L2Tp
WAN Backup Setup please Enable the Dial Backup Mode to perform file backup via USB device. After choosing Enable, please click the 3G USB Modem link to access into the following page for configuring detailed settings. Vigor2110 Series User’s Guide...
Page 118 In this case, you can fill in this IP address in the Fixed IP field. Please contact your ISP before you want to use this function. Click Yes to use this function and type in a fixed IP address in the box. Vigor2110 Series User’s Guide...
Page 119: Lan
IP address. As a part of the public subnet, the Vigor router will serve for IP routing to help hosts in the public subnet to communicate with other public hosts or servers outside. Therefore, the router should be set as the gateway for public hosts. Vigor2110 Series User’s Guide...
Page 120 You can group local hosts by physical ports and create up to 4 virtual LANs. To manage the communication between different groups, please set up rules in Virtual LAN (VLAN) function and the rate of each. Vigor2110 Series User’s Guide...
Page 121: General Setup
IP Address (Default: 192.168.2.1/ 24) An address code that determines the size of the network. Subnet Mask (Default: 255.255.255.0/ 24) You can configure the router to serve as a DHCP server for the 2nd DHCP Server subnet. Vigor2110 Series User’s Guide...
Page 122 IP settings to any local user configured as a DHCP client. It is highly recommended that you leave the router enabled as a DHCP server if you do not have a DHCP server for your network. Vigor2110 Series User’s Guide...
Page 123 If the IP address of a domain name is already in the DNS cache, the router will resolve the domain name immediately. Otherwise, the router forwards the DNS query packet to the external DNS server by establishing a WAN (e.g. DSL/Cable) connection. Vigor2110 Series User’s Guide...
Page 124: Static Route
Main Router 192.168.1.1 as the default gateway for the Router A 192.168.1.2. Before setting Static Route, user A cannot talk to user B for Router A can only forward recognized packets to its default gateway Main Router. Vigor2110 Series User’s Guide...
Page 125 Click the LAN - Static Route and click on the Index Number 1. Check the Enable box. Please add a static route as shown below, which regulates all packets destined to 192.168.10.0 will be forwarded to 192.168.1.2. Click OK. Vigor2110 Series User’s Guide...
Page 126 Return to Static Route Setup page. Click on another Index Number to add another static route as show below, which regulates all packets destined to 211.100.88.0 will be forwarded to 192.168.1.3. Go to Diagnostics and choose Routing Table to verify current routing table. Vigor2110 Series User’s Guide...
Page 127: Vlan
P3 and P4. After checking the box to enable VLAN function, you will check the table according to the needs as shown below. To remove VLAN, uncheck the needed box and click OK to save the results. Vigor2110 Series User’s Guide...
Page 128: Bind Ip To Mac
It is used to refresh the ARP table. When there is one new PC Refresh added to the LAN, you can click this link to obtain the newly ARP table information. It displays a list 1for the IP bind to MAC information. IP Bind List Vigor2110 Series User’s Guide...
Page 129: Nat
IP address/domain name are recognized by all users. Since the server is actually located inside the LAN, the network well protected by NAT of the router, and identified by its private IP address/port, the goal of Port Redirection function is to Vigor2110 Series User’s Guide...
Page 130 To use this function, please go to NAT page and choose Port Redirection web page. The Port Redirection Table provides 20 port-mapping entries for the internal hosts. Press any number under Index to access into next page for configuring port redirection. Vigor2110 Series User’s Guide...
Page 131 80 to avoid conflict, such as 8080. This can be set in the System Maintenance >>Management Setup. You then will access the admin screen of by suffixing the IP address with 8080, e.g., http://192.168.1.1:8080 instead of port 80. Vigor2110 Series User’s Guide...
Page 132: Dmz Host
LAN. Regular web surfing and other such Internet activities from other clients will continue to work without inappropriate interruption. DMZ Host allows a defined internal user to be totally exposed to the Internet, which usually helps some special applications such as Netmeeting or Internet Games etc. Vigor2110 Series User’s Guide...
Page 133 If you previously have set up WAN Alias for PPPoE or Static or Dynamic IP mode, you will find them in Aux. WAN IP for your selection. Check to enable the DMZ Host function. Enable Enter the private IP address of the DMZ host, or click Choose PC to Private IP select one. Vigor2110 Series User’s Guide...
Page 134: Open Ports
Click Open Ports to open the following page: Indicate the relative number for the particular entry that you want to Index offer service in a local host. You should click the appropriate index number to edit or clear the corresponding entry. Vigor2110 Series User’s Guide...
Page 135: Firewall
Specify the transport layer protocol. It could be TCP, UDP, or ----- Protocol (none) for selection. Specify the starting port number of the service offered by the local Start Port host. Specify the ending port number of the service offered by the local End Port host. Vigor2110 Series User’s Guide...
Page 136 It will check packets according to the filter rules. If legal, the packet will pass the router. The following illustrations are flow charts explaining how router will treat incoming traffic and outgoing traffic respectively. Vigor2110 Series User’s Guide...
Page 137 4. Port Scan attack 12. Tear drop attack 5. IP options 13. Ping of Death attack 6. Land attack 14. ICMP fragment 7. Smurf attack 15. Unknown protocol 8. Trace route Below shows the menu items for Firewall. Vigor2110 Series User’s Guide...
Page 138: General Setup
If the firewall system does not have any response (pass or block) for these packets, such as no response coming from web content filter, then the router’s firewall will block the packets directly. Vigor2110 Series User’s Guide...
Page 139 Choose one of the QoS rules to be applied as firewall rule. Quality of Service For detailed information of setting QoS, please refer to the related section later. Choose the WAN interface for applying Load-Balance Policy. Load-Balance Policy Vigor2110 Series User’s Guide...
Page 140 ANSI 1252 Latin I. If you do not choose any codepage, no decoding job of URL will be processed. Please use the drop-down list to choose a codepage. If you do not have any idea of choosing suitable codepage, Vigor2110 Series User’s Guide...
Page 141 (0~65535). The more the value is, the better the performance will be. However, if the network is not stable, small value will be proper. Session timeout – Setting timeout for sessions can make the best utilization of network resources. Vigor2110 Series User’s Guide...
Page 142: Filter Setup
Use Up or Down link to move the order of the filter rules. Move Up/Down Set the link to the next filter set to be executed after the current Next Filter Set filter run. Do not make a loop with many filter sets. Vigor2110 Series User’s Guide...
Page 143 It is for Data Filter only. For the Call Filter, this setting is not available since Call Filter is only applied to outgoing traffic. Click Edit to access into the following dialog to choose the Source/Destination IP source/destination IP or IP ranges. Vigor2110 Series User’s Guide...
Page 144 To set the service type manually, please choose User defined as the Service Type and type them in this dialog. In addition, if you want to use the service type from defined groups or objects, please choose Group and Objects as the Service Type. Vigor2110 Series User’s Guide...
Page 145 The number typed here is the total sessions of the packets that Sessions Control do not match the filter rule configured in this page. The default setting is 12000. Vigor2110 Series User’s Guide...
Page 146 Please set at least one profile for anti-virus in CSM>> Web Content Filter web page first. Or choose [Create New] from the drop down list in this page to create a new profile. For troubleshooting needs, you can specify to record information Vigor2110 Series User’s Guide...
Page 147 Syslog. From Codepage Information of Setup dialog, you will see the recommended codepage listed on the dialog box. Window size – It determines the size of TCP protocol (0~65535). The more the value is, the better the performance Vigor2110 Series User’s Guide...
Page 148 TCP protocol only; session timeout is configured for the data flow which matched with the firewall rule. DrayTek Banner – Please uncheck this box and the following screen will not be shown for the unreachable web page. The default setting is Enabled.
Page 149 Each filter set is composed by 7 filter rules, which can be further defined. After that, in General Setup you may specify one set for call filter and one set for data filter to execute first. Vigor2110 Series User’s Guide...
Page 150: Dos Defense
Timeout. The default setting for threshold and timeout are 150 packets per second and 10 seconds, respectively. Check the box to activate the ICMP flood defense function. Enable ICMP flood Similar to the UDP flood defense function, once if the defense Vigor2110 Series User’s Guide...
Page 151 ICMP datagrams (packets) that exceed the maximum length. To avoid this type of attack, the Vigor router is designed to be capable of discarding any fragmented ICMP packets with a length greater than 1024 octets. Vigor2110 Series User’s Guide...
Page 152 All the warning messages related to DoS Defense will be sent to user and user can review it through Syslog daemon. Look for the keyword DoS in the message, followed by a name to indicate what kind of attacks is detected. Vigor2110 Series User’s Guide...
Page 153: Objects Settings
IPs in the same department can be defined with an IP object (a range of IP address). You can set up to 192 sets of IP Objects with different conditions. Clear all profiles. Set to Factory Default Click the number under Index column for settings in detail. Vigor2110 Series User’s Guide...
Page 154 Type the MAC address of the network card which will be MAC Address controlled. Type the start IP address for Single Address type. Start IP Address Type the end IP address if the Range Address type is selected. End IP Address Vigor2110 Series User’s Guide...
Page 155: Ip Group
Below is an example of IP objects settings. This page allows you to bind several IP objects into one IP group. Clear all profiles. Set to Factory Default Click the number under Index column for settings in detail. Vigor2110 Series User’s Guide...
Page 156 All the available IP objects with the specified interface chosen Available IP Objects above will be shown in this box. Click >> button to add the selected IP objects in this box. Selected IP Objects Vigor2110 Series User’s Guide...
Page 157: Service Type Object
Type a name for this profile. Name Specify the protocol(s) which this profile will apply to. Protocol Source Port and the Destination Port column are available for Source/Destination Port TCP/UDP protocol. It can be ignored for other protocols. The Vigor2110 Series User’s Guide...
Page 158: Service Type Group
(<) – the port number less than this value is available for this profile. Below is an example of service type objects settings. This page allows you to bind several service types into one group. Clear all profiles. Set to Factory Default Vigor2110 Series User’s Guide...
Page 159: Keyword Object
Click >> button to add the selected IP objects in this box. Selected Service Type Objects You can set 200 keyword object profiles for choosing as black /white list in CSM >>URL Web Content Filter Profile. Vigor2110 Series User’s Guide...
Page 160: Keyword Group
Firewall settings. This page allows you to bind several keyword objects into one group. The keyword groups set here will be chosen as black /white list in CSM >>URL Web Content Filter Profile. Vigor2110 Series User’s Guide...
Page 161: File Extension Object
Profile 1 with name of “default” is the default profile, some files with the file extensions specified in this profile will be ignored and not be scanned by Vigor router. Clear all profiles. Set to Factory Default Vigor2110 Series User’s Guide...
Page 162 Type a name for this profile. Profile Name Type a name for such profile and check all the items of file extension that will be processed in the router. Finally, click OK to save this profile. Vigor2110 Series User’s Guide...
Page 163: Csm Profile
URL address requested (e.g.www.bbc.co.uk) will be checked against our server database. This database is updated as frequent as daily by a global team of Internet researchers. The server will look up the URL and return a category to your router. Your Vigor2110 Series User’s Guide...
Page 164: App Enforcement Profile
Click the number under Index column for settings in detail. There are three tabs IM, P2P, and Misc displayed on this page. Each tab will bring out different items that you can choose to disallow people using. Vigor2110 Series User’s Guide...
Page 165 Clear All The profiles configured here can be applied in the Firewall>>General Setup and Firewall>>Filter Setup pages as the standard for the host(s) to follow. The items categorized under IM ----- The items categorized under Misc ----- Vigor2110 Series User’s Guide...
Page 166: Url Content Filter Profile
Click CSM and click URL Content Filter Profile to open the profile setting page. You can set eight profiles as URL content filter. Simply click the index number under Profile to open the following web page. Vigor2110 Series User’s Guide...
Page 167 URL Access Control and Web Feature below, such function can determine the priority for the actions executed. For this one, the router will process the packages with the conditions set below for web feature first, then URL second. Vigor2110 Series User’s Guide...
Page 168 After specifying keywords, the Vigor router will decline the connection request to the website whose URL string matched to any user-defined keyword. It should be noticed that the more simplified the blocking keyword list is, the more efficiently the Vigor router performs. Vigor2110 Series User’s Guide...
Page 169 Upload – Check the box to reject any file upload job. File Extension Profile – Choose one of the profiles that you configured in Object Setting>> File Extension Objects previously for passing or blocking the file downloading. Vigor2110 Series User’s Guide...
Page 170: Web Content Filter Profile
Note: If you have used Service Activation Wizard to activate WCF service, you can skip this section. WCF adopts the mechanism developed and offered by certain service provider (e.g., DrayTek). No matter activating WCF feature or getting a new license for web content filter, you have to click Activate to satisfy your request.
Page 171 Click it to open http://myvigor.draytek.com for searching Find more another qualified and suitable server. Click this link to do the verification. Test a site to verify whether it is categorized Click this link to retrieve the factory settings.
Page 172 Block - restrict accessing into the corresponding webpage with the characters listed on Group/Object Selections. If the web pages do not match with the specified feature set here, they will be processed with the categories listed on the box below. Vigor2110 Series User’s Guide...
Page 173: Bandwidth Management
To solve the problem, you can use limit session to limit the session procession for specified Hosts. In the Bandwidth Management menu, click Sessions Limit to open the web page. Vigor2110 Series User’s Guide...
Page 174 Defines the available session number for P2P application. Maximum P2P Sessions Adds the specific session limitation onto the list above. Vigor2110 Series User’s Guide...
Page 175: Bandwidth Limit
LAN>>General Setup. Click this button to close the function of limit bandwidth. Disable Define the default speed of the upstream for each computer in Default TX limit LAN. Vigor2110 Series User’s Guide...
Page 176: Quality Of Service
(or in another term “dropped”) from an overflowing queue, packets of sensitive applications mentioned above might be the ones to drop off. How this will affect application performance? There are two components within Primary configuration of QoS deployment: Vigor2110 Series User’s Guide...
Page 177 SLA among different DS domain owners. It’s not easy to achieve deterministic and consistent high-priority QoS traffic throughout the whole network with merely Vigor router’s effort. In the Bandwidth Management menu, click Quality of Service to open the web page. Vigor2110 Series User’s Guide...
Page 178 There are four queues allowed for QoS control. The first three (Class 1 to Class 3) class rules can be adjusted for your necessity. Yet, the last one is reserved for the packets which are not suitable for the user-defined class rules. Vigor2110 Series User’s Guide...
Page 179 TCP ACK, you can check this box to push ACK of upload faster to speed the network traffic. Limited_bandwidth Ratio The ratio typed here is reserved for limited bandwidth of UDP Vigor2110 Series User’s Guide...
Page 180 Edit link of that one. After you click the Edit link, you will see the following page. Now you can define the name for that Class. In this case, “Test” is used as the name of Class Index #1. Vigor2110 Series User’s Guide...
Page 181 By the way, you can set up to 20 rules for one Class. If you want to edit an existed rule, please select the radio button of that one and click Edit to open the rule edit page for modification. Vigor2110 Series User’s Guide...
Page 182 To add a new service type, edit or delete an existed service type, please click the Edit link under Service Type field. After you click the Edit link, you will see the following page. Vigor2110 Series User’s Guide...
Page 183: App Qos
APP QoS employs the function of APP Enforcement to detect several types of software in application layer. By combining the function of QoS, Vigor router can perform the bandwidth management for the application of VoIP, Streaming, IM and P2P. Vigor2110 Series User’s Guide...
Page 184 VoIP packets will be the first to be sent out and P2P packets will be the last to be sent out. There are four applications (VoIP, Streaming, IM and P2P) Enable (for Application) which can be specified with different QoS Class. Vigor2110 Series User’s Guide...
Page 185: Applications
Check this box to enable DDNS function. Enable Dynamic DNS Setup Clear all profiles and recover to factory settings. Set to Factory Default Set the time for the router to perform auto update for Auto-Update interval DDNS service. Vigor2110 Series User’s Guide...
Page 186 Disable the Function and Clear all Dynamic DNS Accounts In the DDNS setup menu, uncheck Enable Dynamic DNS Setup, and push Clear All button to disable the function and clear all accounts from the router. Vigor2110 Series User’s Guide...
Page 187: Schedule
You can set up to 15 schedules. Then you can apply them to your Internet Access or VPN and Remote Access >> LAN-to-LAN settings. To add a schedule, please click any index, say Index No. 1. The detailed settings of the call schedule with index 1 are shown below. Vigor2110 Series User’s Guide...
Page 188 Suppose you want to control the PPPoE Internet access connection to be always on (Force On) from 9:00 to 18:00 for whole week. Other time the Internet access connection should be disconnected (Force Down). Office Hour: (Force On) Mon - Sun 9:00 am 6:00 pm Vigor2110 Series User’s Guide...
Page 189: Radius
The RADIUS server and client share a secret that is used to Shared Secret authenticate the messages sent between them. Both sides must be configured to use the same shared secret. Re-type the Shared Secret for confirmation. Confirm Shared Secret Vigor2110 Series User’s Guide...
Page 190: Upnp
NAT router. The application will also learn the external IP address and configure port mappings on the router. Subsequently, such a facility forwards packets from the external ports of the router to the internal ports used by the application. Vigor2110 Series User’s Guide...
Page 191 Non-privileged users can control some router functions, including removing and adding port mappings. The UPnP function dynamically adds port mappings on behalf of some UPnP-aware applications. When the applications terminate abnormally, these mappings may not be removed. Vigor2110 Series User’s Guide...
Page 192: Igmp
Click this link to renew the working multicast group status. Refresh If you check Enable IGMP Proxy, you will get the following page. All the multicast groups will be listed and all the LAN ports (P1 to P4) are available for use. Vigor2110 Series User’s Guide...
Page 193: Wake On Lan
Type any one of the MAC address of the bound PCs. MAC Address Click this button to wake up the selected IP. See the following Wake Up figure. The result will be shown on the box. Vigor2110 Series User’s Guide...
Page 194: Vpn And Remote Access
LAN, you should disable the VPN service of Vigor Router to allow VPN tunnel pass through, as well as the appropriate NAT settings, such as DMZ or open port. This submenu only applies to PPP-related VPN connections, such as PPTP, L2TP, L2TP over IPSec. Vigor2110 Series User’s Guide...
Page 195: Ipsec General Setup
Eventually to set up a secure tunnel for IKE Phase 2. Phase 2: negotiation IPSec security methods including Authentication Header (AH) or Encapsulating Security Payload (ESP) for the following IKE exchange and mutual examination of the secure tunnel establishment. Vigor2110 Series User’s Guide...
Page 196 By default, this option is active. High - Encapsulating Security Payload (ESP) means payload (data) will be encrypted and authenticated. You may select encryption algorithm from Data Encryption Standard (DES), Triple DES (3DES), and AES. Vigor2110 Series User’s Guide...
Page 197: Ipsec Peer Identity
Click each index to edit one peer digital certificate. There are three security levels of digital signature authentication: Fill each necessary field to authenticate the remote peer. The following explanation will guide you to fill all the necessary fields. Vigor2110 Series User’s Guide...
Page 198: Remote Dial-In User
L2TP by itself or over IPSec) and corresponding security methods, etc. The router provides 32 access accounts for dial-in users. Besides, you can extend the user accounts to the RADIUS server through the built-in RADIUS client function. The following figure shows the summary table. Vigor2110 Series User’s Guide...
Page 199 Click each index to edit one remote user profile. Each Dial-In Type requires you to fill the different corresponding fields on the right. If the fields gray out, it means you may leave it untouched. The following explanation will guide you to fill all the necessary fields. Vigor2110 Series User’s Guide...
Page 200 Check the checkbox-You can specify the IP address of the remote dial-in user, ISDN number or peer ID (used in IKE aggressive mode). Uncheck the checkbox-This means the connection type you select above will apply the authentication methods and Vigor2110 Series User’s Guide...
Page 201 Triple DES (3DES), and AES. Local ID - Specify a local ID to be used for Dial-in setting in the LAN-to-LAN Profile setup. This item is optional and can be used only in IKE aggressive mode. Vigor2110 Series User’s Guide...
Page 202: Lan To Lan
4 subgroups. If the fields gray out, it means you may leave it untouched. The following explanations will guide you to fill all the necessary fields. For the web page is too long, we divide the page into several sections for explanation. Vigor2110 Series User’s Guide...
Page 203 Pass – click it to have an inquiry for data transmission between Netbios Naming Packet the hosts located on both sides of VPN Tunnel while connecting. Block – When there is conflict occurred between the hosts on Vigor2110 Series User’s Guide...
Page 204 Internet. You can select to use L2TP alone or with IPSec. Select from below: None: Do not apply the IPSec policy. Accordingly, the VPN connection employed the L2TP without IPSec policy can be viewed as one pure L2TP connection. Vigor2110 Series User’s Guide...
Page 205 AES with Authentication-Use AES encryption algorithm and apply MD5 or SHA-1 authentication algorithm. Specify mode, proposal and key life of each IKE phase, Advanced Gateway, etc. The window of advance setup is shown as below: Vigor2110 Series User’s Guide...
Page 206 The length of the ID is limited to 47 characters. Index (1-15) in Schedule - Enter the index of schedule profiles to control the call barring according to the preconfigured schedules. Refer to section 3.5.2 Schedule for detailed configuration. Vigor2110 Series User’s Guide...
Page 207 ID (should be the same with the ID setting in dial-in type) Gateway by checking the box. Also, you should further specify the corresponding security methods on the right side. If you uncheck the checkbox, the connection type you select Vigor2110 Series User’s Guide...
Page 208 Network IP Address/Remote Network Mask through the VPN Remote Network Mask connection. For IPSec, this is the destination clients IDs of phase 2 quick mode. Local Network IP / Local Display the local network IP and mask for TCP / IP Vigor2110 Series User’s Guide...
Page 209: Connection Management
Tool and clicking Dial button. Click this button to execute dial out function. Dial Choose the time for refresh the dial information among 5, 10, Refresh Seconds and 30. Click this button to refresh the whole connection status. Refresh Vigor2110 Series User’s Guide...
Page 210: Certificate Management
Remember to adjust the time of Vigor router before using the certificate so that you can get the correct valid period of certificate. Below shows the menu items for Certificate Management. Click this button to open Generate Certificate Request Generate window. Vigor2110 Series User’s Guide...
Page 211 Click this button to refresh the information listed below. Refresh Click this button to view the detailed settings for certificate View request. After clicking Generate, the generated information will be displayed on the window below: Vigor2110 Series User’s Guide...
Page 212: Trusted Ca Certificate
For viewing each trusted CA certificate, click View to open the certificate detail information window. If you want to delete a CA certificate, choose the one and click Delete to remove all the certificate information. Vigor2110 Series User’s Guide...
Page 213: Certificate Backup
The more bandwidth a codec uses the better the voice quality, however the codec used must be appropriate for your Internet bandwidth. Usually there will be two types of calling scenario, as illustrated below: Vigor2110 Series User’s Guide...
Page 214 QoS Assurance assists to assign high priority to voice traffic via Internet. You will always have the required inbound and outbound bandwidth that is prioritized exclusively for Voice traffic over Internet but you just get your data a little slower and it is tolerable for data traffic. Vigor2110 Series User’s Guide...
Page 215: Dialplan
“speed-dial” Phone Number. There are total 60 index entries in the phonebook for you to store all your friends and family members’ SIP addresses. Loop through and Backup Phone Number will be displayed if you are using Vigor2110V for setting the phone book. Vigor2110 Series User’s Guide...
Page 216 And when the VoIP phone is switched into the PSTN phone, the telecom co. might charge you for the connection fee. Please type in backup phone number (PSTN) for this VoIP phone setting. Vigor2110 Series User’s Guide...
Page 217 VoIP interface. Take the above picture (Prefix Table Setup web page) as an example, the prefix number of 03 will replace 8863. For example: dial number of “88631111111” will be changed to “031111111” and sent to SIP server. Vigor2110 Series User’s Guide...
Page 218 Choose the one that you want to enable the prefix number Route settings from the saved SIP accounts. Please set up one SIP account first to make this interface available. Call barring is used to block phone calls coming from the one that is not welcomed. Vigor2110 Series User’s Guide...
Page 219 Unknown Domain or Block IP Address. Simply click the relational links to open the web page. For Block Anonymous – this function can block the incoming calls without caller ID on the interface (Phone port) specified in the following window. Such control also can be done based on preconfigured schedules. Vigor2110 Series User’s Guide...
Page 220 SIP accounts. Such control also can be done based on preconfigured schedules. For Block IP Address – this function can block incoming calls (through Phone port) coming from IP address. Such control also can be done based on preconfigured schedules. Vigor2110 Series User’s Guide...
Page 221 Do Not Disturb [Act] DND. Dial the number typed in this field to release the DND Do Not Distrub [Deact] function. Dial the number typed in this field to make your phone number Hide caller ID [Act] Vigor2110 Series User’s Guide...
Page 222 PSTN number for dialing without passing through Internet. Please type the number in the field of phone number for PSTN relay. Then, check the Enable box to make the PSTN number available for dial whenever you need. Vigor2110 Series User’s Guide...
Page 223: Sip Accounts
Type in the IP address or domain of the STUN server. STUN Server Type in the gateway IP address. External IP The default value is 150 (sec). It is useful for a Nortel server SIP PING interval NAT Traversal Support. Vigor2110 Series User’s Guide...
Page 224 (e.g., nat.draytel.org:5065) Check this box to make the proxy acting as outbound proxy. Act as Outbound Proxy The caller-ID that you want to be displayed on your friend’s Display Name screen. Vigor2110 Series User’s Guide...
Page 225 The default codec is G.729A/B; it occupies little bandwidth while maintaining good voice quality. If your upstream speed is only 64Kbps, do not use G.711 codec. It is better for you to have at least 256Kbps upstream if you would like to use G.711. Vigor2110 Series User’s Guide...
Page 226 This function can detect if the voice on both sides is active or Voice Active Detector not. If not, the router will do something to save the bandwidth for other using. Click On to invoke this function; click Off to close the function. Vigor2110 Series User’s Guide...
Page 227: Phone Settings
Dynamic RTP Port End - Specifies the end port for RTP stream. The default value is 15000. RTP TOS – It decides the level of VoIP package. Use the drop down list to choose any one of them. Vigor2110 Series User’s Guide...
Page 228 Check the box to enable the function. In the limited time that Session Timer you set in this field, if there is no response, the connecting call will be closed automatically. Vigor2110 Series User’s Guide...
Page 229 When the phone call connection succeeds, hang up the phone. The other two sides can communicate, then. You can set SIP accounts (up to six groups) on SIP Account Default SIP Account Vigor2110 Series User’s Guide...
Page 230 Congestion tone will be shown automatically on the page. If you cannot find out a suitable one, please choose User Defined and fill out the corresponding values for dial tone, ringing tone, busy tone, and congestion tone by yourself for VoIP phone. Vigor2110 Series User’s Guide...
Page 231 This function is very useful when the network traffic congestion occurs and it still can remain the accuracy of DTMF tone. SIP INFO- Choose this one then the Vigor will capture the Vigor2110 Series User’s Guide...
Page 232 DTMF tone and transfer it into SIP form. Then it will be sent to the remote end with SIP message. Payload Type (rfc2833) - Choose a number from 96 to 127, the default value was 101. This setting is available for the OutBand (RFC2833) mode. Vigor2110 Series User’s Guide...
Page 233: Status
Indicates the voice codec employed by present channel. Codec The present in-call or out-call peer ID (the format may be IP or PeerID Domain). The format is represented as hours:minutes:seconds. Elapse Total number of transmitted voice packets during this Tx Pkts Vigor2110 Series User’s Guide...
Page 234: Wireless Lan
Point (AP) connecting to lots of wireless clients or Stations (STA). All the STAs will share the same Internet connection via Vigor wireless router. The General Settings will set up the information of this wireless network, including its SSID as identification, located channel etc. Vigor2110 Series User’s Guide...
Page 235 Separate the Wireless and the Wired LAN- WLAN Isolation enables you to isolate your wireless LAN from wired LAN for either quarantine or limit access reasons. To isolate means neither of the parties can access each other. To elaborate an example for business use, you Vigor2110 Series User’s Guide...
Page 236 MAC addresses to isolate users’ access from wired LAN. Manage Wireless Stations - Station List will display all the station in your wireless network and the status of their connection. Below shows the menu items for Wireless LAN. Vigor2110 Series User’s Guide...
Page 237: General Setup
Check the box to enable wireless function. Enable Wireless LAN At present, the router can connect to Mixed (11b+11g), 11g Mode Only, 11b Only, Mixed (11g+11n), 11n Only and Mixed (11b+11g+11n) stations simultaneously. Simply choose Mix (11b+11g+11n) mode. Vigor2110 Series User’s Guide...
Page 238 Means the identification of the wireless LAN. SSID can be SSID any text numbers or various special characters. The default SSID is "Draytek. We suggest you to change it. LAN – Check this box to make the wireless clients (stations) Isolate with the same SSID cannot access wired PCs on LAN.
Page 239 It controls the data transmission rate through Rate Control wireless connection. Upload – Check Enable and type the transmitting rate for data upload. Default value is 30,000 kbps. Download – Type the transmitting rate for data download. Default value is 30,000 kbps. Vigor2110 Series User’s Guide...
Page 240: Security
PSK. The WPA encrypts each frame transmitted from the radio using the key, which either PSK (Pre-Shared Key) entered manually in this field below or automatically negotiated via Vigor2110 Series User’s Guide...
Page 241 Four keys can be entered here, but only one key can be selected at a time. The keys can be entered in ASCII or Hexadecimal. Check the key you wish to use. Vigor2110 Series User’s Guide...
Page 242: Access Control
MAC address from LAN. Add a new MAC address into the list. Delete the selected MAC address in the list. Delete Edit the selected MAC address in the list. Edit Give up the access control set up. Cancel Vigor2110 Series User’s Guide...
Page 243: Wps
On the side of Vigor 2110 series which served as an AP, press WPS button once on the front panel of the router or click Start PBC on web configuration interface. On the side of a station with network card installed, press Start PBC button of network card. Vigor2110 Series User’s Guide...
Page 244 Display related system information for WPS. If the wireless WPS Status security (encryption) function of the router is properly configured, you can see ‘Configured’ message here. Display the SSID1 of the router. WPS is supported by SSID1 SSID Vigor2110 Series User’s Guide...
Page 245: Wds
Provide bridge traffic between two LANs through the air. Extend the coverage range of a WLAN. To meet the above requirement, two WDS modes are implemented in Vigor router. One is Bridge, the other is Repeater. Below shows the function of WDS-bridge interface: Vigor2110 Series User’s Guide...
Page 246 Bridge 2 through WDS links. However, hosts connected to Bridge 1 CANNOT communicate with hosts connected to Bridge 3 through Bridge 2. Click WDS from Wireless LAN menu. The following page will be shown. Vigor2110 Series User’s Guide...
Page 247 Type – There are several types for you to choose. Default Pre-shared Key setting is DrayTek WPA. WPA and WPA2 are used for WDS devices (e.g., AP700). For example, if you have a wireless AP and a Vigor2110n wireless router, you can set the encryption mode as WPA or WPA2 to establish your WDS system between AP and the router.
Page 248: Advanced Setting
It is to assure the safety of propagation delays and reflections for Guard Interval the sensitive digital data. If you choose auto as guard interval, the AP router will choose short guard interval (increasing the wireless performance) or long guard interval for data transmit Vigor2110 Series User’s Guide...
Page 249: Wmm Configuration
AC_BE and AC_BK categories. CWMin means contention Window-Min and CWMax means CWMin/CWMax contention Window-Max. Please specify the value ranging from 1 to 15. Be aware that CWMax value must be greater than Vigor2110 Series User’s Guide...
Page 250 It can assure that the peer must receive the WMM packets. “Check” the box means the AP router will not answer any response request for the transmitting packets. It will have better performance with lower reliability. Vigor2110 Series User’s Guide...
Page 251: Ap Discovery
AP’s MAC address on the bottom of the page and click Bridge or Repeater. Next, click Add to. Later, the MAC address of the AP will be added to Bridge or Repeater field of WDS settings page. Vigor2110 Series User’s Guide...
Page 252: Station List
There is a code summary below for explanation. For convenient Access Control, you can select a WLAN station and click Add to Access Control below. Click this button to refresh the status of station list. Refresh Click this button to add current typed MAC address into Access Control. Vigor2110 Series User’s Guide...
Page 253: Usb Application
FTP sessions. The router allows up to 6 FTP sessions connecting to USB storage disk at one time. Default Charset - At present, Vigor router supports three types of character sets: default, GB2312 and BIG5. Vigor2110 Series User’s Guide...
Page 254: Usb User Management
This page allows you to set profiles for FTP users. Any user who wants to access into the USB disk must type the same username and password configured in this page. Before adding or modifying settings in this page, please insert a USB disk first. Otherwise, an error message will appear to warn you. Vigor2110 Series User’s Guide...
Page 255 Only “/” can be used in such case. You can click to open the following dialog to add any new folder which can be specified as the Home Folder. Vigor2110 Series User’s Guide...
Page 256 Directory –Check the items (List, Create and Remove) for such profile. Before you click OK, you have to insert a USB disk into the USB interface of the Vigor router. Otherwise, you cannot save the configuration. Vigor2110 Series User’s Guide...
Page 257: File Explorer
Create Display current folder. Current Path Click this button to upload the selected file to the USB storage Upload disk. The uploaded file in the USB storage disk can be shared for other user through FTP. Vigor2110 Series User’s Guide...
Page 258: Disk Status
FTP server. It displays the username that user uses to login to the FTP Username server. When you insert USB disk into the Vigor router, the system will start to find out such device within several seconds. Vigor2110 Series User’s Guide...
Page 259: System Maintenance
MAC Address Display the IP address of the LAN interface. IP Address Display the subnet mask address of the LAN interface. Subnet Mask Display the current status of DHCP server of the LAN DHCP Server interface. Vigor2110 Series User’s Guide...
Page 260 It indicates information about equipped WLAN miniPCi Firmware Version card. This also helps to provide availability of some features that are bound with some WLAN miniPCi. Display the SSID of the router. SSID Vigor2110 Series User’s Guide...
Page 261: 251
CPE. Or click Disable to close the mechanism of notification. The default is Disable. If you click Enable, please type the STUN Settings relational settings listed below: Vigor2110 Series User’s Guide...
Page 262: Administrator Password
Type in new password in this field. New Password Type in the new password again. Confirm Password When you click OK, the login window will appear. Please use the new password to access into the web configurator again. Vigor2110 Series User’s Guide...
Page 263: Configuration Backup
Click Backup button to get into the following dialog. Click Save button to open another dialog for saving configuration as a file. In Save As dialog, the default filename is config.cfg. You could give it another name by yourself. Vigor2110 Series User’s Guide...
Page 264 Click Browse button to choose the correct configuration file for uploading to the router. Click Restore button and wait for few seconds, the following picture will tell you that the restoration procedure is successful. Vigor2110 Series User’s Guide...
Page 265: Syslog/Mail Alert
Assign a port for the SMTP server. SMTP Port Assign a mail address for sending mails out. Mail To Assign a path for receiving the mail from outside. Return-Path Check this box to activate this function while using e-mail Authentication application. Vigor2110 Series User’s Guide...
Page 266 From the Syslog screen, select the router you want to monitor. Be reminded that in Network Information, select the network adapter used to connect to the router. Otherwise, you won’t succeed in retrieving information from the router. Vigor2110 Series User’s Guide...
Page 267: Time And Date
Check the box to enable the daylight saving. Such feature is Enable Daylight Saving available for certain area. Select a time interval for updating from the NTP server. Automatically Update Interval Click OK to save these settings. Vigor2110 Series User’s Guide...
Page 268: Management
Check it to enable this function. Enable SNMP Agent Set the name for getting community by typing a proper Get Community character. The default setting is public. Set community by typing a proper name. The default setting is Set Community Vigor2110 Series User’s Guide...
Page 269: Reboot System
Note: When the system pops up Reboot System web page after you configure web settings, please click Reboot Now to reboot your router for ensuring normal operation and preventing unexpected errors of the router in the future. Vigor2110 Series User’s Guide...
Page 270: Firmware Upgrade
Note that this example is running over Windows OS (Operating System). Download the newest firmware from DrayTek's web site or FTP site. The DrayTek web site is www.draytek.com (or local DrayTek's web site) and FTP site is ftp.draytek.com.
Page 271: Activation
CT-CF) adopted by such router. Display the starting date of WCF license activated successfully. Start Date Display the ending date of WCF license activated successfully. Expire Date Click this link to access into http://myvigor.draytek.com for Activate activating WCF function. Vigor2110 Series User’s Guide...
Page 272: Diagnostics
(e.g., PPPoE) is triggered by a package sending from the source IP address. It shows the source IP address (local), destination IP (remote) Decoded Format address, the protocol and length of the package. Click it to reload the page. Refresh Vigor2110 Series User’s Guide...
Page 273: Routing Table
Resolution Protocol) cache held in the router. The table shows a mapping between an Ethernet hardware address (MAC Address) and an IP address. Click it to reload the page. Refresh Click it to clear the whole table. Clear Vigor2110 Series User’s Guide...
Page 274: Dhcp Table
It displays the host ID name of the specified PC. HOST ID Click it to reload the page. Refresh Click Diagnostics and click NAT Sessions Table to open the list page. It indicates the source IP address and port of local PC. Private IP:Port Vigor2110 Series User’s Guide...
Page 275: Data Flow Monitor
Enable Data Flow Monitor Use the drop down list to choose the time interval of refreshing Refresh Seconds data flow that will be done by the system automatically. Click this link to refresh this page manually. Refresh Vigor2110 Series User’s Guide...
Page 276 Peak means the highest peak value detected by the router in data transmission. Speed means line speed specified in WAN>>General Setup. If you do not specify any rate at that page, here will display Auto for instead. Vigor2110 Series User’s Guide...
Page 277: Traffic Graph
Use the drop down list to choose the destination that you want Ping to to ping. Type in the IP address of the Host/IP that you want to ping. IP Address Click this button to start the ping work. The result will be displayed on the screen. Vigor2110 Series User’s Guide...
Page 278: Trace Route
Use the drop down list to choose the protocol that you want to Protocol ping through. It indicates the IP address of the host. Host/IP Address Click this button to start route tracing work. Click this link to remove the result on the window. Clear Vigor2110 Series User’s Guide...
Page 279: Support Area
When you click it, you will be guided to visit myvigor.draytek.com and open the corresponding pages directly. Click Support Area>>Application Note, the following web page will be displayed. Click Support Area>>FAQ, the following web page will be displayed. Vigor2110 Series User’s Guide...
Page 280 Click Support Area>>Product Registration, the following web page will be displayed. Vigor2110 Series User’s Guide...
Page 281: Application And Examples
For using PPP based services, such as PPTP, L2TP, you have to set general settings in PPP General Setup. For using IPSec-based service, such as IPSec or L2TP with IPSec Policy, you have to set general settings in IPSec General Setup, such as the pre-shared key that both parties Vigor2110 Series User’s Guide...
Page 282 Set Dial-Out Settings as shown below to dial to connect to Router B aggressively with the selected Dial-Out method. If an IPSec-based service is selected, you should further specify the remote peer IP Address, IKE Authentication Method and IPSec Security Method for this Dial-Out connection. Vigor2110 Series User’s Guide...
Page 283 If an IPSec-based service is selected, you may further specify the remote peer IP Address, IKE Authentication Method and IPSec Security Method for this Dial-In connection. Otherwise, it will apply the settings defined in IPSec General Setup above. Vigor2110 Series User’s Guide...
Page 284 Go to VPN and Remote Access and select Remote Access Control to enable the necessary VPN service and click OK. Then, for using PPP based services, such as PPTP, L2TP, you have to set general settings in PPP General Setup. Vigor2110 Series User’s Guide...
Page 285 Set Dial-Out Settings as shown below to dial to connect to Router B aggressively with the selected Dial-Out method. If an IPSec-based service is selected, you should further specify the remote peer IP Address, IKE Authentication Method and IPSec Security Method for this Dial-Out connection. Vigor2110 Series User’s Guide...
Page 286 If an IPSec-based service is selected, you may further specify the remote peer IP Address, IKE Authentication Method and IPSec Security Method for this Dial-In connection. Otherwise, it will apply the settings defined in IPSec General Setup above. Vigor2110 Series User’s Guide...
Page 287 Username, Password, and VJ Compression for this Dial-In connection. At last, set the remote network IP/subnet in TCP/IP Network Settings so that Router B can direct the packets destined to the remote network to Router A via the VPN connection. Vigor2110 Series User’s Guide...
Page 288: Create A Remote Dial-In User Connection Between The Teleworker And Headquarter
PPP General Setup. For using IPSec-based service, such as IPSec or L2TP with IPSec Policy, you have to set general settings in IKE/IPSec General Setup, such as the pre-shared key that both parties have known. Vigor2110 Series User’s Guide...
Page 289 Otherwise, it will apply the settings defined in IPSec General Setup above. If a PPP-based service is selected, you should further specify the remote peer IP Address, Username, Password, and VJ Compression for this Dial-In connection. Vigor2110 Series User’s Guide...
Page 290 For Win2000/XP, please use "Network and Dial-up connections" or “Smart VPN Client”, complimentary software to help you create PPTP, L2TP, and L2TP over IPSec tunnel. You can find it in CD-ROM in the package or go to www.draytek.com download center. Install as instructed.
Page 291 VPN router. To use default gateway on remote network means that all the packets of remote host will be directed to VPN server then forwarded to Internet. This will make the remote host seem to be working in the enterprise network. Vigor2110 Series User’s Guide...
Page 292: Qos Setting Example
Vigor router at home to connect to the server in the headquarter office downtown via either HTTPS or VPN to check email and access internal database. Meanwhile, children may chat on Skype in the restroom. Go to Bandwidth Management>>Quality of Service. Vigor2110 Series User’s Guide...
Page 293 Return to previous page. Enter the Name of Index Class 1 by clicking Edit link. Type the name “E-mail” for Class 1. For this index, the user will set reserved bandwidth (e.g., 25%) for E-mail using protocol POP3 and SMTP. Vigor2110 Series User’s Guide...
Page 294 VoIP influent other application. Click OK. If the worker has connected to the headquarter using host to host VPN tunnel. (Please refer to Chapter 3 VPN for detail instruction), he may set up an index for it. Enter the Vigor2110 Series User’s Guide...
Page 295: Lan - Created By Using Nat
An example of default setting and the corresponding deployment are shown below. The default Vigor router private IP address/Subnet Mask is 192.168.1.1/255.255.255.0. The built-in DHCP server is enabled so it assigns every local NATed host an IP address of 192.168.1.x starting from 192.168.1.10. Vigor2110 Series User’s Guide...
Page 296 You can just set the settings wrapped inside the red rectangles to fit the request of NAT usage. To use another DHCP server in the network rather than the built-in one of Vigor Router, you have to change the settings as show below. Vigor2110 Series User’s Guide...
Page 297 You can just set the settings wrapped inside the red rectangles to fit the request of NAT usage. Vigor2110 Series User’s Guide...
Page 298: Calling Scenario For Voip Function
Proxy: iptel.org Act as outbound proxy: unchecked Display Name: David Account Name: 4321 Authentication ID: unchecked Password: **** Expiry Time: (use default value) David calls John CODEC/RTP/DTMF --- He picks up the phone and dials 2222# (DialPlan Vigor2110 Series User’s Guide...
Page 299 Expiry Time: (use default value) CODEC/RTP/DTMF--- David calls John (Use default value) He picks up the phone and dials 2222# (DialPlan Phone Number for John) Or, He picks up the phone and dials 1234# (John’s Account Name) Vigor2110 Series User’s Guide...
Page 300: Peer-To-Peer Calling
Display Name: Paulin Acco4unt Name: 4321 Authentication ID: unchecked Password: (blank) Expiry Time: (use default value) Paulin calls Arnor CODEC/RTP/DTMF--- He picks up the phone and dials 2222# (DialPlan (Use default value) Phone Number for John) Vigor2110 Series User’s Guide...
Page 301: Upgrade Firmware For Your Router
4. Click on the link of Router Tools to download the file. After downloading the files, please decompressed the file onto your host. 5. Double click on the icon of router tool. The setup wizard will appear. Vigor2110 Series User’s Guide...
Page 302 (keep the old custom settings) and xxxx.rst (reset all the custom settings to default settings). Choose any one of them that you need. 10. Click Send. 11. Now the firmware update is finished. Vigor2110 Series User’s Guide...
Page 303: Request A Certificate From A Ca Server On Windows Ca Server
Go to Certificate Management and choose Local Certificate. Vigor2110 Series User’s Guide...
Page 304 Copy and save the X509 Local Certificate Requet as a text file and save it for later use. Connect to CA server via web browser. Follow the instruction to submit the request. Below we take a Windows 2000 CA server for example. Select Request a Certificate. Vigor2110 Series User’s Guide...
Page 305 64 encoded certificate and Download CA certificate. Now you should get a certificate (.cer file) and save it. Back to Vigor router, go to Local Certificate. Click IMPORT button and browse the file to import the certificate (.cer file) into Vigor router. When finished, click refresh and Vigor2110 Series User’s Guide...
Page 306 “------BEGINE CERTIFICATE------..” You may review the detail information of the certificate by clicking View button. Vigor2110 Series User’s Guide...
Page 307: Request A Ca Certificate And Set As Trusted On Windows Ca Server
Use web browser connecting to the CA server that you would like to retrieve its CA certificate. Click Retrive the CA certificate or certificate recoring list. Vigor2110 Series User’s Guide...
Page 308 You may review the detail information of the certificate by clicking View button. Note: Before setting certificate configuration, please go to System Maintenance >> Time and Date to reset current time of the router first. Vigor2110 Series User’s Guide...
Page 309: Creating An Account For Myvigor
The website of MyVigor (a server located on http://myvigor.draytek.com) provides several useful services (such as Anti-Spam, Web Content Filter, Anti-Intrusion, and etc.) to filtering the web pages for the sake of protecting your system. To access into MyVigor for getting more information, please create an account for MyVigor.
Page 310 3. Click the link of Create an account now. 4. Check to confirm that you accept the Agreement and click Accept. 5. Type your personal information in this page and then click Continue. 6. Choose proper selection for your computer and click Continue. Vigor2110 Series User’s Guide...
Page 311 New Account Confirmation Letter from myvigor.draytek.com. 9. Click the Activate my Account link to enable the account that you created. The following screen will be shown to verify the register process is finished. Please click Login. Vigor2110 Series User’s Guide...
Page 312: Creating An Account Via Myvigor Web Site
11. Now, click Login. Your account has been activated. You can access into MyVigor server to activate the service (e.g., WCF) that you want. 1. Access into http://myvigor.draytek.com. Find the line of Not registered yet?. Then, click the link Click here! to access into next page.
Page 313 2. Check to confirm that you accept the Agreement and click Accept. 3. Type your personal information in this page and then click Continue. 4. Choose proper selection for your computer and click Continue. Vigor2110 Series User’s Guide...
Page 314 New Account Confirmation Letter from myvigor.draytek.com. 7. Click the Activate my Account link to enable the account that you created. The following screen will be shown to verify the register process is finished. Please click Login. Vigor2110 Series User’s Guide...
Page 315 UserName and Password. Then type the code in the box of Auth Code according to the value displayed on the right side of it. Now, click Login. Your account has been activated. You can access into MyVigor server to activate the service (e.g., WCF) that you want. Vigor2110 Series User’s Guide...
Page 316: How Can I Get The Files From Usb Storage Device Connecting To Vigor Router
Setup a user account for the FTP service by using USB Application >>USB User Management. Click Enable to enable FTP/Samba User account. Here we add a new account "user1" and assign authorities “Read”, “Write” and “List” to it. Click OK to save the configuration. Vigor2110 Series User’s Guide...
Page 317 Use the account "user1" to login. When the following screen appears, it means the FTP service is running properly. Return to USB Application >> USB Disk Status. The information for FTP server will be shown as below. Vigor2110 Series User’s Guide...
Page 318 Now, users in LAN of Vigor2110 can access into the USB storage device by typing ftp://192.168.1.1 on any browser. They can add or remove files / directories, depending on the Access Rule for FTP account settings in USB Application >>USB User Management. Vigor2110 Series User’s Guide...
Page 319: Trouble Shooting
Turn on the router. Make sure the ACT LED blink once per second and the correspondent LAN LED is bright. If not, it means that there is something wrong with the hardware status. Simply back to “1.3 Hardware Installation” to execute the hardware installation again. And then, try again. Vigor2110 Series User’s Guide...
Page 320 Go to Control Panel and then double-click on Network Connections. Right-click on Local Area Connection and click on Properties. Select Internet Protocol (TCP/IP) and then click Properties. Vigor2110 Series User’s Guide...
Page 321 Select Obtain an IP address automatically and Obtain DNS server address automatically. Double click on the current used Mac OS on the desktop. Open the Application folder and get into Network. On the Network screen, select Using DHCP from the drop down list of Configure IPv4. Vigor2110 Series User’s Guide...
Page 322: Pinging The Router From Your Computer
Open the Application folder and get into Utilities. Double click Terminal. The Terminal window will appear. Type ping 192.168.1.1 and press [Enter]. If the link is OK, the line of “64 bytes from 192.168.1.1: icmp_seq=0 ttl=255 time=xxxx ms” will appear. Vigor2110 Series User’s Guide...
Page 323: Checking If The Isp Settings Are Ok Or Not
Click Internet Access group and then check whether the ISP settings are set correctly. Check if the Enable option is selected. Check if Username and Password are entered with correct values that you got from your ISP. Vigor2110 Series User’s Guide...
Page 324 Check if the Enable option for Broadband Access is selected. Check if WAN IP Network Settings is set appropriately. Check if IP Address, Subnet Mask and Gateway are set correctly (must identify with the values from your ISP) if you choose Specify an IP address. Vigor2110 Series User’s Guide...
Page 325: Problems For 3G Network Connection
PIN code and try again. If it still fails, it might be the compliance problem of system. Please open DrayTek Syslog Tool to capture the connection information (WAN Log) and send the page (similar to the following graphic) to the service center of DrayTek.
Page 326: Backing To Factory Default Setting If Necessary
Go to System Maintenance and choose Reboot System on the web page. The following screen will appear. Choose Using factory default configuration and click Reboot Now. After few seconds, the router will return all the settings to the factory settings. Vigor2110 Series User’s Guide...
Page 327: Contacting Your Dealer
After restore the factory default setting, you can configure the settings for the router again to fit your personal request. If the router still cannot work correctly after trying many efforts, please contact your dealer for further help right away. For any questions, please feel free to send e-mail to support@draytek.com. Vigor2110 Series User’s Guide...

This manual is also suitable for:

Vigor2110n Vigor2110vn

Draytek Vigor2110 Series User Manual

Preface

Configuring Basic Settings

User Mode Operation

Admin Mode Operation

Application and Examples

Trouble Shooting

Quick Links

Need help?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Draytek Vigor2110 Series

Summary of Contents for Draytek Vigor2110 Series
