IKE Authentication
Method
IPSec Security Method
Vigor2110 Series User's Guide
security methods in the general settings.
Netbios Naming Packet
Pass – Click it to have an inquiry for data transmission
between the hosts located on both sides of VPN Tunnel
while connecting.
Block – When there is conflict occurred between the
hosts on both sides of VPN Tunnel in connecting, such
function can block data transmission of Netbios Naming
Packet inside the tunnel.
Multicast via VPN
Some programs might send multicast packets via VPN
connection.
Pass – Click this button to let multicast packets pass
through the router.
Block – This is default setting. Click this button to let
multicast packets be blocked by the router.
Assign Static IP Address – Allow the IP address typed here
to dial in.
User Name - This field is applicable when you select PPTP or
L2TP with or without IPSec policy above.
Password - This field is applicable when you select PPTP or
L2TP with or without IPSec policy above.
This group of fields is applicable for IPSec Tunnels and L2TP
with IPSec Policy when you specify the IP address of the
remote node. The only exception is Digital Signature (X.509)
can be set when you select IPSec tunnel either with or without
specify the IP address of the remote node.
Pre-Shared Key - Check the box of Pre-Shared Key to invoke
this function and type in the required characters (1-63) as the
pre-shared key.
Digital Signature (X.509) – Check the box of Digital
Signature to invoke this function and Select one predefined
Profiles set in the VPN and Remote Access >>IPSec Peer
Identity.
This group of fields is a must for IPSec Tunnels and L2TP
with IPSec Policy when you specify the remote node. Check
the Medium, DES, 3DES or AES box as the security method.
Medium-Authentication Header (AH) means data will be
authenticated, but not be encrypted. By default, this option is
invoked. You can uncheck it to disable it.
High-Encapsulating Security Payload (ESP) means payload
(data) will be encrypted and authenticated. You may select
encryption algorithm from Data Encryption Standard (DES),
Triple DES (3DES), and AES.
Local ID - Specify a local ID to be used for Dial-in setting in
the LAN-to-LAN Profile setup. This item is optional and can
be used only in IKE aggressive mode.
191
