PPP/MP Setup
IP Address
Assignment Method
(IPCP)
Vigor2110 Series User's Guide
PPP Authentication – Select PAP only or PAP or CHAP for PPP.
WAN Connection Detection - Such function allows you to verify
whether network connection is alive or not through ARP Detect or
Ping Detect.
Mode – Choose ARP Detect or Ping Detect for the system to
execute for WAN detection.
Ping IP – If you choose Ping Detect as detection mode, you have to
type IP address in this field for pinging.
TTL (Time to Live) – Displays value for your reference. TTL value
is set by telnet command.
Default – Click this button to reset to factory setting.
PPP Authentication – Select PAP only or PAP or CHAP for PPP.
If you want to connect to Internet all the time, you can check
Always On.
Idle Timeout – Set the timeout for breaking down the Internet after
passing through the time without any action.
Usually ISP dynamically assigns IP address to you each time you
connect to it and request. In some case, your ISP provides service to
always assign you the same IP address whenever you request. In this
case, you can fill in this IP address in the Fixed IP field. Please
contact your ISP before you want to use this function.
WAN IP Alias - If you have multiple public IP addresses and would
like to utilize them on the WAN interface, please use WAN IP Alias.
You can set up to 8 public IP addresses other than the current one
you are using. Notice that this setting is available for WAN1 only.
Fixed IP – Click Yes to use this function and type in a fixed IP
address in the box of Fixed IP Address.
Default MAC Address – You can use Default MAC Address or
33
