Index
IP Address
TX rate (kbps)
RX rate (kbps)
Sessions
Action
Current /Peak/Speed
Display the number of the data flow.
Display the IP address of the monitored device.
Display the transmission speed of the monitored device.
Display the receiving speed of the monitored device.
Display the session number that you specified in Limit Session
web page.
Block - can prevent specified PC accessing into Internet within
5 minutes.
Unblock – the device with the IP address will be blocked in
five minutes. The remaining time will be shown on the session
column.
Current means current transmission rate and receiving rate for
WAN interface.
Peak means the highest peak value detected by the router in
data transmission.
Speed means line speed specified in WAN>>General Setup. If
you do not specify any rate at that page, here will display Auto
for instead.
