MAC Bind IP
Quality of Service
Load-Balance policy
APP Enforcement
URL Content Filter
Web Content Filter
When the IP Object Profile (with specified MAC Address and
IP address for Address Type) is selected for Source IP
/Destination IP setting, the system will process the packet
according to the following rules:
If the MAC address of the packet meets the specified
MAC address listed in IP Object Profile,
No matter which IP address that the packet is, it can pass
through Vigor router easily.
If the MAC address of the packet cannot meet the
specified MAC address listed in IP Object Profile, the
system will consider the IP settings (Non-Strict or Strict)
to determine if the packets can pass or be blocked.
If Non-Strict is selected: The packet can pass.
If Strict is selected: The packet will be blocked.
Choose one of the QoS rules to be applied as firewall rule. For
detailed information of setting QoS, please refer to the related
section later.
Choose the WAN interface for applying Load-Balance Policy.
Select an APP Enforcement profile for global IM/P2P
application blocking. If there is no profile for you to selelct,
please choose [Create New] from the drop down list in this
page to create a new profile. All the hosts in LAN must follow
the standard configured in the APP Enforcement profile
selected here. For detailed information, refer to the section of
APP Enforcement profile setup. For troubleshooting needs,
you can specify to record information for IM/P2P by checking
the Log box. It will be sent to Syslog server. Please refer to
section Syslog/Mail Alert for more detailed information.
Select one of the URL Content Filter profile settings (created
in CSM>> URL Content Filter) for applying with this router.
Please set at least one profile for choosing in CSM>> URL
Content Filter web page first. Or choose [Create New] from
the drop down list in this page to create a new profile. For
troubleshooting needs, you can specify to record information
for URL Content Filter by checking the Log box. It will be
sent to Syslog server. Please refer to section Syslog/Mail
Alert for more detailed information.
Select one of the Web Content Filter profile settings (created
in CSM>> Web Content Filter) for applying with this router.
Please set at least one profile for anti-virus in CSM>> Web
Content Filter web page first. Or choose [Create New] from
the drop down list in this page to create a new profile. For
troubleshooting needs, you can specify to record information
