5.3.2. Ethernet

Port Settings
Figure 5.5.: LAN Ports
This menu can be used to individually assign each Ethernet port to a LAN interface, just
in case you want to have different subnets per port or use one port as WAN interface. You
may assign multiple ports to the same interface. Please note that on systems without
an Ethernet switch, the ports will be bridged by software then and operated by running
the Spanning Tree Protocol (STP).
Link Settings
Link negotiation can be set for each Ethernet port individually. Most devices support
auto-negotiation which will configure the link speed automatically to comply with other
devices in the network. In case of negotiation problems, you may assign the modes
manually but it has to be ensured that all devices in the network utilize the same
settings then.
IP Settings
This page can be used to configure IP addressing for your LAN/WAN Ethernet inter-
faces.
