System - NetModule NB2700 User Manual

5.8. SYSTEM

5.8.1. System
System Settings
The following system parameters can be set:
Local hostname: The hostname of the system
Syslog redirect address: Specifies an IP address to which system log messages should
be redirected to. A tiny system log server for Windows is included in TFTP32
which can be downloaded from our website.
Syslog max. file size: The maximum size of message log files in kilobytes until they
will be rotated
Reboot delay: The number of seconds which will be waited before regular system re-
boots (might be needed for system-rebooting events)
Banks to be displayed: You can configure the behavior of the status LEDs on the front
panel of your device. They are usually divided into two banks (top/ bottom) and
are either indicating the connection status or the digital IO port status. You may
configure toggle mode, so that the LEDs periodically cycle between the two states.
NB2700 User Manual
Figure 5.49.: System
98
