Please keep in mind that the DNS servers can be set globally in the DNS server config-
uration menu. But as soon as a link comes up it will use the interface-specific name-
servers (e.g. the ones being retrieved over DHCP) and update the resolver configuration
accordingly.
Mode: Defines whether this interface is being used as LAN or WAN interface
When running in LAN mode the interface accepts the following static settings:
IP address: The IP interface address
Subnet mask: The subnet mask for this interface
When running in WAN mode the interface may be configured with the following settings:
WAN mode: The WAN operation mode, defines whether the interface should run as
DHCP client, statically configured or over PPPoE
MTU: The maximum transfer unit for the interface, if provided it will specify the largest
size of a packet
When running as DHCP client, no further configuration is required because all IP-related
settings (address, subnet, gateway, DNS server) will be retrieved from a DHCP server
NB2700 User Manual
Figure 5.6.: LAN Link Settings
