3. Specifications
There are currently three different models of NB2700 available:
• NB2700 Mobile
• NB2700 Mobile & WLAN
• NB2700 WLAN

3.1. Operating Elements

The following table describes the NB2700 status indicators. The color of the LED
represents the signal quality for wireless links.
red means low
yellow means moderate
green means good or excellent
Label Color
Status blinking The device is busy due to startup, software or configu-
Mob1
blinking Mobile connection 1 is being established.
Mob2
blinking Mobile connection 2 is being established.
VPN
WLAN
blinking WLAN connection is being established.
State Function
ration update.
on The device is ready. The captions of the top bank apply.
on The device is ready. The captions of the bottom bank
apply.
on Mobile connection 1 is up.
off Mobile connection 1 is down.
on Mobile connection 2 is up.
off Mobile connection 2 is down.
on VPN connection is up.
off VPN connection is down.
on WLAN connection is up.
