Interface: The network interface on which a packet will be transmitted in order to reach
the gateway or network behind it
Metric: The routing metric of the interface (default 0), higher metrics have the effect
of making a route less favorable
Flags: (A)ctive, (P)ersistent, (H)ost Route, (N)etwork Route, (D)efault Route
The flags obtain the following meanings:
Flag
A
P
H
N
D
NB2700 User Manual
Description
The route is considered active, it might be inactive if the
interface for this route is not yet up.
The route is persistent, which means it is a configured route,
otherwise it corresponds to an interface route.
The route is a host route, typically the netmask is set to
255.255.255.255.
The route is a network route, consisting of an address and
netmask which forms the subnet to be addressed.
The route is a default route, address and netmask are set
to 0.0.0.0, thus matching any packet.
Table 5.2.: Static Route Flags
