Nb2700 Status Indicators - NetModule NB2700 User Manual

Label Color State
GPS
Voice
DO1
DO2
DI1
DI2
NB2700 User Manual
Function
off WLAN connection is down.
on GPS is turned on and a valid NMEA stream is available.
off GPS is turned off or no valid NMEA stream is available.
on A voice call is currently active.
off No voice call is active.
on Normally open output port 1 is closed.
off Normally open output port 1 is open.
on Normally closed output port 2 is closed.
off Normally closed output port 2 is open.
on Input port 1 is set.
off Input port 1 is not set.
on Input port 2 is set.
off Input port 2 is not set.
Table 3.1.: NB2700 Status Indicators
14
