BMW R 1100 RT Repair Manual page 60

Technical Data
Crankshaft
Marking of main bearing and crankpin on
front crank web
no paint mark
paint mark
Grinding stage 0 (grinding stage 1= —0.25mm)
Guide bearing bore dia.
Guide bearing dia.
Main bearing journal dia.
Radial clearance
Wear limit
Main bearing bore dia.
Main bearing dia.
Main bearing journal dia.
Radial clearance
Wear limit
Width of guide bearing
Bearing width of main bearing journal
Axial play
Wear limit
Grinding stage 0 (grinding stage1= –0.25mm)
Crankpin dia.
Bearing width of crankpin
Connecting rod
Big end bore dia.
Big end bearing dia.
Radial clearance
Wear limit
11.10
mm (in)
mm (in)
mm (in)
mm (in)
mm (in)
mm (in)
mm (in)
mm (in)
mm (in)
mm (in)
mm (in)
mm (in)
mm (in)
mm (in)
mm (in)
mm (in)
mm (in)
mm (in)
mm (in)
mm (in)
R 1100 RS
Grinding stage 0
Grinding stage 1
-0.25mm (-0.009843 in)
64.949...64.969
(2.557047...2.557834)
Green:
59.964...60.003
(2.36079...2.36232)
Yellow: 59.974...60.013
(2.36118...2.36272)
Green:
59.939...59.948
(2.35980...2.360157)
Yellow: 59.949...59.958
(2.360197...2.36055)
0.016...0.064
(0.0006299..0.002519)
0.1 (0.003937)
60.000...60.019
(2.3622...2.36295)
Green: 54.998...55.039
(2.16528...2.16689)
Yellow: 55.008...55.049
(2.16567...2.16728)
Green: 54.971...54.980
(2.1642...2.164567)
Yellow: 54.981...54.990
(2.16461...2.16496)
0.018...0.068
(0.0001086....002677)
0.13 (0.005118)
24.890...24.940
(0.97992...0.98189)
25.020...25.053
(0.98504...0.986339)
0.080...0.163
(0.0031496...0.006417)
0.2 (0.007874)
47.975...47.991
(1.88878...1.88941)
22.065...22.195
(0.86870...0.87381)
51.000...51.013
(2.00787...2.008386)
48.016...48.050
(1.89039...1.89173)
0.025...0.075
(0.000984...0.0029527)
0.13 (0.001118)
