Datamax E-Class Mark III Professional Operator's Manual page 53

DISPLAYED ITEM
COLUMN EMULATION
XXX Dots
ROW EMULATION
XXX Dots
SOP EMULATION
DISABLED
110 (PRODPLUS)
220 (ALLEGRO)
250 (PRODIGY)
BACK AFTER PRINT
MODE
DISABLED
ENABLED
BACKUP DELAY
(1/50s)
000
FONT EMULATION
STANDARD FONTS
CG TIMES
USER ID S50
LABEL STORE
STATE & FIELDS
FIELDS ONLY
MENU LANGUAGE
ENGLISH
DISPLAY SETTINGS
GRAPHIC DISPLAY
MODE
STANDARD
ENHANCED
DISPLAY UNITS
STANDARD
IMPERIAL
METRIC
DISPLAY BACKLIGHT
BACKLIGHT MODE
AUTO ON TIME
DISPLAY CONTRAST
50
FAULT HANDLING
LEVEL
NO REPRINT
STANDARD
BUZZER
ENABLED
DISABLED
SCL FONT BOLD FACTOR
08 (1 – 36)
Chapter 4 – Menu System
Allows the column dots per inch to be adjusted (153 - 253 dots), so that numbers smaller than the
printhead resolution reduce the printed output from right to left, where:
Default setting is dependant on printer model.
Allows the row dots per inch to be adjusted (103 - 303), so that numbers smaller than the printhead
resolution enlarge the height of the printed output and numbers larger reduce it, where:
Default setting is dependant on printer model.
Allows label positioning commands to function with backward compatibility when printing label
formats designed for legacy models, where:
Produces the natural start of print position. (Default Setting)
Emulates the Prodigy Plus® start of print position.
Emulates the Allegro® start of print position.
Emulates the Prodigy™ start of print position.
Determines media movement when a cutter, present sensor, peel and present, or GPIO is enabled,
where:
Repositions media, where:
Movement occurs only when the next label is ready to print, minimizing edge curling.
Setting)
Movement occurs according to BACKUP DELAY timing after a cut, cleared sensor, or SOP to allow
fastest throughput.
Instructs the printer to retract a presented label after a specified time elapses (0 – 255, in one-
fiftieth of a second increments), where:
Retraction occurs when the next label is received and processed. (Default Setting)
Allows font substitution for all internal fonts where:
Prints using a standard (internal) font. (Default Setting)
Prints using the CG Times font.
Prints using a downloaded font.
Determines the command recall level used when retrieving stored label formats, where:
Recalls the printer state (i.e., heat, speed settings, etc.) and the label-formatting commands for the
stored label. (Default Setting)
Recalls the label-formatting commands for the stored label.
Selects the menu and configuration label language. Only languages that are resident will be
displayed (see Appendix D), where:
Enables English (Default Setting)
Determines the appearance of the items in the display, where:
Determines the magnification of the displayed items, where:
Is the normal setting.
Is the enlarged setting.
Determines the displayed type of distance
Displays the information according to the UNITS OF MEASURE setting (see above).
Displays the information in inches.
Displays the information in millimeters and centimeters.
Controls the mode and "ON" time of the display's backlight
Sets the mode in which the backlight is activated. Choices are Always On, Always Off, or Auto.
Set the amount of time the backlight will remain on. BACKLIGHT MODE (see above) must be set to auto.
Adjusts the displays contrast (0-100), where:
Is the default setting
Determines the intervention required and the disposition of the label in process when a fault occurs,
where:
Selects the user action and the reprint status upon declaration of a fault, where:
Printing stops and a fault message is displayed. Following correction of the problem, the FEED Key
must be pressed to clear the fault, but the label in process is not reprinted.
Printing stops and a fault message is displayed. Following correction of the problem, the FEED Key
must be pressed to clear the fault then the label in process is reprinted. (Default Setting.)
Sets a scalable font boldfacing amount, where:
Enables the printers buzzer. (Default Setting)
Disables the printers buzzer.
Sets a scalable font boldfacing amount, where:
Is the setting, based on an incrementing scale, where eight (08) is nominal.
ITEM DESCRIPTION
information, where:
(Default
