Advanced Entry Calibration (continued)
Step Action
Using the button, increment the
Gain Number by one. Record the
J
TOF Value. Repeat this process for
each Gain Number.
Gain Number
Step Action
In your sample calibration table,
where both the Label Value and
TOF Value are at least 20, subtract
the amounts and record the result
as a Difference Value (see below).
K
Identify the largest Difference
Value and the corresponding Gain
Number. This Gain Number will be
used to resample the media.
Gain Number
34
Displayed Message
TRAN SENSOR GAIN
Sample Calibration Table
Label Value
00 252
01 250
02 248
... ...
31 09
Displayed Message
TRAN SENSOR GAIN
Sample Calibration Table
Label Value
00 252
01 250
02 248
... ...
15 188
16 184
17 179
18 174
19 170
... ...
31 132
These are TOF Values, where
1
"245" represents the current
245
sensor reading.
(0 - 31)
TOF Value
248
245
234
...
14
In the example below, Gain
Number 18 is chosen because;
31
both values are at least twenty
14
and it has the highest Difference
(0 - 31)
Value.
TOF Value
248
245
234
...
63
51
38
25
19
...
14
Chapter 3 – Printer Operation
