Datamax E-Class Mark III Professional Operator's Manual page 39

Advanced Entry Calibration (continued)
Step Action
Raise the cover assembly then
proceed according to the media
type:
Die-cut – Remove a label or two
from the liner then position the
liner in the Media Sensor.
H
Notched – Position the Media in
the Media Sensor under the notch.
Reflective – Position the Media in
the Media Sensor under the black
mark.
Lower and latch the Cover
Assembly.
Using the or
I
Gain Number to 0.
Record the reading as a TOF Value
for Gain Number 0 in the table.
Gain Number
Chapter 3 – Printer Operation
Displayed Message
TRAN SENSOR GAIN
TRAN SENSOR GAIN
button, set the
Sample Calibration Table
Label Value
00 252
01 250
02 248
... ...
31 09
(1) Do not position the Media
Sensor under a perforation; and
if using preprinted media, ensure
the label area placed over the
31
sensor is free of text, graphics,
09
lines, etc.
(0 - 31)
(2) Do not move the Media
Sensor after this step.
This is the TOF Value for a gain
0 setting of 0, where "248"
represents the current sensor
248
(0 - 31) reading.
TOF Value
248
Comment
Difference Value
33
