Datamax E-Class Mark III Professional Operator's Manual page 38

Advanced Entry Calibration (continued)
Step Action
Using the or
Gain Number to 0.
Record the sensor reading as a
F
Label Value for Gain Number 00 in
a table (32 rows by four columns,
with headings similar to those
shown below.)
Gain Number
Step Action
Using the button, increment the
Gain Number by one and then
Record the Label Value.
G
Repeat this process for each Gain
Number.
Gain Number
32
Displayed Message
button, set the
TRAN SENSOR GAIN
Sample Calibration Table
Label Value
00 253
01
02
...
31
Displayed Message
TRAN SENSOR GAIN
Sample Calibration Table
Label Value
00 252
01 250
02 248
... ...
31 09
0 This is the Label Value for a gain
setting of 0.
253
(0 - 31)
TOF Value
1 This is the Label Value for a gain
setting of 1.
250
(0 - 31)
TOF Value
Chapter 3 – Printer Operation
Comment
Difference Value
Comment
Difference Value
