1. I
NTRODUCTION
Thank you for selecting the Martin Mania SCX500. This automated
moving-mirror projector has the following features:
• Automatic triggering and music triggering modes
• Stand-alone single fixture and master/slave operation, both with auto
trig and music trig
• DMX controllable, choice of 6- or 8-channel DMX control modes
• 12 pre-programmed macros
• 15 full colors (including white) and 5 multi-colors. Split color feature for
added color capability
• 16 gobos
• 180° pan and 72° tilt
• Adjustable focus
• 15° beam angle
• 150 watt long-life halogen lamp
• Versatile mounting options
U n p a c k i n g
The packing material is carefully designed to protect the fixture during
shipment - always use it to transport the fixture.
The Mania SCX500 is supplied with:
• Lamp (installed)
• Power cable
• 5 meter (16.4 ft.) RS-485 XLR cable for data link
• User manual
• Mounting U-bracket and mounting plate
• Fasteners for U-bracket and mounting plate
Important! The mounting plate is attached to the fixture with thumb
screws to protect the mirror, and the mirror assembly is
secured for transport. Before applying power, remove the
mounting plate, remove any transport packaging, and cut and
remove any plastic tie-wraps holding the mirror!

Introduction

5
