INTRODUCTION
1.4 System Configuration
FIGURE 1.
TMC-7DSP/TMC-6DSP Color CCD Camera
Figure 1 (below) presents a typical system configuration.
TMC-7DSP/TMC-6DSP System Configuration
Computer with
Frame Grabber
Board
Auto-Iris Lens
(optional)
OPTION SHUTTER PWR/RGB
0
VIDEO
MODE
AWB
1 2 3 4
* Video Output is the
same as BNC connector
Power
Ext. Sync
Integration
Video Output*
Monitor
Page 3
