INSTALLATION
FIGURE 3.
TMC-7DSP/TMC-6DSP Color CCD Camera
Ground and 12V DC terminals respectively. Be sure to replace the plastic terminal guard on the power
supply at this time.
Note:
The "K" series power supplies are designed primarily for OEM users who will be
mounting the power supply inside a protective enclosure. For use in exposed situations,
the DC-12N and PD-12 are recommended.
2.2.2 (d)
CBL-2R-7D RGB and Video Output Cable
CBL-2R-7D
RED
GREEN
BLUE
SYNC
C. Video
Page 7
