4.2.2 Shutter Mode Control

In Shutter Mode Control, you can specify either AE (Auto
Exposure) or Manual shutter mode.
4.2.2 (a) Auto Exposure Mode
In AE mode, the camera automatically sets the shutter speed
and dynamically adjusts it according to the conditions of the
light source.
Note: Selecting AE mode enables Back Light Compensation control (see Section 4.2.5 on
page 22), but disables shutter speed spin box.
4.2.2 (b) Manual Shutter Mode
In Manual shutter mode, you can manually change the shutter speed from 60fps to 10,000fps.
Note: Selecting Manual Shutter mode enables the shutter speed spin box, but disables Back
Light Compensation control (see Section 4.2.5 on page 22).
S h u t t e r
S h u t t e r
Mode Speed
0
1/60 (1/50)
1/100 (1/120)
1
2
1/250
1/500
3
4 1/1,000
1/2,000
5
1/4,000
6
7 1/10,000

4.2.3 White Balance Control

You can select either Internal White Balance mode or External White Balance mode by clicking the Int
(Internal WB) radio button or the Ext (External WB) radio button, respectively (Figure 11, "White
Balance Control"). "WB status" indicates which WB mode you have selected.
