INTRODUCTION

1.4 Applications

1.5 System Con guration
FIGURE 1.
TM-200 / TM-300 Miniature CCD Camera
The miniature size of the TM-200/TM-300 camera eliminates the need for a remoted imager camera in
all but the most confined spaces. This camera fits easily, both physically and functionally, into all types
of machine vision, automated inspection, and related applications. Other uses include remotely piloted
vehicles, miniature inspection devices, surveillance, microscopes and medical equipment.
Figure 1 (below) presents a typical system configuration in which a computer and frame grabber board
are used. A computer and frame grabber board are not required for operation of the TM-200/TM-300
camera.
TM-200 System Con guration
Monitor
SHUTTER
SPEED
1.0 AGC FLD
0 1 GAIN
9
8 2
3
7
6 4
0.45 MGC FRM
5
VIDEO
POWER
* Video Output is the
same as BNC connector
Power
Ext. Sync
Integration
Video Output*
Computer with
Frame Grabber
Board
Page 3
