1.3 Functional Options

Page 2
In addition to the standard VBS output, the TMC-7DSP/TMC-6DSP cameras feature separate
outputs for the RGB signals with sync and Y/C output. RGB signals are output without the use of a
"breakout" module. Separate RGB and sync signals can be output directly from the camera via the
12-pin connector. Y/C output is available via the 6-pin connector. The Y signal also can be used for
auto iris control.
• 1/60 to 1/10,000 sec. programmable shutter and auto shutter
The auto shutter function on the TMC-7DSP/TMC-6DSP adjusts the shutter speed automatically to
maintain a wide dynamic range of video output (5 lux to 50,000 lux). This eliminates the need for
bulky, expensive auto iris lenses.
RS-232C external control
•
Many functions, including gain, white balance, gamma, aperture, hue control, and shutter control
can be controlled externally via a PC.
• Anti-smear filter
Like all PULNiX color cameras, the TMC-7DSP/TMC-6DSP camera contains a filter to minimize
smear that can result when shooting a very bright object. Smear should only occur under extremely
bright and point light source conditions.
• External sync (HD, VD sync) capability
The TMC-7DSP/TMC-6DSP accepts external HD-VD or composite sync.
• Three Year Warranty
The CCD solid state image sensor allows the camera to maintain a superior performance level
indefinitely while requiring virtually no maintenance. PULNiX backs all of the TM Series cameras
with a three-year warranty.
Warning: Unscrewing the camera cover or opening the camera in any way
will void this warranty.
• Standard or mini cylindrical remote head configurations (one meter separation)
• Custom remote imager lengths
TMC-7DSP/TMC-6DSP Color CCD Camera
INTRODUCTION
