TABLE 1.
Page 14
White Balance Mode Selection Table
Mode
ATW
Push lock
Hold
Indoor fixed value
Fluorescent light fixed value
User (fl. light fixed value 2)
Outdoor fixed value
3.1.4 (a) Auto Trace White Balance (ATW)
The Auto Trace White Balance mode (ATW) is a feedback system that automatically aligns the white
balance by detection the R-G and B-G before gamma correction processing.
3.1.4 (b) Push Lock
Convergence is performed at a faster operation speed than ATW without an operation frame or other
limitations. However, the response time, operation frame and other factors cannot be selected.
3.1.4 (c) Hold
When shifting to the Hold mode, the convergence operation is stopped, and the R, G and B gains at that
point are written to the EEPROM. Push Lock mode and Hold mode can be combined to realize Push
Lock mode. Operation is performed in Push Lock mode while the button is pressed and shifts to Hold
mode when the button is released, allowing the white balance gain at that point to be written to the
EEPROM.
SW1 SW2
Up (0) Up (0)
Up (0) DN (1)
DN (1) DN (1)
Up (0) Up (0)
DN (1) Up (0)
Up (0) DN (1)
DN (1) DN (1)
TMC-7DSP/TMC-6DSP Color CCD Camera
OPERATION
SW3 Set color temp.
Up (0)
Up (0)
Up (0)
DN (1) approx. 3200K
DN (1) approx. 4200K
DN (1) approx. 4700K
DN (1) approx. 6300K
