OPERATION
TMC-7DSP/TMC-6DSP Color CCD Camera
3.1.4 (d) Automatic Exposure (AE)
AE
SW4 AE/ME
JSW1 FLON
JSW2 BLCOF
JSW3 MIRIS
JSW4 AEREF
JSW5 AGCMAX
*1. NTSC : 1/100s; PAL : 1/120s
Note: For AE setting: AE/ME(UP), FLON(CLOSE), MIRIS(CLOSE)
3.1.4 (e) Gamma Variant
Gamma Variant
JSW6 GAMMA
UP (L)
AE Mode
Close (L) Open (H)
Flickerless OFF *1 Flickerless ON
Close (L) Open (H)
Background lighting Background lighting
correction ON Correction OFF
Close (L) Open (H)
Electronic iris Mechanical iris
Close (L) Open (H)
1001RE setting User setting values
Close (L) Open (H)
20dBmax 26dBmax
Close (L)
Gamma 0.45 (typical)
DOWN
ME Mode
JSW1-4 are not
active in ME mode
Open (H)
Gamma 1.0 (linear)
Page 15
