APPENDIX

6.1 Specifications
TABLE 2.
Page 28
6.1.1 Product Specifications
TMC-7DSP/TMC-6DSP Product Specifications Table
Model
Imager
Pixels
Cell size
Color filter
Scanning
Sync
TV resolution
S/N Ratio
Min. illumination
Video output
Color balance
AGC
Gamma
Lens mount
Power requirement
Operating temp.
Vibration & Shock
Size (W x H x L)
Weight
Power cable
Power supply
Functional options
Accessories
TMC-7DSP (NTSC)
1/2" interline transfer CCD (6.4 x 4.8mm)
768 (H) x 494 (V)
8.4µm (H) x 9.8µm (V)
Cy, Ye, Mg, G complementary color filter
2:1 interlace, field mode scanning
525 lines, 59.94Hz
Internal sync; internal sync/external auto switch with HD/VD input
fH = 15.734KHz, fV = 59.95Hz
460 (H) x 400 (V) TV lines
50 dB (AGC off), 56 dB typical
2 lux F = 1.4 (AGC on)
VBS = 1.0 Vp-p at 75Ω (NTSC and PAL)
Y (B/W) = 1.0 Vp-p with sync, Chroma = 285mV at 75Ω (Y/C or S-VHS)
RGB = 714m Vp-p without sync, Sync 285mV at 75Ω (TMC-7DSP only)
Through-the-lens auto white balance: memory (std) or auto-tracking
(optional) and manual hue adjustment
Max. 32 dB AGC, on-off switchable, manual gain control
0.45 (factory std.), 1.0 (programmable)
12V DC, 280 mA
Vibration: 7 Grms (10Hz to 2000Hz), Shock: 70 G
42mm x 32mm x 146mm (1.65" x 1.26" x 5.74")
12P-02, KC-10 for NTSC/PAL only
12V DC, 500mA
Refer to Option Matrix chart in current Price List
CS-232-7D (Y/C and RS-232 Controller Set,
CBL-2R-7D RGB Cable (for TMC-DSP only)
TMC-7DSP/TMC-6DSP Color CCD Camera
TMC-6DSP (PAL)
752 (H) x 582 (V)
8.6µm x 8.3µm
625 lines, 50Hz
fH = 15.625KHz, fV = 50.00 Hz
450 (H) x 450 (V) TV lines
C-mount
-10°C to +50°C
210g (7.3oz)
