OPERATION

FIGURE 8.

FIGURE 9.
TMC-7DSP/TMC-6DSP Color CCD Camera

3.2.1 Top Board

TMC-7DSP/TMC-6DSP Top Board

VR6 VR5
J5
SW1
1 2 3 4 5 6 7 8
SW1
1 Flon VR2
2 Blcof VR3
3 Miris VR4
4 Aeref VR5
5 AGCMAX VR6
6 Gamma
7 Not used
8 Not used

3.2.2 Bottom Board

TMC-7DSP/TMC-6DSP Bottom Board

VR1
J4
VR1 VD Phase Adjustment
VR2 PLL Adjustment (no mount)
J2
VR4
APL
Sharpness 3.0± 0.1V
C-Gain 2.5± -/1V
Hue 1.8± 0.1V
PLL 3.2± 0.1V
J2
(VR2)
VR3
J1
VR2
TP1 TP3
Page 17
