1.3 Functional Options

Page 2
infrared. It requires only 1.0 lux of minimum illumination and 0.5 lux minimum illumination at
maximum gain. In general, such a low light camera allows use of a higher lens F-value and
provides greater depth of field and sharper images.
• High Resistance To Image Burning
Since the CCD is highly resistant to image burning, the camera may be exposed to bright objects
for a long period of time. It must be noted, however, that a "smear" phenomenon may occur when
shooting a very bright object. An infrared cutoff filter is recommended to obtain a clear picture.
• High Resistance To Magnetic Field and Vibration/Mechanical Shock
Due to its robust design, the CCD imager can withstand strong vibration and shock, and little or no
noise will appear in the picture. Since the TM-5LC camera is not influenced by a magnetic field, it
will produce stable images even when placed next to objects such as electronic furnaces, welding
machines, or NMR scanners.
• Low Power Consumption
Typical power consumption is only 1.5W. This makes the camera excellent for use with battery-
operated systems.
• Optics
The TM-5LC camera is designed for custom optics in OEM applications. The TM-5LC cylindrical
enclosure has M14x0.5 threads that are compatible with Tamron lenses. Additionally, a C/CS-
mount lens can be used with the optional adapter (part number 32-3663).
• Three-Year Warranty
The CCD solid state image sensor allows the camera to maintain a superior performance level
indefinitely while requiring virtually no maintenance. PULNiX backs all of the TM-Series cameras
with a three-year warranty.
Warning: Opening the camera in any way will void this warranty.
• AGC Off (On std.)
• Gamma 0.45 (1.0 std.)
TM-5LC Super-Miniature Cylindrical CCD Camera
INTRODUCTION
