3.2 Adjustment Procedures

FIGURE 12.
Page 18

3.2.1 Signal Board

Signal Board (top side)
W1
AGC
U2
Set W1(AGC/MGC)
Set W2(GAMMA)
Set W3(DV/AV)
Set W4(Video R/S)
Set W5(N/P)
Set W6(FRM/FLD)
Set W7(SMD2)
VR1 AGC
VR2 MGC
VR3 AGC MAX
VR4 Pedestal
VR1 VR2
MGC
ON
U1
DV
W4
R
J4
Right (MGC) Manual Gain
Left(1) Gamma = 1.0
Left(DV) Direct analog (right)
Left(R)
Open(N)
Open(FLD)
Open
TM-7200/TM-6200 High Resolution Digital CCD Camera
VR3 VR4
W2
OFF
W3
AV
S
OPERATION
U3
