OUTLINE DIMENSIONS

Dimensions shown in inches and (mm).
223-Pin Ceramic Pin Grid Array
j
2
j
1
D
e
INCHES
SYMBOL MIN
A 0.084
A 0.40
1
b 0.018 TYP
b 0.050 TYP
1
D 1.844
e 1.700 TYP
1
e 0.100 TYP
L 0.172
3
h 0.020 TYP
j 1.125
1
j 1.065
2
NOTE
When socketing the CPGA package, use of a low
insertion force socket is recommended.
e
1
h
A B C D E F G H J K L M N P R S T U
A
1
b
1
MILLIMETERS
MAX MIN MAX
0.102 2.11 2.59
0.60 1.02 1.52
0.46 TYP
1.27 TYP
1.876 46.84 47.64
43.18 TYP
2.54 TYP
0.188 4.37 4.77
0.500 TYP
1.147 28.56 29.14
1.186 27.05 27.61
