I Quick set mode items

Q1 RF POWER
This item adjusts the RF output power. The RF out-
put power can be adjusted from L, 1 to 9 and H for
indication, however, it can be adjusted continuously.
Q2 MIC GAIN
This item adjusts microphone gain from 1 to 10 for
indication, however, it can be adjusted continuously.
Q2 CW PITCH
This item adjusts the CW pitch. CW pitch is
adjustable from 300 to 900 Hz in 10 Hz steps.
Q2 RTTY TONE
This item selects the RTTY tone. RTTY tone is tog-
gled between 1275, 1615 and 2125 Hz.
Q3 VOX DELAY
This item adjusts the VOX (Voice-activated Transmit)
delay time. The delay time can be adjusted from 0 to
2 sec. in 0.1 sec. units.
Q3 BK-IN DELAY
This item adjusts break-in delay time for CW semi
break-in operation. The delay time is selectable from
2.0 to 13.0 (dots).
Q3 RTTY SHIFT
This item adjusts the RTTY shift. There are 3 selec-
table values: 170, 200 and 425 Hz.
Q4 VOX GAIN
This item adjusts the VOX gain for the VOX (voice
activated transmit) function.
Q4 RTTY KEYING
This item adjusts the RTTY keying. Normal or
reverse keying can be selected.
(all modes)
(SSB/AM/FM only)
(CW only)
(RTTY only)
(SSB/AM/FM only)
(CW only)
(RTTY only)
(SSB/AM/FM only)
(RTTY only)
The default is H (maximum power).
Note that while adjusting the output
power, the power meter is displayed
automatically.
The default is 5.
Note that while adjusting mic gain, the
ALC meter is displayed automatically.
CW
The default is 600 Hz.
RTTY
The default is 2125 Hz.
USB
The default is 1.0 seconds.
CW
The default is 7.5 dots.
RTTY
The default is 170 Hz.
USB
The default is 5.
RTTY
The default is "n," normal.
Normal
Reverse
7
SET MODE
: key open=mark
: key open=space
