ABOUT SP-7 EXTERNAL SPEAKER
If the SP-7 external speaker is used with the IC-706MKIIG, please install the fer-
rite supplied bead on the speaker cable, as shown below.
• A ferrite bead and a cable fastener are supplied with IC-706MKIIG.

INSTALLATION NOTE:

• Install the ferrite bead as near as possible the connecting plug.
• Attach the ferrite bead making a loop with the cable as shown in the diagram at
below left.
• Fasten the ferrite bead and speaker cable with the supplied cable fastener.
1-1-32 Kamiminami, Hirano-ku, Osaka 547-0003 Japan
Cable fastener
pull
Count on us!
A-6045H-2EU
Printed in Japan
© 2001 Icom Inc.
