7
SET MODE
6 AUTO OFF
The auto power OFF function can be used to auto-
matically turn the transceiver OFF after a specified
time of operation. This item can be set to 30 min., 60
min., 90 min., 120 min., or OFF.
7 RF/SQL
The [RF/SQL] control can be set as the squelch con-
trol (default), the RF/squelch control (USA version
default) or automatic
FM/WFM/AM modes; as RF in SSB/CW/RTTY
modes). (See p. 22)
8 SUBDIAL
When this item is set to "rit," pushing [RIT/SUB]
turns the RIT function ON (lights red)—rotating [M-
CH] changes the RIT frequency; when this item is set
to "Freq," pushing [RIT/SUB] turns the sub dial func-
tion ON (lights green)—rotating [M-CH] changes the
operating frequency. Note that in FM, WFM and AM
modes, pushing [RIT/SUB] always selects the sub
dial function (lights green), regardless of this setting.
9 OPT. FIL 1
When an optional filter is installed, this selection is
necessary, otherwise the filters cannot be selected.
Selections available are FL-100, FL-101, FL-103,
FL-223, FL-232 and none (default). See p. 22 for
usable filters for each mode and see p. 60 for filter
installation.
10 OPT. FIL 2
When an optional filter is installed, this selection is
necessary, otherwise the filters cannot be selected.
Selections available are FL-100, FL-101, FL-103,
FL-223, FL-232 and none (default). See p. 22 for
usable filters for each mode and see p. 60 for filter
installation.
11 PEAK HOLD
When the peak hold function is ON, the highest acti-
vated segment of the meter remains visible for 0.5
sec.; when OFF, the meter functions normally.
51
(auto power OFF)
(SQL/AUTO/RF•SQL)
(acts as squelch
(Subdial function)
(optional filter)
(optional filter)
(peak hold)
Auto power OFF
deactivates. (default)
The [RF/SQL] control
in
functions as RF gain
control only.
Pushing [RIT/SUB]
selects the RIT function
(default).
No filters are selected
(default).
No filters are selected
(default).
Peak hold ON
(default)
Auto power OFF set to
20 min.
The [RF/SQL] control
functions as squelch
control only.
Pushing [RIT/SUB]
selects the sub dial function.
FL-223 (for LSB/USB mode)
is selected.
FL-223 (for LSB/USB mode)
is selected.
Peak hold OFF
