7
SET MODE
33 S-LVL SPCH
When an optional UT-102
is installed, the synthesizer can be set to read out the
frequency/mode only, or both the frequency/mode
and S-meter level.
34 CI-V ADDRES
To distinguish equipment, each CI-V transceiver has
its own Icom standard address in hexadecimal code.
The IC-706MKIIG's address is 4EH.
When 2 or more IC-706MKIIG's are connected to an
optional CT-17
main dial to select a different address for each IC-
706MKIIG in the range 01H to 7FH.
35 CI-V BAUD
This item sets the data transfer rate. When "Auto" is
selected, the baud rate is automatically set according
to the connected controller or remote controller.
36 CI-V TRN
Transceive operation is possible with the IC-
706MKIIG connected to other Icom HF transceivers
or receivers. When "on" is selected, changing the
frequency, operating mode, etc. on the IC-706MKIIG
automatically changes those of connected trans-
ceivers (or receivers) and vice versa.
37 CI-V 731
When connecting the IC-706MKIIG to the IC-735 for
transceive operation, you must change the operating
frequency data length to 4 bytes.
• This item be set to "on" only when operating trans-
MUST
ceiver with the IC-735.
55
(S-level speech)
SPEECH SYNTHESIZER UNIT
(CI-V address)
- , rotate the
CI V LEVEL CONVERTER
(CI-V data rate)
(CI-V transceive)
(CI-V operating fre-
quency data length)
Voice synthesizer reads out
both the frequency/mode
and S-meter level (default).
Address set to 58H
(default).
Auto baud rate
(default)
Transceive ON
(default)
Frequency data set to
5 bytes (default).
Voice synthesizer reads out
the frequency/mode only.
Address set to 7FH.
19200 bps
Transceive OFF
Frequency data set to
4 bytes.
