12 QUICK SPLIT

When this item is set to ON, pushing [SPL] for 2 sec.
sets the undisplayed VFO frequency to the displayed
VFO frequency plus the split offset or duplex offset,
and activates split operation.

13 SPLIT LOCK

When this item is ON the main dial can be used to
adjust the transmit frequency (XFC) even while the
lock function is activated.
14 SPL OFFSET
This item sets the offset (difference between transmit
and receive frequencies) for the quick split function.
Note that this setting is not valid in FM/WFM modes.
15 DUP HF
(duplex offset)
This item sets the offset for the duplex function when
operating on the HF bands.
16 DUP 50M
(duplex offset)
This item sets the offset for the duplex function when
operating on the 50 MHz band.
17 DUP 144M
This item sets the offset for the duplex function when
operating on the 144 MHz band.
18 DUP 430M
This item sets the offset for the duplex function when
operating on the 430 MHz band.
19 1TOUCH RPTR
This item sets the offset direction when using the
one-touch repeater function. +duplex or –duplex can
be selected.
(quick split function)
(split lock)
(split offset)
(duplex offset)
(duplex offset)
(one touch repeater)
Quick split function ON
(default).
Split lock function OFF
(default)
Default is 0.100 MHz.
Default is 0.100 MHz.
Default is 0.500 MHz.
Default is 0.600 MHz.
Default is 5.000 MHz.
DUP
Duplex direction is set
to –duplex.
SET MODE
Quick split function OFF.
Split lock function ON
DUP
Duplex direction is set to
+duplex.
