HPOD C-, X-, Ku-Band High-Power Outdoor Amplifier
Appendix C
C.4
Scheduled Maintenance
The SSPA heat sink should be cleaned once a year, or sooner depending on
environmental conditions.
To perform this maintenance:
Step
Task
1
Disconnect power from the HPOD SSPA.
2
Remove the power supply as described in Sect. C.2.1.
3
Remove the fan assembly as described in Sect. C.3.1.
4
Use compressed air to clear the heat sink portions of the power supply.
5
Use compressed air to blow through the SSPA heat sink to remove any foreign object
accumulation that may be obstructing airflow.
6
Re-install the power supply as described in Sect. C.2.2.
7
Re-install the fan assembly as described in Sect. C.3.2.
C–6
Revision 6
MN/HPOD.IOM
