Table A-1. Summary Of Available Redundancy System Assembly Kits - Comtech EF Data HPOD Installation And Operation Manual

HPOD C-, X-, Ku-Band High-Power Outdoor Amplifier
Appendix A
SECTION / TABLE
PRODUCT (Parts List)
A-2
A-3
A.2
Common Kits
A-4
A-5
N/A
A-6
A-7
–
A.3
1:1 Kits
A-8
A-9
A-10
A-11
A.4
N/A
1:2 Kits

Table A-1. Summary of Available Redundancy System Assembly Kits

FIGURE(S) CEFD P/N
A-1 PL/12319-1
A-2 PL/12300-1
A-3 KT/12200-1
A-4 KT-0000017
A-5 thru A-9 N/A
A-10 KT/11799
A-11 KT/11387
A-12 KT/12240-1
A-13 KT/12201-1
A-14 KT-0020523
A-15 KT/11936-1
A-16 KT/12337-1
A-17 thru A-21 N/A
DESCRIPTION
Universal Pole Mounting Kit
HPOD Unit Mounting Kit
HPOD 1:1 Redundancy System – Common Unistrut Kit
HPOD 1:2 Redundancy System – Common Unistrut Kit
HPOD 1:1 Redundancy System Mounting and Switch Kit Examples
ODPA C-Band 1:1 Redundancy Switch/Waveguide Kit
ODPA X-Band 1:1 Redundancy Switch/Waveguide Kit
HPOD 1:1 C-Band Redundancy System – Switch and Unistrut Assembly
HPOD C-Band 1:1 Redundancy Switch/Waveguide Kit
HPOD C-Band Offline Unit Termination Bypass Waveguide Kit
HPOD Ku-Band 1:1 Redundancy Assembly Kit
HPOD Ku-Band 1:1 Redundancy Switch/Waveguide Kit
HPOD C-Band 1:2 Redundancy System Mounting and Switch Kit Examples
